SERVICE MANUAL Gfp 255 C

July 15, 2015

Table of Content

Page

1. Part li t ……………………………………………………….. 3-5

2. Exploded Drawing

View 1 - Frame and Stand…………………………………. 6

View 2 - Left Side Frame……………………………….….. 7

View 3 - Right ide frame………………………...……..... 8

View 4 - Stand………..…………………………………… 9

View 5 - Upper Rewind Hou ing…………..……………... 10

3. Wiring Diagram…….. ……………………………………………. 11

CORRESPONDENCE: SHIPPING: Service Part

Graphic Fini hing Partner LLC Graphic Fini hing Partner LLC Smooth Fini h LLC

PO Box 1097 13878 Park Steed Drive Don Bahr

Maryland Height , MO. 63043 Earth City, MO. 63045 455 Bo al Way

800-986-2005 Lavonia,, GA.30553

ale @gfpartner llc.com 770-235-9374

www.gfpartner llc.com info@ moothfini h.net

July 15, 2015

DRAWING PART VIEW

NUMBER NUMBER DESCRIPTION NUMBER STOCK ITEM

01 55C-1 Front cross member 1

02 55C-2

Bottom nip roller 1

YES

03 55C-3

Top nip roller 1

YES

04 55C-4

dler bar 1

05 55C-5

Linkage pressure adjustment shaft 1

06 55C-6

Rear cross member 1

07 TH-24 Hand protection rubber cover 1

08 DH-8 Hand wheel 1

YES

10 TH-18 Bearing sleeve 1

YES

11 DH-101 Print hold down bolt 1 YES

12 55C-155 Print hold down bar 1

YES

13 55C-11 Left side cover 2

14 TH-41 Pressure-regulating bearing seat

2,3

YES

15 TH-40 Pressure-regulating locating shaft

2,3

YES

16 TH-39 Pressure-regulating support seat

2,3

YES

17 TH-16 Angle gear

2,3

YES

18 TH-04 Stopper

2,3

YES

19 TH-07 Rewind tube bearing

2,3

YES

20 DH-48 Emergency switch

2,3

YES

21 55C-19 Drive Motor

YES

22 55C-121 Left side frame

23 TH-115 Photoelectric sensor

YES

24 TH-150 Leveling feet

YES

25 TH-85 Wiring terminal

YES

26 55C-24

Capacitor

ncluded with motor

27 55C-25

Motor sprocket

YES

28 55C-26

Nip roller sprocket

YES

DRAWING

PART VIEW

NUMBER NUMBER DESCRIPTION NUMBER STOCK ITEM

29 55C-27 Chain 2

YES

30 55C-28

Switch 3

YES

31 C-17

Knob 3

YES

32 55C-30 On lamp 3

YES

33 55C-122 Right side frame 3

34 TH-99 Potentiometer 3

35 TH-98 Power switch 3

YES

36 C-20 Wave filter 3

37 C-21 Power cord 3

38 TH-94 Fuse ( 1 amp 5 x 20mm) 3

YES

39 C-22 Tightner 3

40 55C-38 Aviation plug 3

41 TH-87 Speed control board 3

YES

42 55C-40 Photocell eye control board 3

YES

43 55C-123 110V transformer 3

44 55C-124 110V transformer 3

45 TH-111 Pedal switch 3

YES

46 55C-43 Right side cover 3

47 55C-125 Left stand side frame 4

48 55C-45 Stand cross member 4

49 TH-47 Stand locking screw 4

YES

50 55C-126 Right stand side frame 4

51 55C-51 Cloth tray 4

52 55C-52

Velcro straps 4

53 55C-53

Caster 4

54 55C-54

Caster with brake 4

55 55C-127

Left supply roll bracket 4 YES

56 55C-46 Lower supply shaft

57 C-30

Brake pad

58 TH-03

Film core adaptor/brake

YES

DRAWING

PART VIEW

NUMBER NUMBER DESCRIPTION NUMBER STOCK ITEM

59 55C-128

Right supply roll bracket 4

YES

60 55C-129

Right rewind housing 5

61 55C-130

Damping positioning tube

62 55C-131

Roller compressed spring

63 55C-132

Friction disc (1)

64 55C-133

Friction plate (1)

65 55C-134

Sprocket wheel link plate

66 55C-135

Small chain sprocket

67 55C-136

Composite bearing

68 55C-137

Left locking inner sleeve

69 55C-138

Damping adjustment shaft

70 55C-139

Right locking inner sleeve

71 55C-140

Right locking outer sleeve

72 55C-141

Left supporting plate

73 55C-142

Left rewind housing

74 55C-143

Damping adjustment shaft

75 55C-144

Right support plate

76 55C-145

Friction Disc (2)

77 55C-146

Friction plate (2)

78 55C-147

Large chain sprocket

79 55C-148

Rewind chain

80 55C-149

Compression spring positioning sleeve

81 55C-150

Damping positioning tube (2)

82 55C-62

Brake adjustment knob

83 55C-151

Shaft pressing sleeve

84 55C-152

Left shaft end cover

85 55C-153

Quick grip shaft

86 55C-55

Cardboard rewind tube

87 55C-154

Right shaft end cover

88 55C-156 Quick Grip shaft assembly

View 1- Frame and tand

–

Left ide frame

View 3 –Right ide frame

View 4 – Stand

View 5 – Upper Rewind hou ing
