Gigabyte S55U Manuel utilisateur

Contents

Connection

Establishing a Wired Internet Connection..................................................3

Establishing a Wireless Internet Connection............................................. 3

Connecting Bluetooth Devices...................................................................4

Using HDMI&CEC......................................................................................4

Connecting a Digital Audio System to Use eARC/ARC.............................5

Connecting an AV device, a PC or a Game Console with an HDMI

cable...................................................................................................... 6

Connecting USB Devices...........................................................................7

Game

Game Mode Settings................................................................................. 8

Game Assistant..........................................................................................9

Smart Functions

Getting Familiar with the Home Screen...................................................10

Using Voice Control................................................................................. 11

Media........................................................................................................12

Apps......................................................................................................... 16

Picture and Sound

Adjusting the Picture Quality....................................................................18

Adjusting the Sound Quality.................................................................... 21

Multi-screen

Screen Sharing........................................................................................ 24

Content Sharing....................................................................................... 24

Accessibility and System

Accessibility.............................................................................................. 26

Configuring Device Preferences Settings................................................ 26

Configuring Advanced System Settings...................................................28

Troubleshooting

Picture Issues...........................................................................................31

Sound Issues........................................................................................... 31

Network Issues.........................................................................................32

External Device Connection Issues......................................................... 32

Apps......................................................................................................... 33

Media Files...............................................................................................33

Voice Control Issues................................................................................34

Other Issues.............................................................................................34

Using the E-Manual

Launching the E-Manual.......................................................................... 36

Using the Buttons in the E-Manual..........................................................36

Connection

Establishing a Wired Internet Connection

Connecting to a wired (Ethernet) network

Press button to select icon to enter Network & Internet.

To get access to the Internet in a wired way, it is recommended to use

a modem or router that supports Dynamic Host Configuration Protocol

(DHCP). Modems and routers that support DHCP automatically provide the

IP address, subnet mask, gateway, and DNS, so you don't have to enter

them manually. Most home networks already have DHCP.

See the illustration below.

Establishing a Wireless Internet Connection

Connecting to a wireless network

Press button to select icon, and select Network & Internet > Wi-Fi

To connect to an available wireless network, make sure that you have the

wireless router’s SSID and password before attempting to connect.

To get access to the Internet in a wireless way:

1. Turn on your Wi-Fi.

2. The list of networks will display automatically.

3. Select a wireless network from the list, input the password.

4. If the network connection does not appear in the list, select See all to

display all the list, or select Add new network to input a Wi-Fi name,

select the type of security mode, and enter password.

Connecting Bluetooth Devices

Connecting a Bluetooth device

To pair a Bluetooth device, such as Bluetooth headphones, speakers,

keyboards, mouse or even moblie devices:

1. Before pairing your Bluetooth devices, make sure they're in pairing mode

and put devices within range of the monitor. To put your Bluetooth devices

in pairing mode, refer to the user manual of devices.

2. Press button to select icon, and select Remotes & Accessories

> Add accessory to put the monitor in pairing mode. A list of available

Bluetooth devices will be displayed.

3. Select the desired device from the list, then follow the onscreen

instructions. If you are prompted to enter a passcode, refer to the user

manual of the device. After pairing is completed, the device is connected

and is stored to the monitor.

Note:

• You need to unpair a paired device first if the maximum number of paired

devices was reached.

Listening to the monitor through Bluetooth devices

1. Pair the Bluetooth audio devices using the monitor’s Bluetooth function.

Refer to the user manual of your audio device such as Bluetooth speaker,

sound bar and headphones for detailed connection steps and usage.

2. Press button to select icon, select Sound > Audio Output, and

then select the Bluetooth option to listen to the audio through bluetooth

devices.

Note:

• Compatibility issues may occur depending on the Bluetooth device.

• The monitor and Bluetooth device may disconnect depending on the

distance between them.

Using HDMI&CEC

Use the monitor's remote to control external devices that are connected

to the monitor by an HDMI cable. The external devices need to support

HDMI&CEC function.

Connecting an external device through HDMI&CEC function

Press button to select icon, and select Inputs > HDMI control.

1. Set HDMI control to On.

2. Connect an HDMI&CEC compliant device to the monitor.

3. Turn on the connected external device. The device is automatically

connected to the monitor. After connection is finished, you can access the

menu of the connected device on your monitor screen using your monitor

remote and control the device.

Enabling device auto power off

Press button to select icon, and select Inputs > Device auto power

off.

Set to On to turn off CEC compatible external devices when the monitor is

turned off.

Enabling Display auto power on

Press button to select icon, and select Inputs > Display Auto Power

On.

Set to On to turn on the monitor when CEC compatible external devices is

turned on.

Note:

• HDMI cables must be used to connect HDMI&CEC compatible devices to

your monitor.

• The HDMI&CEC feature of the connected device must be turned on.

• If you connect an HDMI device that is not HDMI&CEC compatible, all the

HDMI&CEC control features do not work.

• Depending on the connected HDMI device, the HDMI&CEC control

feature may not work.

• The HDMI&CEC feature are supported One Touch Play, Routing Control,

System Standby, Device OSD Name Transfer, Remote Control Pass

Through, Give Device Power Status, System Audio Control.

Connecting a Digital Audio System to Use eARC/

ARC

If you’d like to use the Enhanced Audio Return Channel (eARC) / the Audio

Return Channel (ARC) feature to have sound sent from the monitor back

down an HDMI cable to a digital sound system, you can connect to the

HDMI 3 (eARC) Port of your monitor.

By using this feature, you will also be able to control the sound system with

your monitor remote instead of using multiple remotes for each device.

After the connection:

1. Power on the sound system.

2. Press button to select icon, and select Sound > Audio Output >

eARC/ARC. If the device supports eARC function, first select Sound >

eARC to set it to On.

Note:

• It works only when the monitor is connected to the audio receiver that

supports the eARC/ARC function.

• If the device has an Input Selector feature then make sure to change it to

monitor.

• When this port is used as the eARC/ARC function, it can be used as

signal input when a DVD is connected to amplifier and the amplifier is

connected to the monitor at the same time. (Some amplifiers may not

support series connection.)

Connecting an AV device, a PC or a Game Console

with an HDMI cable

You can connect an AV device, a PC or a Game Console with an HDMI

cable.

After the connection:

1. Power on the device.

2. Press button on your remote, select the corresponding HDMI as the

input source.

Note:

• Only HDMI 3 / 4 Port supports HDMI 2.1, If you'd like to use UHD @120Hz

Timing, first select Menu > HDMI Format > Enhanced format

• Refer to the "Multilingual Installation Guide" for more connection

information.

• Some devices such as DVD player require HDMI signal to be set to

output in the device's settings. Please consult your device user manual for

instructions.

• If there is no sound from your monitor, change the device's audio settings.

Connecting USB Devices

Connect the USB devices such as hard drives, USB sticks and digital

cameras for browsing photos, listening to music.

• Support the USB disk 4G, 8G, 16G, 32G, 64G, 128G and other common

market size, and 8T hard drive is currently supported.

• Support format: NTFS, FAT32.

• Certain digital cameras may not be compatible with the monitor.

Game

Game Mode Settings

Enabling game mode

Press button to select icon, and select Picture > Picture Mode.

You can select the Game mode to optimize the monitor's settings for you to

enjoy a comfortable gaming experience with PC or game console connected

to the monitor.

In the Game Mode:

• Reducing input lag to make sure every press or click matches what's

happening on the screen;

• Improving responsiveness to produce very little motion blur;

• Processing YUV 4:4:4 format signals precisely to present accurate image

colors.

Note:

• This function may not be applicable in some input sources.

Enabling Low Input Lag Mode

Press button to select icon, and select Picture > Advanced Settings

> Low Input Lag Mode.

You can enjoy a smooth viewing experience with external devices connected

to the monitor when Low Input Lag Mode is turned on.

Note:

• When Game mode is selected, Low Input Lag will not be switched off

automatically.

Enabling FreeSync

Press button to select icon, and select Picture > Advanced Settings

> FreeSync.

You can enjoy a smooth viewing experience with external devices connected

to the monitor when FreeSync is turned on.

Note:

• Some functions above may not be applicable in some models/countries/

regions.

Game Assistant

Gaming Info

Under HDMI input, press button on your remote to select Gaming, and

select Gaming Info.

Configure the FPS (First Person Shooting) game related settings.

•Gaming Timer

Select countdown timer mode, including off, Count Up, Count Down. To

disable this function, set the setting to off.

•Refresh Rate

Enable or disable the real-time refresh rate setting.

•Info Location

Specify the location of the information to be shown on the screen.

Crosshair

Press button on your remote to select Gaming, and select Crosshair.

Select the desired crosshair type to suit your gaming environment. It makes

aiming much easier.

Display Alignment

Press button on your remote to select Gaming, and enable or disable

Display Alignment.

When the function is enabled, it displays the alignment lines on the four

sides of the screen, providing handy tool for you to line up multiple monitors

perfectly.

Autres manuels pour S55U

Table des matières

Autres manuels Gigabyte Moniteur

Gigabyte

Gigabyte AORUS FI32Q X Manuel utilisateur

Gigabyte

Gigabyte M27F A Manuel utilisateur

Gigabyte

Gigabyte Aorus FI27Q-P Manuel utilisateur

Gigabyte

Gigabyte G27QC Manuel utilisateur

Gigabyte

Gigabyte M27Q Manuel utilisateur

Gigabyte

Gigabyte AORUS FI32Q Manuel utilisateur

Gigabyte

Gigabyte M32Q Manuel utilisateur

Gigabyte

Gigabyte Aorus FI32U Manuel utilisateur

Gigabyte

Gigabyte AORUS F048U Manuel utilisateur

Gigabyte

Gigabyte M32UC Manuel utilisateur

Gigabyte

Gigabyte Aorus KD25F Manuel utilisateur

Gigabyte

Gigabyte GD-1503BP Manuel utilisateur

Gigabyte

Gigabyte M28U Manuel utilisateur

Gigabyte

Gigabyte G24F Manuel utilisateur

Gigabyte

Gigabyte S55U Manuel utilisateur

Gigabyte

Gigabyte GS27F Manuel utilisateur

Gigabyte

Gigabyte G34WQC Manuel utilisateur

Gigabyte

Gigabyte AORUS FI32Q X Manuel utilisateur

Gigabyte

Gigabyte AORUS FI27Q-X Manuel utilisateur

Gigabyte

Gigabyte G24F Manuel utilisateur

Gigabyte

Gigabyte Aorus FI27Q-P Manuel utilisateur

Gigabyte

Gigabyte G27Q Manuel utilisateur

Gigabyte

Gigabyte AORUS FI25F Manuel utilisateur

Gigabyte

Gigabyte G27FC Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
