Congratulations on the Purchase of Your New GIGABYTE Notebook Q2442 !

This quick start guide will help you to get started with setting up your notebook.

For more detailed information, please visit our website at www.gigabyte.com.

All specications are subject to the manufacturer's conguration at the time of shipping and

may change without prior notice, written or otherwise.

Using GIGABYTE Notebook for the First Time

Check Supplied Items

To install the battery please follow these steps:

Slide the battery into the slot until both latches (Shown as

) “click” into

place.

You may hear a “clicking” sound, once the battery is secure.

2Slide latch Ato the left to lock the battery in place.

AC Adapter Battery Pack Manual

Power Cord Driver CD Warranty Card

* The illustrations in this document may appear differently from your model.

English

POSH

1Connect the the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the left side of the notebook..

3Connect the power cord to the power outlet.

Switching on the Power :

After you turn on the Q2442 for the very first time, do not turn it off until the

operating system has been configured. Please note that the volume for the

audio will not function until Windows®Setup has completed.

Booting Up the Q2442 for the First Time :

Depending on your conguration, the Microsoft®Windows® Boot Screen will be

the rst screen that you will see as the notebook starts up. Follow the on-screen

prompts and instructions and enter your personal information to complete the

setup of the Windows®Operating System.

English

Your GIGABYTE Notebook Tour

POSH

1 2 43 5

Top View

Left View

1Built-In Microphone

2Webcam

3LCD Display

4Keyboard

5TouchPad

6LED Indicators 

7Super POSH Button

8Power Button

Power Status LED

Wireless Lan Status LED

HDD Status LED

Battery Status LED

1DC-in Jack

2LAN (RJ-45) Port

3External Moniter (VGA) Port

4HDMI Port

5USB3.0 Port

English

Base View & Front View

Right View

2 4 531

K/B

1USB2.0 Port

2Headphone Jack

3Microphone Jack

4Optical Disc Drive

5Kensington Lock Slot

1Battery Bay

2Memory, CPU compartment

3HDD Compartment

4Multi Card Reader 

5Speakers

6-in-1 Card Reader Supports :

● Secure Digital (SD)

● SDXC

● SDHC

● Memory Stick (MS)

● Multi Media Card (MMC)

● Memory Stick PRO (MS PRO)

English

The keyboard has a numeric keypad for easy numeric data input. Pressing the Fn +

NumLk keys turns on/off the numeric keypad. It also features function keys to allow you

to change operational features instantly. The function keys (Ecs,F1~F11) will act as hot

keys when pressed while the Fn key is held down.

Hotkey Function Description

Fn+Esc Bluetooth Enable/Disable Bluetooth

Fn+F1 Sleep Mode

Enter Suspend Mode.

Fn+F2 Silent Mode Enable/Disable Silent mode

(Power Management)

Fn+F3 Mute Toggle Mute On/Off.

Fn+F4 Display Toggle Changes Display Mode: LCD-only, CRT/HDMI-only

and simultaneous LCD&CRT/HDMI

Fn+F5 Volume Down Decrease the speaker volume.

Fn+F6 Volume Up Increase the speaker volume.

Fn+F7 Brightness Down Decrease the brightness level.

Fn+F8 Brightness Up Increase the brightness level.

Fn+F9 Touchpad Toggle Enable/Disable Touchpad

Fn+F10 WLAN Toggle Enable/Disable WLAN

Fn+F11 Webcam Toggle Enable/Disable the CCD camera

Hotkeys

English

6GIGABYTE Smart Recovery

● System Recovery (Restore your Q2442 operating system) :

The hard drive of the Q2442 has a hidden partition that contains a full backup image of

the operating system that can be used to recover the system in the event that something

happens to the operating system.

CAUTION:

If the hard drive is removed or the partition deleted, the recover options will no longer

be available and a recovery service will be needed.

● Launch System Recovery :

The system recover feature is part of the Notebook installation and it ships preset from the

factory. The options menu allows you to launch the Windows®recovery tool to reinstall the

operating system to factory defaults.

● Below will briey describe how to launch the recovery tool and to get the recovery started.

1.Turn off or restart the Notebook.

2.Turn the Notebook on and press and hold the F9 key to launch the tool.

3.The recovery window will open and give you the option

to "Recovery" in the toolbar. You will be prompted if

you want to recovery. Click on "Recovery" to begin the

repair if you do.

4.The "Recovering" window willopen and begin the

recovery.

5.Once it is complete, you will be prompted to reboot the

Notebook.

English

Super POSH Introduction

Super POSH is an integrated AP which has great benefit for system. It includes “Super

Power” “Super OSD” “Super Speed” and “Super HDD.”

● Super Power:

Super Power provides an integrated page for user to control power management.

It could increase battery life and effective of you.

A.Mode:

There would be 4 Mode for selection. Description as below:

Mode Icon Description

Power saving

Decrease system performance to provide more

battery time.

Normal

Balance system performance.

Highperformance

Provide system best performance.

Dynamic switch

Switch “Power saving” & “Normal mode”

automatically when battery mode, and auto switch

“High performance” mode when plug-in.

* Super Power always keeps status.

English

B.Information:

Super Power display some power information of system.

Items Description

Battery

LifeTime

Show battery discharge time.

CPU

Show CPU loading.

Battery

Percentage

Show the percentage of battery.

There will also be a status bar:

Color Status

red 0~10

orange 11~30

Blue 31~100

Power

Status

Show Current Power Status from AC or Battery icons.

Battery mode

Plug-in and Charging

Plug-in and Full

AC only

Warning:

If the percentage of battery was under 10%, there will pop a warning window

on task icon.

English

● Super OSD (on screen display) :

Super OSD provide several styles and locations selection of OSD and also could get

the current status of OSD from status bar.

Super OSD function as follow: The function depends on the denition.

Function Preview

Bluetooth

Silent mode

Mute(only speaker)

Volume

Brightness

Touchpad

Wireless

Webcam

Caps Lock

Num Lock
