Gold Note PH-1 Manuel utilisateur

Italian Music Experience

OWNER’S MANUAL

PH-1

MM & MC PHONO PREAMPLIFIER

IMPORTANT SAFETY INFORMATION

This appliance has a serial number located on the rear panel.

Please record the model and serial number and retain them for your records.

Serial Number:

Model:

Do not disassemble any part of the product.

Do not use any part of the product for other purposes.

For service and problems of any kind, contact qualied Gold Note personnel.

Protect the product from rain and humidity and keep away from heat sources, electric and electronic motors etc.

The power Chord supplied must be used only on this unit.

Gold Note does not have responsibility for any improper use of this unit.

CAUTION!

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER ONLY TO QUALIFIED GOLD NOTE SERVICE PERSONNEL FOR SERVICE

WARNING!

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE

IMPORTANT SAFETY INFORMATION

1. Read these instructions and store them.

2. Heed all warnings.

3. Follow the instructions.

4. Do not use this apparatus near water.

5. Clean only with a dry cloth.

6. Do not block the ventilation openings and install in

accordance with the manufacturer's instructions.

7. Do not install near heat sources such as radiators, heat

registers, stoves or other apparatus (including ampliers) that

produce heat.

8. Do not defeat the safety purpose of the polarised or

grounding-type plug: a polarised plug has two blades with

one wider than the other.

A grounding type plug has two blades and a third grounding

prong.

The wide blade or the third prong are provided for your safety.

If the provided plug does not t into your outlet, consult an

electrician for replacement of the obsolete outlet.

9. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

10. Only use attachments/accessories specied by the

manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table

specied by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the

cart/apparatus combination to avoid injury from tip-over.

12. Unplug this apparatus during lightning storms or when

unused for long periods of time.

13. Refer all servicing to qualied service personnel only.

Servicing is required when the apparatus has been damaged

in any way (such as when the power cord or plug is damaged,

liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or

moisture) and in any case when the apparatus does not

operate normally or has been dropped.

INTRODUCTION & SPECIFICATIONS

The Gold Note PH-1 is a high performance convenient MM & MC phono preamplier featuring Ultra Linear

Power Supply.

The design developed for the PH-1 allows matching easily any kind of MM and MC cartridge with a wide

option of set up with easy access impedance setting and true balanced design output connectors.

The PH-1 enables superior audio purity with any audio system featuring an optional external super

Power Supply (PSU).

SPECIFICATIONS

Frequency response: 20Hz-20kHz at +/-3dB

THD – Total Harmonic Distortion: <0.05% THD at 20Hz-20kHz Gain: >65dB MC – >48dB MM

Signal to Noise ratio: -88dB

Analogue input: one stereo RCA

Input sensitivity: from 0.15mV MC – up to 6.0mV MM

Input impedance: 470ΩMC variable – 47KΩMM xed

Audio out: stereo RCA

Line output level: 2V RCA xed

POWER

Mains supply: 100/115/230V, 50/60Hz, depending on market destination and not convertible

Power supply: Ultra Linear

Power consumption: 20W max

PHYSICAL

Dimensions: 100mm L x 105mm H x 260mm D

Total weight: 3.5 kg

TECHNICAL INFO & OPTIONS

OPERATING CONDITIONS

Once the PH-1 has been correctly wired and positioned on a solid shelf it is ready to play.

The PH-1 has been designed for use in Hi-Fi systems in sheltered locations. It ought therefore to be protected from any

eventual variations in temperature and humidity. Avoid to use the unit close to radiators or other strong heat sources,

electrical and electronic motors, switched on mobile phones etc.

The location in proximity of other audio components is not theoretically critical, but you should nevertheless pay attention to

this.

In any case, take care to unplug completely the unit every time you need to move it, or to move the turntable on which it is

matched.

PH-1 GAIN & LOAD

The PH-1 should be purchased set up already as per user needs concerning both Gain and Load.

It is anyway possible vary the PH-1 Gain from MM to MC.

It is also possible vary the load impedance on this unit.

Because to do that is necessary to remove the cover of the unit we suggest to contact the local Gold Note® distributor to avoid

of warranty invalidity.

Once the cover is removed it is possible to access the DIP SWITCH with 4 Micro-Switches underneath two black Chokes.

The Micro-Switches 1 & 4 can vary the Gain of the unit: setting the Micro-Switches towards the NUMBERS SIDE the PH-1

operates in MM mode; while setting the Micro-Switches towards the ON SIDE the PH-1 operates in MC mode.

The Micro-Switches 2 & 3 are able to vary the load impedance of the unit: with the Micro-Switches towards the NUMBERS SIDE

the PH-1 operates with a x 47K

(right for all MM cartridges); with Micro-Switches towards the ON SIDE the PH-1 operates

with a 470

(default) or changing the resistors (optional) with the unit with a specic load as requested by the user

PANNELLO POSTERIORE

ON/OFF MASTER SWITCH RCA L/R

ANALOGUE AUDIO OUT

RCA L/R

ANALOGUE AUDIO IN

AC IEC POWER PLUG

WITH FUSE (500MA) PSU-1 INPUT

EXTERNAL POWER SUPPLY

GND GROUND

WARRANTY & SERVICE

WARRANTY

To validate the warranty is necessary to register the unit on the Gold Note internet web site within 15 days from the purchase on the

appropriate area of the web site:

www.goldnote.it/warranty

If the unit is not registered correctly or has been purchased from a different country of the purchaser home address the unit will not be

covered by any warranty and the registration will be refused.

The warranty does not does not cover in any case: Tubes, Phono Cartridge Styli and Batteries.

SERVICE

Every GOLD NOTE® product is the result of meticulous technological research, and consequently their correct functioning is guaranteed.

In spite of this it is possible that problems may emerge which non-specialist users cannot resolve.

In this case, contact your dealer to be advised on how the fault can be solved.

Do not return any object directly to the factory or to the national distributor or without being authorised to do so.

In such cases both GOLD NOTE® and the distribution agents operating within your territory decline responsibility of any kind.

For more information please visit www.goldnote.it/service

PLEASE NOTE

Descriptions and technical characteristics may vary at any time and without notice.

FAQ

HOW TO ADJUST IT

For spare parts visit the ofcial Gold Note store at:

http://www.akamaiaudio.it/

ACTION

DESCRIPTION

MATCHING THE CARTRIDGE

CLEANING THE PHONO STAGE

The MC & MM cartridges may

need a specic Gain and Load

impedance adjustment.

The Phono Stage is dirty and

needs to be cleaned

Refer to page 4 of this manual MM to set up properly

both the MM or the MC cartridge.

With EXTREME care use ONLY pure alcohol and a

very soft 100% cotton cloth to sweep dust and stains

out.

Any acid or not extremely soft cloth will irreversibly

damage the Phono Stage ne aesthetic.

Do not use any alcohol to clean the Phono Stage

anodized label, or printed parts.

Only dry cloth is allowed

TROUBLESHOOTING

SYMPTOM DESCRIPTION CAUSE REMEDY

SPEAKER HUMMING

PROBLEMS

The speakers hum

when the Phono

Stage is connected to

the system

The Phono Stage is very

SENSITIVE to house environment

positions.

Be sure the position chosen is

compatible with the Phono Stage.

Try to plug or to unplug the ground

connector always nding the best

solution of your audio system.

The Electrical loops created by the

ground connection needs to be tried.

The “open” input of the Phono Stage

may strongly hum. Always connect the

Input Interconnect to test the Phono

Stage.

Any phono stage designed to achieve

good sonic performances hums a bit

when the volume of the amplifier is

high. That is normal and strongly

noticeable especially without music

and with MC gain unit selection.

Install them well. Eventually a tone

arm cable problem can occur; please

check other ways out

Be sure to always use shielded cables

for Phono Stage connections.

Connect it being sure that the AC wall

plug works

Connect them properly

Substitute the fuse with one of the

same value.

Be sure you selected the right Input

of the amplifier

The Ground connector is not

plugged.

The Phono stage Input

Interconnect are not plugged.

The listening volume is very

high.

The tone arm and cartridge are

not properly installed

The interconnect input and/or

output cables are not shielded.

The AC Phono Stage plug is

disconnected from the AC wall

plug

The interconnect cables are not

properly connected to the Phono

Stage.

The fuse is blown

PHONO STAGE (THE)

DOES NOT WORK WHEN

THE PHONO STAGE IS

SWITCHED ON

NOTE
