GoPro Wi-Fi Remote Manuel utilisateur
Wi-Fi Combo Kit
USER MANUAL + WARRANTY INFO
1_ComboKit_UM_ENG_v9.indd 1 3/15/12 11:50 AM
IMPORTANT: Before using your Wi-Fi
BacPac™and Wi-Fi Remote™
, you will
need to download product updates at:
gopro.com/update
3
Wi-Fi Remote + Wi-Fi BacPac
1_ComboKit_UM_ENG_v9.indd 2-3 3/15/12 11:50 AM
Congratulations
on your purchase of the Wi-Fi Bacpac+
Wi-Fi Remote Combo Kit. Now you
can Wi-Fi enable your GoPro camera
and control it with your Wi-Fi Remote,
smartphone or tablet. You can live
stream* video
and share photos + videos
to the web
wherever you have a network
connection.
Wi-Fi BacPac +
GoPro Camera
GoPro App:
Full camera control
plus live preview and
playback of photos
+ videos on most
smartphones and
tablets
GoPro Remote:
Control up tp 50
cameras at a time
from up to 600/
180m away
(optimal conditions)
Wi-Fi Network:
Live stream* video and share photos
+ videos to the web where ever you
have a network connection
*
Live streaming, video + photo sharing to the web and Bluetooth will be
downloadable with a future product update at gopro.com/update
1_ComboKit_UM_ENG_v9.indd 4-5 3/15/12 11:50 AM
Wi-Fi BacPac
Features 10
Battery + Charging 11
Assembly 12
Powering Camera ON/OFF XX
Wi-Fi Remote
Features 16
Battery + Charging 17
Camera Control XX
Ways to Wear 18
Connecting
CONNECT HD HERO2:
Wi-Fi Remote 24
Smartphone/Tablet 25
Wi-Fi Network 25
CONNECT ORIGINAL HD HERO:
Wi-Fi Remote 24
Safety Instructions 28
Limited Warranty 32
Table of Contents
1_ComboKit_UM_ENG_v9.indd 6-7 3/15/12 11:50 AM
Wi-Fi BacPac
9
1_ComboKit_UM_ENG_v9.indd 8-9 3/15/12 11:50 AM
Wi-Fi BacPac POWER/MENU Button.
ACTION RESULT
Short Button Press
When BacPac is powered OFF
Powers ON the Wi-Fi BacPac
Short Button Press
When BacPac is powered ON
Shortcuts HD HERO2 to Wi-Fi
menu. Not supported on
original HD HERO.
Long Press Powers OFF the Wi-Fi BacPac
Status Screen (indicates battery level and connection
status of Wi-Fi battery and Bluetooth).
USB Port (cable included).
Features
We recommend charging your Wi-Fi BacPac for one hour
before using it the first time, however no damage will occur
if you don’t. To charge the Wi-Fi BacPac, connect it to a
computer or USB power supply with the included USB cable.
Checking Battery Level
When the Wi-Fi BacPac is not attached to a camera, you
can check it’s battery level on the Status Screen by pressing
the
POWER/MENU button. The display will turn on for 5
seconds to show battery power level.
The Wi-Fi BacPac will
not power ON unless it is attached to a GoPro camera.
Wi-Fi BacPac Battery Life
When the Wi-Fi BacPac’s battery runs out it will pull power
from the camera’s battery. This extends the life of your Wi-Fi
BacPac but will drain your camera’s battery over time.
Battery + Charging
10 11
1_ComboKit_UM_ENG_v9.indd 10-11 3/15/12 11:50 AM
ATTACHING THE WIFI BACPAC TO A GOPRO CAMERA:
1. Slide the hooked end of the Wi-Fi BacPac (A) into the groove on the
right side of the camera body (B).
2. Push the Wi-Fi BacPac connector (C) into the HERO Port (D) on the
back of the camera.
3. Power ON the Wi-Fi BacPac by pressing the POWER/MENU button.
In addition to wirelessly connecting your camera to the
Wi-Fi Remote, smartphones, tablets and networks, the
Wi-Fi BacPac makes it possible to turn cameras ON/OFF
with these devices.
To do this the Wi-Fi BacPac must be powered ON even
when your camera is powered OFF
.
Wi-Fi BacPac Battery Life
To learn how long your Wi-Fi BacPac Battery will last while
powered ON in idle mode waiting to turn your camera ON,
visit gopro.com/support
When the Wi-Fi BacPac’s battery runs out it will pull power
from the camera’s battery. This extends the life of your Wi-Fi
BacPac but will drain your camera’s battery over time.
Assembly Powering Camera
12 13
1_ComboKit_UM_ENG_v9.indd 13 3/15/12 11:50 AM
Wi-Fi Remote
15
1_ComboKit_UM_ENG_v9.indd 14-15 3/15/12 11:50 AM
Features
1. LCD Display
2. SHUTTER/SELECT Button >
3. POWER/MODE Button >
4. Status LED
5. Removable Attachment Strap
6. Removable Attachment Key + Key Ring
7. Charging Port / Attachment Key Slot
Battery + Charging
We recommend charging your Wi-Fi Remote for one hour
before using it the first time, however no damage will occur
you don’t. To charge the Wi-Fi Remote, connect it to a
computer or USB power supply with the included USB cable.
The LCD Screen displays the Wi-Fi Remote’s
battery while the Wi-Fi Remote is powering
ON or charging.
To charge: Plug charging cable into charging slot until
it clicks.
To remove charger: Slide and hold the latch lever in the
direction of the arrow, then remove the charging cable.
Note: This slot is used for the charging cable and the attachment key.
ICON The Wi-Fi Remote is waterproof to 10 / 3m.
16 17
1_ComboKit_UM_ENG_v9.indd 16-17 3/15/12 11:50 AM
Camera Controls
You will have different Wi-Fi Remote on-screen camera
controls if you are connected to more than one camera
at a time.
Wi-Fi Remote Connected To One Camera
Your Wi-Fi Remote Screen will match exactly
what appears on your HD HERO2 camera
Wi-Fi Remote Connected to Multiple
Cameras
When you cycle through the modes on the Wi-Fi
Remote Screen, you wil see:
DEFAULT
MODE
Wi-Fi Remote
Default Start-
up Mode
Sets all cameras
to their default
power-up
mode
Video Mode
Sets all
cameras
to video
mode.
Photo Mode
Sets all
cameras
to photo
mode.
Burst Mode
Sets all
cameras
to burst
mode.
Time-lapse
mode
Sets all
cameras to
time-lapse
mode.
Ways to Wear
ATTACHMENT STRAP:
The Attachment Strap attaches to your wrist, backpack
straps, poles, bike frames and more. To attach the Wi-Fi
Remote to the Attachment Strap:
1. Thread the Attachment Strap through the slots on the bottom of
your Wi-Fi Remote.
2. Position Wi-Fi Remote along the strap until positioned as shown below.
18 19
1_ComboKit_UM_ENG_v9.indd 18-19 3/15/12 11:50 AM
