GOAL ZERO Nomad 20 Manuel utilisateur

Table of Contents

Get To Know Your Gear 2

How It Works 4

Auto Restart 5

Chaining 6

Frequently Asked Questions 7

Technical Specifications 8

Français 9

Español

Deutsch

日本語

GET TO KNOW YOUR GEAR

Adjustable

Kickstand

20 Watt Solar Panel

Flip Charging

Dock

8mm Output

USB

Output Port

8mm

Chaining Port

4 5

HOW IT WORKS

Charging phones, power banks and other USB-powered devices

from the Nomad 20 is as easy as plugging in.

1. Open your Nomad 20 and unfold the panels.

2. Use the built-in kickstand to position the panel toward the

sun.

3. Plug your phone or device into the USB port located on the

back side of the panel and charge up.

Charge a Sherpa Power Bank or small Goal Zero Yeti Power

Station from the sun using the integrated 8mm solar charging

cable.

1. Open your Nomad 20 and unfold the panels.

2. Plug the 8mm cable into the 8mm port located on your power

bank or power station and charge up.

NOTE

A Goal Zero Flip power bank (sold separately) will fit securely

into the Flip charging dock to collect and store power while on

the move.

USB Charging

8mm Charging

STORE

Plug a Goal Zero Power Bank

or phone into the panel.

COLLECT

Gather the sun’s energy

with the solar panel.

POWER

Charge gear

anywhere.

WHAT IT POWERS

Phone Sherpa 100AC Goal Zero

Yeti 200X Lithium

+ Other

USB Devices

Sherpa 100PD

AUTO RESTART

PRO TIP

In low light conditions (i.e. lack of sunlight, shadow, dusk,

etc.), some devices, including smartphones, will automatically

stop charging from a solar panel due to a low current input.

The Nomad 20 features auto restart technology that knows

the difference between a device that has reached a fully

charged state and one that disconnects due to environmental

causes. When the latter is detected, the Nomad 20 will

automatically resume charging to start charging the device

again. No extra work on your part is needed.

When operating in low light conditions, we recommend

pairing your solar panel with a portable power bank for the

best charging experience possible. A Goal Zero Flip power

bank (sold separately) will fit securely into the Nomad 20’s

integrated Flip charging dock and allow you to collect and

store a continuous stream of power to charge your device.

4 5

HOW IT WORKS

Charging phones, power banks and other USB-powered devices

from the Nomad 20 is as easy as plugging in.

1. Open your Nomad 20 and unfold the panels.

2. Use the built-in kickstand to position the panel toward the

sun.

3. Plug your phone or device into the USB port located on the

back side of the panel and charge up.

Charge a Sherpa Power Bank or small Goal Zero Yeti Power

Station from the sun using the integrated 8mm solar charging

cable.

1. Open your Nomad 20 and unfold the panels.

2. Plug the 8mm cable into the 8mm port located on your power

bank or power station and charge up.

NOTE

A Goal Zero Flip power bank (sold separately) will fit securely

into the Flip charging dock to collect and store power while on

the move.

USB Charging

8mm Charging

STORE

Plug a Goal Zero Power Bank

or phone into the panel.

COLLECT

Gather the sun’s energy

with the solar panel.

POWER

Charge gear

anywhere.

WHAT IT POWERS

Phone Sherpa 100AC Goal Zero

Yeti 200X Lithium

+ Other

USB Devices

Sherpa 100PD

AUTO RESTART

PRO TIP

In low light conditions (i.e. lack of sunlight, shadow, dusk,

etc.), some devices, including smartphones, will automatically

stop charging from a solar panel due to a low current input.

The Nomad 20 features auto restart technology that knows

the difference between a device that has reached a fully

charged state and one that disconnects due to environmental

causes. When the latter is detected, the Nomad 20 will

automatically resume charging to start charging the device

again. No extra work on your part is needed.

When operating in low light conditions, we recommend

pairing your solar panel with a portable power bank for the

best charging experience possible. A Goal Zero Flip power

bank (sold separately) will fit securely into the Nomad 20’s

integrated Flip charging dock and allow you to collect and

store a continuous stream of power to charge your device.

6 7

Q: Is the Nomad 20 waterproof?

A: The best answer: it’s weatherproof. We’ve gone to great

lengths to ruggedize the Nomad 20; including beefing up the

manufacturing process with advanced lamination techniques so

it’ll slough off rain and snow.

Q: Does the Nomad 20 have a built-in battery?

A: No. In order to make the Nomad 20 as lightweight as possible,

we chose to sell batteries as an optional accessory. You can

either plug your phone or device into the Nomad 20 to charge

up directly from the sun, or pair the panel with one of our power

banks to collect and store power for later. The Nomad 20 works

seamlessly with our line of ultra-portable Flip Power Banks,

versatile Sherpa Power Banks, or small Yeti Power Stations.

Q: Is this chainable with other Nomad panels?

A: Yes, but only on some Goal Zero Nomad Solar Panels. You can

plug the Charge Cable into the chaining ports on Nomad 20

Solar Panels and larger.

FREQUENTLY ASKED QUESTIONS

CHAINING

Chaining panels is a great way to collect more power from

the sun and recharge devices quicker. You can chain up to

150W of solar panels together. We recommend no more than

four in a chain (see the NOTE below).

1. Plug the 8mm Charge Cable into another Nomad Solar

Panel’s 8mm input.

2. Using the 8mm Charge Cable of the final panel, plug

into a Sherpa Power Bank or Goal Zero Yeti Portable

Power Station. You could also plug into the USB port on

the last panel to charge USB powered devices.

NOTE

After four solar panels are chained together, you might notice

something called line loss, which has to do with the loss of

voltages over long distances. The farther the power has to

travel through cables, from panel to panel, the more power you

will lose.

6 7

Q: Is the Nomad 20 waterproof?

A: The best answer: it’s weatherproof. We’ve gone to great

lengths to ruggedize the Nomad 20; including beefing up the

manufacturing process with advanced lamination techniques so

it’ll slough off rain and snow.

Q: Does the Nomad 20 have a built-in battery?

A: No. In order to make the Nomad 20 as lightweight as possible,

we chose to sell batteries as an optional accessory. You can

either plug your phone or device into the Nomad 20 to charge

up directly from the sun, or pair the panel with one of our power

banks to collect and store power for later. The Nomad 20 works

seamlessly with our line of ultra-portable Flip Power Banks,

versatile Sherpa Power Banks, or small Yeti Power Stations.

Q: Is this chainable with other Nomad panels?

A: Yes, but only on some Goal Zero Nomad Solar Panels. You can

plug the Charge Cable into the chaining ports on Nomad 20

Solar Panels and larger.

FREQUENTLY ASKED QUESTIONS

CHAINING

Chaining panels is a great way to collect more power from

the sun and recharge devices quicker. You can chain up to

150W of solar panels together. We recommend no more than

four in a chain (see the NOTE below).

1. Plug the 8mm Charge Cable into another Nomad Solar

Panel’s 8mm input.

2. Using the 8mm Charge Cable of the final panel, plug

into a Sherpa Power Bank or Goal Zero Yeti Portable

Power Station. You could also plug into the USB port on

the last panel to charge USB powered devices.

NOTE

After four solar panels are chained together, you might notice

something called line loss, which has to do with the loss of

voltages over long distances. The farther the power has to

travel through cables, from panel to panel, the more power you

will lose.

TECHNICALSPECIFICATIONS

Solar Panel:

Rated Power 20W

Open Circuit Voltage Voc 18-22V

Cell Type Monocrystalline

Ports:

8mm Port 14-22V, up to 1.3A (20W max)

USB Port 5V, up to 2.1A (10.5W max)

General:

Weight 2.28 lbs (1.03 kg)

Dimensions

(unfolded) 11.5 x 21.75 x 0.75 in

(29.2 x 55.3 x 1.9 cm)

Dimensions

(folded) 11.5 x 7.4 x 1.25 in

(29.2 x 19 x 3.2 cm)

Certs

Warranty 12 Months

Be sure to activate your warranty at goalzero.com/warranty

Nomad 20 Solar Panel

GOAL ZERO HEADQUARTERS

675 West 14600 South

Bluffdale, UT 84065

1-888-794-6250

Designed in the U.S.A.

Made in China

Nomad is a trademark of Goal Zero.

JG112619V1

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

Autres manuels pour Nomad 20

Table des matières

Autres manuels GOAL ZERO Panneau solaire

GOAL ZERO

GOAL ZERO NOMAD 5 Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 50 Manuel utilisateur

GOAL ZERO

GOAL ZERO Boulder 200 BC Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 100 Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 100 Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 7 Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 28 PLUS Manuel utilisateur

GOAL ZERO

GOAL ZERO Escape 30 Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 5 Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 14 plus Manuel utilisateur

GOAL ZERO

GOAL ZERO BOULDER 90 Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 7 Plus Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 7 Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 27M Manuel utilisateur

GOAL ZERO

GOAL ZERO Boulder90 Manuel utilisateur

GOAL ZERO

GOAL ZERO Boulder 200BC Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 50 Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 10 Manuel utilisateur

GOAL ZERO

GOAL ZERO BOULDER30 Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 50 Manuel utilisateur

GOAL ZERO

GOAL ZERO Boulder 200BC Manuel utilisateur

GOAL ZERO

GOAL ZERO Nomad 7 Plus Manuel utilisateur

GOAL ZERO

GOAL ZERO BOULDER 100BC Manuel utilisateur

GOAL ZERO

GOAL ZERO NOMAD 10 Manuel utilisateur

Manuels Panneau solaire populaires d'autres marques

Navitron

Navitron HFC-2 Manuel utilisateur

AXITEC

AXITEC 60-CELL Manuel utilisateur

thermital

thermital TSOL 20 N BLU Manuel utilisateur

AZO Digital

AZO Digital MPPT-3000 Manuel utilisateur

Clenergy

Clenergy PV-ezRack SolarTripod Manuel utilisateur

Beretta

Beretta SCF-20N Manuel utilisateur

moovo

moovo KSM001 Manuel du produit

solarwatt

solarwatt EasyIn 60M Series Manuel utilisateur

Solarland

Solarland Portable Series Manuel

Ubiquiti

Ubiquiti sunMAX Manuel utilisateur

Lippert

Lippert Furrion FSFP37MW-BL Manuel utilisateur

Sonnenkraft

Sonnenkraft GK5-HP Manuel utilisateur

REC

REC TwinPeak 2S Mono 72 Series Manuel utilisateur

Sunforce

Sunforce 50039 Manuel utilisateur

Flexsolar

Flexsolar C100 Mode d’emploi

Süd Solar

Süd Solar 03005 Manuel utilisateur

Kodak

Kodak SP21 Manuel utilisateur

Carmanah

Carmanah Go Power! Solar Flex GP-FLEX-30 Manuel utilisateur
