THANK YOU
We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of these bath
accessories. We strive to continually create quality products designed to enhance your home. Visit us online to
see our full line of products available for your home improvement needs. Thank you for choosing Glacier Bay!
USE AND CARE GUIDE
18 IN. TOWEL BAR
24 IN. TOWEL BAR
Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-434-5224
HOMEDEPOT.COM
REV.01YOW
Model # 20113-0101 20113-0204
20113-0201 20113-0127D
20113-0104 20113-0227D
2
Table of Contents
Safety Information....................................2
Warranty ...................................................2
Planning Installation ..............................3
Tools Required .......................................3
Hardware Included.................................3
Pre-Installation.........................................3
Package Contents ..................................4
Installation................................................5
Care and Cleaning.....................................6
Safety Information
Please read and understand this entire manual before
attempting to assemble, operate, or install the product.
Warranty
LIMITED LIFETIME WARRANTY
Glacier Bay products are manufactured with superior quality standards and workmanship and are backed by our
limited lifetime warranty. Glacier Bay products are warranted to the original consumer purchaser to be free of
defects in materials or workmanship. We will replace FREE OF CHARGE any product or parts that proves defective.
Simply, return the product / part to any of The Home Depot retail locations or call 1-855-HD Glacier (1-855-434-
5224) to receive the replacement item. Proof of purchase (original sales receipt) from the original consumer
purchaser must be made available for all Glacier Bay warranty claims.
This warranty excludes incidental/inconsequential damages and failures due to misuse, abuse, or normal wear and
tear. This warranty excludes all industrial, commercial & business usage, whose purchasers are hereby, extended
duration of warranty.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages, so the
rights that vary from state to state and province to province. Please see a store or contact 1-855-HD Glacier for
more details.
Service Parts .............................................6
MOC.TOPEDEMOH3
.ecnatsissarehtrufrof4225-434-558-1tcatnocesaelP
Pre-Installation
PLANNING INSTALLATION
Before beginning installation of these products, ensure all parts are present. Compare parts with the Package
Contents and Hardware Included lists. If any part is missing or damaged, do not attempt to install the products.
TOOLS REQUIRED
Safety
goggles
Phillips
screwdriver
Flathead
screwdriver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 4
Level Tape measure
Electric drill
Pencil
2
4
BB
CC
Wood screw
Mounting bracket
Plastic anchor
6"[152mm]
BA D
TEMPLATE
PLANTILLA
CALIBRE
C
18"[457mm]
24"[610mm]
DD Set screw 2
EE Installation template 1
AA BB CC DD EE
4
Pre-Installation (continued)
PACKAGE CONTENTS
Part Description Quantity
A2
1
2
D
B
C
Towel bar post (left)
18 in. Towel bar
Towel bar post (right)
24 in. Towel bar 1
C
B
A
A
C
D
MOC.TOPEDEMOH5
.ecnatsissarehtrufrof4225-434-558-1tcatnocesaelP
Installation
1 Marking the mounting location 2 Installing the mounting brackets
Drill 1/4 in. holes in the previously marked
locations.
□
3 Installing the product
Place the post (A, C) over the mounting
bracket (BB) and secure it with the set
screw (DD), as shown.
□
NOTE: The included template (EE) may be used to mark the
mounting locations for the towel bars: A and C for the 18
in. towel bar/ A and D for the 24 in.
BB
NOTE: When mounting the products to a wood wall, fasten
the mounting brackets (BB) to the wall using the wood
screws (AA). There will be no need for drilling or plastic
anchors (CC).
Push the plastic anchors (CC) flush into the dry wall.
□
Fasten the mounting bracket (BB) to the wall with
the wood screws (AA).
□
□Repeat this step as needed for each bath
accessory.
□
□
□
□
Remove the set screw (DD) from the base of the
product posts.
Place the product in the desired mounting
location, using a level to position it accordingly,
and use a pencil to lightly mark the outline of the
posts.
Center the mounting bracket (BB) within the
marked post locations, and mark where the
screw holes will be drilled.
Repeat this step as needed for each bath
accessory.
□Repeat this step for the remaining
post (A, C).
NOTE: Ensure the towel bar (B or D) is inserted prior to
securing the second post (A, C) to the mounting
bracket (BB).
15mm
BB AA
CC
BB
AA
DD
BB
DD
6
Service Parts
Part Description Part Number
Mounting hardware
(screw, bracket, and
plastic anchor)
Set screw
1
2
RP80216
RP50041
Care and Cleaning
□
□
□
Preserve the finish of the bath accessory using a non-abrasive wax.
When using non-abrasive cleaners, rinse off immediately when finished cleaning the bath accessory.
Do not use abrasive cleaners when cleaning this bath accessory.
*Towel bars and Posts are not available service parts.
1
2
2
1
Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-434-5224
HOMEDEPOT.COM
Retain this manual for future use.
GUÍA DE USO Y MANTENIMIENTO
TOALLERO DE 18 PLG (45,72 CM)
TOALLERO DE 24 PLG (60,96 CM)
¿Problemas, preguntas o piezas faltantes? Antes de regresar a la tienda,
llama al Servicio al Cliente de Glacier Bay
de Lunes a Viernes de 8 a.m. a 6 p.m., Hora Estándar del Este
1-855-434-5224
HOMEDEPOT.COM
GRACIAS
Agradecemos la confianza que has depositado en Glacier Bay al comprar estos accesorios de baño. Nos esforzamos por crear
continuamente productos de calidad diseñados para mejorar tu hogar.Visítanos en Inte rnet para ver nuestra línea completa de
productos disponibles para las necesidades de mejoras de tu hogar. ¡Gracias por elegir a Glacier Bay!
Modelo Núm.: 20113-0101 20113-0204
20113-0201 20113-0127D
20113-0104 20113-0227D
9
Tabla de Contenido
Información de Seguridad .......................9
Garantía ...................................................9
Planificación de la Instalación ..............10
Herramientas Necesarias .....................10
Herrajes Incluidos .................................10
Pre-instalación.........................................10
Contenido del Paquete...........................11
Instalación ................................................12
Cuidado y Limpieza ..................................13
Información de Seguridad
Lee y comprende este manual completo antes de
intentar ensamblar, operar o instalar el producto.
Garantía
Piezas de Repuesto ..................................13
GARANTÍA LIMITADA DE POR VIDA
Los productos de Glacier Bay están fabricados con normas y mano de obra de calidad superior y están respaldados
por nuestra garantía de por vida limitada. Glacier Bay garantiza al comprador consumidor original que sus productos
no presentan defectos materiales o de fabricación. Simplemente, devuelva el producto o pieza a
cualquiera de las tiendas minoristas de The Home Depot o llame al 1-855-HD Glacier (1-855-434-5224)
para recibir el artículo de reemplazo. El comprobante de compra (recibo de venta original) del comprador consumidor
original debe estar disponible para todos los reclamos de garantía de Glacier Bay.
Esta garantía excluye daños y fallos incidentales/consecuenciales debido al mal uso, abuso o desgaste normal por
el uso. Esta garantía excluye todos los usos industriales, comerciales y de negocios, a cuyos compradores se les
extiende en la presente una garantía limitada de cinco años a partir de la fecha de compra, con todos los otros
artículos de esta garantía que aplican excepto la duración de la garantía.
Algunos estados y provincias no permiten la exclusión o la limitación de los daños incidentales o consecuentes,
por lo tanto, las limitaciones y exclusiones anteriores podrían no aplicarse a su caso. Esta garantía le otorga derechos
tienda o llame al 1-855-HD Glacier para obtener más detalles.
MOC.TOPEDEMOH10
Para obtener asistencia, llama al 1-855-434-5224.
Pre-instalación
PLANIFICACIÓN DE LA INSTALACIÓN
Antes de comenzar la instalación de este producto, asegúrate de que no falta ninguna pieza. Compara las piezas con
la lista de Contenido del Paquete y Herrajes Incluidos. Si falta alguna pieza o está dañada, no intentes instalar el
producto.
HERRAMIENTAS NECESARIAS
Destornillador de
cabeza plana
HERRAJES INCLUIDOS
Pieza Descripción Cantidad
AA 4
Nivel Cinta métrica
Taladro eléctrico
Lápiz
2
4
BB
CC
Tornillo para madera
Soporte de montaje
Anclaje plástico
6"[152mm]
BA D
TEMPLATE
PLANTILLA
CALIBRE
C
18"[457mm]
24"[610mm]
DD Tornillo de fijación 2
EE Plantilla de instalación 1
AA BB CC DD EE
Gafas de
seguridad
Destornillador
Phillips
NOTA: No se muestra el tamaño real de los herrajes.
