Introduction
Pleasereadtheseinstructionsandfollowthemcarefullyforthe
safe and economical use of your Combination boiler.
This boiler must have been installed by a competent person in
accordancewiththerulesinforceinthecountriesofdestination.
Once the pilot has been lit and the controls set, the boiler is
automatic in operation.
The Swift-flow combination boiler is able to provide room
heating as part of a central heating system and domestic hot
water direct from the cold water supply, without the need for
secondary storage.
The boiler can be fitted with one of two makes of clock, which
look like this:-
IMPORTANT NOTICE:
This boiler is for use only on G20 gas.
Gas Leak or Fault
Ifagasleakorfaultexistsorissuspected,turntheboileroffand
consult your local gas company or your local installation/
servicing company.
Domestic Hot Water Temperature
NOTE. Themainswatertemperatureinthewinterislowerthan
in the summer.
Thewatertemperaturecanbeincreasedorreducedbyadjusting
the flow rate at the hot water draw off tap.
Boilers Installed in Compartments
Iftheboiler has been fitted into acompartmentor cupboard, do
not obstruct the compartment air supply vents.
Do not use the compartment for storage.
Electrical Supply
WARNING. The boiler must be earthed.
The boiler must be connected to a 230V~50Hz permanent
supply.
Connection of the whole electrical system of the boiler and any
heatingsystemcontrolstotheelectricalsupply,mustbethrough
one common isolator.
Isolation should preferably be by a double pole switched fused
spurbox. The fused spur box should be readily accessible and
preferably adjacent to the appliance. It should be identified as
to its use.
Alternatively a fused 3A 3 pin plug and shuttered unswitched
socket may be used.
Thecoloursofthreecoreflexiblecableare,blue-neutral,brown
- live, green and yellow - earth.
As the markings on your plug may not correspond with these
colours continue as follows:-
The wire coloured blue must be connected to the terminal
marked “N” or “Black”.
The wire coloured brown must be connected to the terminal
marked “L” or “Red”.
The wire coloured green and yellow must be connected to the
terminal marked “E” or “Green” or the earth symbol .
PVC flexible cable having a conductor size of 0.75mm2(24/
0.20mm)mustbeusedwithintheboilercasingtoconnecttothe
boiler.
Electrical Supply Failure
The boiler will not work without an electrical supply.
Normaloperationoftheboilershouldresumewhentheelectrical
supply is restored.
Note. The boiler safety cutoff may have operated, please refer
to the following section to reset.
Reset any external controls, to resume normal operation of the
central heating.
Thedigitaltimer,hasalithiumbatterybackupandwillnot need
resetting.
Boiler Safety Cutoff Reset Button
Theboilerisfittedwithasafetycutoffdevicetopreventdamage
through overheating.
Should the main burner go out during a demand the red neon
on the Reset Button will light.
In certain circumstances the red neon light may not come on,
duetonosystemdemand. Itissuggestedthatahotwaterdraw
off tap be opened to create a demand, the neon should then
come on.
Allow the boiler and system to cool down waiting at least a
minimum of four minutes before pressing the Reset button.
If the problem persists, turn the boiler off and consult the local
gas company or your installation/ servicing company.
6509
Clock / Timer
Digital timer Electro / mechanical
clock / timer
Instructions for Use
