GOLDEN PRIME TECHNOLOGIES JMG-PULP 500 Mode d’emploi
Juicer Mixer Grinder
&
Mixer Grinder
INSTRUCTION MANUAL
CUM
WARRANTY CARD
Juicer Mixer Grinder & Mixer Grinder
JUICER MIXER GRINDER
JMG-BLISS 500 | JMG-PULP 500 | JMG-PULP +500
MIXER GRINDER
MG-QUIXI 500 | MG-QUIXI 550 PREMIUM
MG-QUIXI 600 | MG-QUIXI 750
Dear Customer,
Welcome to the world of Golden Prime Home Appliances.
GP brings this amazingly versatile home appliance which will reduce your kitchen drudgery. The Juicer
Mixer Grinder / Mixer Grinder is a great time saver and a convenient gadget.
This booklet will help you to understand and use your JMG properly. It gives you the required
instructions on its operation and care.
Precautions.................................................3
Electrical Requirement .............................3
Know Your Juicer Mixer Grinder.............4
Technical Specications....................4
How to Assemble the Jar..................6
Know Your Mixer Grinder .........................7
Technical Specications....................8
How to Assemble the Jar..................9
Usage of Control Panel......................9
Motor Overload Protector (OLP) ......9
Juicer Mixer Grinder/Mixer Grinder .... 10
Instruction For Use .......................... 10
Instruction For Cleaning ................. 11
Important Safeguards..................... 11
Notes......................................................... 12
Terms & Conditions................................ 14
Warranty Card ......................................... 15
CONTENT
3
PRECAUTIONS
• Read the instructions carefully before using the Juicer Mixer Grinder (JMG)/Mixer Grinder (MG).
• Place the your JMG/MG on an even platform at a convenient height so that the ingredients under
operation can be easily seen.
• Have sucient space around the JMG/MG to keep the various items required. Also ensure that
the JMG/MG is placed 6 inches away from the wall.
• Keep the JMG/MG away from heat and sunlight.
• The JMG/MG operates at optimum eciency at the specied voltage. Wide variations in voltage
may affect the performance of the JMG/MG.
• Clean the oil traces inside the jar before rst use.
• Do not run the mixer without load.
• Ensure that the JMG/MG housing is tted properly on to the motor housing before operation.
• Fix the jar to the base unit by turning it clockwise. Make sure it is rmly locked in position prior to
usage.
• Never insert your hand/spatula/spoon when the JMG/MG is in operation.
• Since the blades are quite sharp, be careful while changing them.
• Use only lukewarm water to clean your JMG/MG.
ELECTRICAL REQUIREMENT
• Check that the voltage on the rating plate of your appliance corresponds with your house
electricity supply which must be AC.
IMPORTANT NOTES:
1. GP products are intended for household use only.
2. Parts illustrated in this use and care manual are indicative only, parts provided with the
products may differ with illustrations.
3. Specications are subject to change without notice.
Juicer Mixer Grinder & Mixer Grinder
Mix
1
2
3
79
11
10
1
58
3
6
2
4
12
13
No Part Name No Part Name
1 Main Body 8 Bottom Pad
2 Bottom 9 Food Pusher
3 Juicer Cover 10 Blender Jar
4 Power Cable 11 Blender Jar Lid
5 Rotary Knob 12 Dry Grinding Jar
6 Swing Locks 13 Dry Grinder Jar Lid
7 Spout Cover
KNOW YOUR JUICER MIXER GRINDER
5
TECHNICAL SPECIFICATIONS
MODEL JMG-BLISS 500 JMG-PULP+500 JMG-PULP 500
VOLTAGE 220-240V
WATTAGE 500W
SPEED CONTROL 3 Speed Piano Switch with Incher Facility
3 Speed Control with
Incher (Rotary) for
Momentary Operation
RPM (Approx) 18500 19000 18000
MAIN CORD 1.5 mtr Long, 2 Pin 1.5 mtr Long, 3 Pin 1.5 mtr Long, 2 Pin
PROTECTION Class II
MOTOR INSULATION Universal Class - B
MATERIAL
HOUSING High quality ABS Plastic
JAR LIQUIDISER SAN
JAR GRINDER Stainless Steel
CHUTNEY JAR N/A Stainless Steel N/A
CAPACITY
LIQUIDISER JAR 1500 ml
JAR GRINDER 1000 ml
CHUTNEY JAR N/A 400 ml N/A
Juicer Mixer Grinder & Mixer Grinder
HOW TO ASSEMBLE THE JAR
JUICER JAR
1. Slide the online pulp container
into the juicer body.
4. Place the juicer cover onto the
juicer body diagonally as shown in
the gure, then push it down.
2. Place the juicer casting on the
basic unit.
5. Lock the clamps on both sides
of the juicer body.
3. Place the lter mesh into the
body and push down slightly so
that the mesh sits and locks the
lower coupler of the basic unit. If
necessary, rotate the mesh a little
till it sits.
6. Plug the cord in and the juicer is
ready to use.
BLENDER JAR / GRINDER JAR
1. Place the grinder jar on the basic
motor unit and turn it in a clockwise
direction till it locks in place.
2. Put the cover on the jar and place
your hands rmly on the cover.
3. Plug the cord into the mains. Now
run the jar on the incher / whipper
speed for 1 second to see if the jar
has t properly.
7
KNOW YOUR MIXER GRINDER
No Part Name No Part Name
1 Main Body 7 Flat Lid for Dry/Wet Grinding Jar
2 Speed / Incher Selector Knob 8 Dry/Wet Grinding Jar
3 Liquidising Jar 9 Jar Base
4 Dome for Liquidising Jar 10 Chutney Jar Lid
5 Dome cap for Liquidising Jar 11 Chutney Jar
6 Jar Handle
Juicer Mixer Grinder & Mixer Grinder
TECHNICAL SPECIFICATIONS
MODEL MG-QUIXI 500 MG-QUIXI 550
Premium MG-QUIXI 600 MG-QUIXI 750
VOLTAGE 220-240V
WATTAGE 500W 550W 600W 750W
SPEED CONTROL 3 Speed Control with Incher (Rotary) for Momentary Operation
RPM (Approx) 19,500 19,800 20,500 21,000
MAIN CORD 1.5 mtr Long, 2 Pin 1.5 mtr Long,
3 Pin
PROTECTION Class II
MOTOR
INSULATION Universal Class B
MATERIAL
HOUSING High quality ABS Plastic
JAR LIQUIDISER Stainless Steel
JAR GRINDER Stainless Steel
CHUTNEY JAR Stainless Steel
CAPACITY
LIQUIDISER JAR 1200 ml 1500 ml
JAR GRINDER 750 ml 1000 ml
CHUTNEY JAR 350 ml 450 ml
9
1
2
3
4
1. Hold the jar in one hand and check if the blade moves freely and rotates (g. 1).
2. Place ingredients in the Steel Jar. Cover the Jar with dome/lid. Place the jar on the basic unit, press
it slightly downward and then turn it clock wise to lock it in the top body socket (g. 2)
3. Plug in. Support cover gently by hand (g 3) and switch on using the slowest speed (position 1 off
switch).
4. Switch off after operation. For unlocking the jar, press the jar downward and then turn it anticlock
wise (g. 4) and lift the jar from the basic unit.
HOW TO ASSEMBLE THE JAR
USAGE OF CONTROL PANEL
The control panel is a 3 speed rotary switch with an in built 4” inching position for whipping operation.
For whipping, turn the rotary switch in the anticlockwise direction.
0
4
1
2
3
0
4
1
2
3
0
4
1
2
3
0
4
1
2
3
0
4
1
2
3
MOTOR OVERLOAD PROTECTOR (OLP)
The JMG/MG is tted with a heavy duty universal motor using a
winding wire that can withstand extremes of temperatures. It is
however possible that the mixer motor may get overloaded when you
attempt to grind quantities in excess.
The motor of the JMG/MG is protected by a resetting type Over Load
Protector (OLP).
In case of overloading, the OLP disconnects the power supply to the
motor, in such an event, switch off the supply. Remove the excess the
load or add water to the ingredients.
Wait for a few minutes. Reset the OLP located below the base plate
and restart the mixer.
Juicer Mixer Grinder & Mixer Grinder
INSTRUCTIONS FOR USE
JUICER (In JMG only)
1. Mount the juicer housing cum pulp chamber on the basic unit.
2. Place the juice mesh into the juicer body. Ensure that the mesh is placed properly and locks the
lower couple of the basic unit. Please check its tment by rotating it by hand to see if it is rotating
freely. Don’t apply any undue pressure.
3. Slide the juice Sport (outlet) cover in position and press.
4. Mount the juice cover onto the juice body and lock the clamps, plug the cord in and the juicer
is ready to use. Press the switch marked ‘Pulse’ to check if the lter mesh assembly is properly
seated with the lower couple of the basic unit. The mesh should spin evenly without wobbling.
5. Wash ingredients and cut in small pieces to t feeder opening and place a glass under the spout.
Set switch to position ‘1’. Push Ingredients into feeder with the food pusher.
6. For short operations, turn the speed control to pulse position.
7. Once the juicing operation is over, press the ‘0’ button and unplug the unit.
LIQUIDIZING JAR - BLENDING
1. The minimum capacity of the jar is 1/3 of the jar and maximum capacity is 2/3.
2. Fill the jar with solids to be liquidized.
3. Fit the jar onto the main unit.
4. Add water, if needed.
5. Cover the jar with the lid.
6. Now switch on the mixer for a minute to get nely blended juices and purees.
GRINDER JAR - WET/DRY
1. This jar can be used for grinding black pepper, roasted coffee seeds, turmeric, coriander, red
chillies, etc.
2. The jar should not be lled more than half of its total capacity.
3. Ensure that the jar is absolutely clean and dry.
4. Fill the jar with the ingredients.
5. Cover the jar with the lid and t on the main unit.
6. While grinding turmeric, break it into smaller pieces before you start grinding.
7. If the ingredients need to be stirred during wet grinding of rice and dal batter, stop the mixer,
insert the spatula and stir.
CHUTNEY JAR
1. This jar can be used for preparation of chutneys.
2. Inch to 5-7 times to powder ingredients.
3. Then add water as required.
4. Cover the jar with the lid and t on the main unit.
JUICER MIXER GRINDER/MIXER GRINDER
