Gobius Pro Manuel utilisateur

Gobius Pro, Instructions on paper, August 2019-1

Gobius Sensor Technology AB

Ljungåsvägen 2

Phone +46 (0)31 650170

302 91 Halmstad

www.gobius.se

Sweden

[email protected]

Hi.

This information is for you who likes to have them written on paper.

You will get the same and more updated info when downloading the App,

Gobius, from Internet, Google play and App Store.

Please note that you have to get the App before installing the sensor.

You do all settings from the App.

After installation you don’t need the App for using the Gobius Pro.

If you connect a panel like our Gobius fish with 2 LEDs in red and green,

you don’t need your phone to use the sensor.

Download the Gobius App from Google Play or App Store.

In the Gobius Pro box you get:

-1 sensor with 2 m cable

-1 tank surface 3M Cleaner

-1 extra 3M sensor tape

-1 panel (the Gobius fish) with

1 red and 1 green LED light

Check the tank wall thickness. If it’s thicker than the specification,

Gobius Pro will not work.

-Stainless Steel & Steel 3 mm

-Polyethene, 12 mm

-Aluminium, 5 mm

-Fibre Glass, 8 mm

There are some more important things you have to consider

before mounting the sensor on the tank wall.

-Don’t put the sensor closer than 35 mm from an edge,

or another sensor and always on a vertical side of the

tank.

-The tank wall temperature has to be above + 20 C (+ 68 F).

If it’s below the tape will not work satisfying. A heat gun

or a hair dryer can be useful when you need to heat up

the tank wall. After the installation the sensor will work

between -10 C and + 60 C.

If you are going to install more than one sensor on the tank, always

start with the lowest. Repeat the Guide again for the next coming sensor.

You can have maximum 9 sensors on one tank and the App can manage

several tanks.

Mounting the sensor on the tank wall. Start with cleaning the place for

the sensor. Please use the 3M Cleaner. Check that the tank wall is not

concave, and that the temperature is above +20 C. Peal of the protective

paper on the tape and press firmly (hard) on the sensor some seconds

and wait a few minutes before proceeding with next step.

Each sensor has 2 digital outputs (On & Off signal).

You can connect lamps, relays or buzzers to each

sensor. In the package you get the “Gobius fish”

panel with two LEDs, red and green. See also last page.

Now it’s time for connecting the sensor to the power,

+ is red cable and - is black. The sensor is supporting 12-24 volts.

(If you connect the other way, nothing will be damaged).

Your smart phone has to have Bluetooth activated to get in contact with the

sensor. Please have a look in your phones Configuration. The Gobius App will

automatically connect to the sensor. You DON’T have to pair the sensor in your

phones configuration. No code is necessary for pairing the phone with the sensor.

The App is now searching for your sensor. When you have your sensor Bluetooth

connected, you can say “Hello” to the sensor. The sensor will give back an audible

signal.

Now it’s time for configuration.

-Give your tank a name

-Alarm, select

oWhen the level is above the sensor

oWhen the level is below the sensor

oAlways off

-Fluid, select

oWater tank

oGasoline tank

oDiesel tank

oGrey water tank

oWaste/black water tank

oOil tank

oOther fluid tank

-Measurement period, select (time between measurement)

o10 sec

o30 sec

o1 min

o2 min

o1 hour

o4 hour

o24 hour

o48 hour

oNever

-Tank material, select

oPolyethene

oSteel

oStainless steel

oAluminum

oFiber Glass

-Digital output 1, select (green and red cable)

oAlways off

oAlways on

oOn when the level is above the sensor

oOn when the level is below the sensor

-Digital output 2, select (yellow and red cable)

oAlways off

oAlways on

oOn when the level is above the sensor

oOn when the level is below the sensor

-Calibration, select (The fluid level has to be above or below the sensor

when performing the calibration)

oFull tank

oEmpty tank

After performing this configuration you can start the Calibration. It will take about

10 seconds. When it’s done you will get OK on your phone. The sensor is now

ready to work.

On the Show screen you have some small icons

-Number of Bluetooth icons = number of sensors

-Extra alarm when full = Red

-(if not = Green)

-Blue icon, saying that the sensor is Bluetooth connected

to your phone. Red icon, no Bluetooth connection

-Bar chart, animation. The sensor is measuring

-The green bar = the fluid level

-Extra alarm when empty = Red

(if not = Green)

-Wheel, press for going to Setup pages

-If you have more than one tank, scroll left-right

More information on the Show screen

-ABOUT, gives you

oVersion no

oName of the developers

oSupport, direct mail contact with our Support Center

oGDPR And Warranty issues

-GUIDE

oDirect access to install next sensor

Level information. If you have one or two sensors on the tank,

you get a dot in red or green, showing if the level is above or

below the sensor. See also point 11 above in this instruction.

If you have more than two sensors, you get a bar chart showing

the level in your tank. Depending on the choice of fluid, you get

different colors on the bar.

From the configuration icon on the Show screen, you can make an extra

measurement. Please note that your phone has to be connected (Via Bluetooth) to

the sensor.

Edit the sensor Settings

You can always change the settings when you like to do it, like change the Tank

name.

When you do a new Calibration it will be done for all sensors on the tank.

If a title on your phone is in grey, it means that you are not Bluetooth connected

to your sensors.

Sample with the Gobius fish panel

Digital output 1: Select, “On when the level is above the sensor”,

please connect the green cable + the red cable to the fish cables.

The red LED will light when the level is above the sensor.

Digital output 2, Select, “Always on”, please connect the yellow cable + the red

cable to the fish cables. The green LED will always light when the power to the

sensor is on.

Adding more sensors

Start always from the sensor and go up wards, one by one sensor.

Editing several sensors

You can always make a new Calibration for all sensors at the same time, as well as

changing settings like: measurement period, titles, digital outputs and warning yes

or no.

For more information, please contact

Gobius Sensor Technology AB

Anders Meiton, CEO and inventor of Gobius products

Phone: +46 (0)31 650170

E-mail: [email protected]

Gobius Sensor Technology AB develops and markets innovative products and

solutions that create positive effects for boat owners and the world wide maritime

environment. The products are easy to install, easy to use, reliable and are

environmental friendly. Gobius is marketed by distributors and dealers in 22

countries. The company started in 2008 as FM Marin AB and has launched

products, which in an easy and effective way, from the outside of the tank,

measure the level of waste, water, fuel and fluid tanks. We have also received

some awards in Sweden, Europe and USA.

Patent/Trademarks: US 8.448.509, Sweden 0701520-9 and EU 2165164.

Trademark Gobius, owned by Gobius Sensor Technology AB.

For further information, please visit www.gobiuspro.com and

www.gobius.se.
