German pool GIC-BS28B2 Manuel utilisateur

GIC-BS28B2-M-08-(1)

BUILT-IN INDUCTION COOKER

在使用之前請詳細閱讀「使用說明書」及「保用條例」，並妥為保存。

Please read these instructions and warranty information

carefully before use and keep them handy for future reference.

嵌入式電磁爐

GIC-BS28B2

P.2

目錄 TABLE OF CONTENTS

安裝說明 INSTALLATION INSTRUCTIONSP.3

產品結構 PRODUCT STRUCTURE P.4

操作說明OPERATING INSTRUCTIONSP.5



鍋具 COOKWAREP.7

安全注意事項SAFETY CAUTIONSP.8

清潔與保養CARE & MAINTENANCEP.8

常見故障及處理 TROUBLESHOOTING P.9

技術規格TECHNICAL SPECIFICATIONSP.10

保用條款WARRANTY TERMS & CONDITIONSP.11

P.3

安裝說明 INSTALLATION INSTRUCTIONS

安裝前注意 Notice

﹣嵌入式電磁爐周圍不應有任何障礙物阻擋機身，以免影響電磁爐的散熱效能

There should not be any obstacles surrounding the unit

﹣請確保電源插頭設在方便接插的地方，並必須接上地線

Make sure power plug is accessible after installation. Power outlet must be earthed

安裝時，注意機身底部以下必須預留不少於

25cm高的空間排風。

For ventilation purposes, there should be no less than

25 cm high empty space under the unit body.

機身底部進出風口不能設在封閉的空間裡，必須

保持與不同空間的空氣連接，並儘量與房間裡的

空氣保持一定程度的連接。

Air vent under the unit must be well circulated. Circulation

between space under the unit and room atmosphere

should be present.

依據機身尺寸*，在廚櫃檯面開孔。

According to cooker’s dimensions*, make a

cutout hole on the cabinet/counter top.

安裝程序 Procedures

將隨機的耐油橡膠貼於玻璃支架底部的黏

貼處，然後將機身嵌入櫃中。

Attach the supplied rubber tape to the bottom

part of the unit body, and then place unit

through the cutout hole.

插上電源，安裝完畢。

Connect power and cooker is ready to use.

①

25cm

②

③

櫃臺臺面

注意:安裝時必須確保後排氣口高於臺面，使

之能正常出風(如上圖所示)。

Notes: When the induction cooker is installed, the

exhaust outlet must be put ONTO the kitchen work-

top, so that it can exhaust successfully. Please refer

to the above pictures.

*參考開孔尺寸(mm)

Suggested cutout (mm) 670 (W) X 360 (D)

P.4

產品結構 PRODUCT STRUCTURE

操作面板 Control Panel

Venting Outlet

Cook-Top Panel

Control Panel

Rubber Seal

Air Inlet

Main On/Off Switch

Power Cord

1. 快速加熱鍵Turbo Key

2 & 8. 定時顯示Timer Display

3 & 9. 定時鍵Timer Key

4 & 10.火力段位指示燈Power Indicator Light

5 & 11. 面板餘溫指示Residual Heat Indicator

6 & 12. 火力調節鍵Power Adjustment Key

7 & 13. 電源開關鍵Power On / Off Switch

14. 鎖定鍵Lock Key

P.5

操作說明 OPERATING INSTRUCTIONS

將電源插頭插入插座，先按機身上“總電源開

關”，再按“電源開關鍵”，電磁爐進入待機狀

態，風扇轉動3秒後自動停止，此時電源開關掣右

方LED指示燈閃爍。

加熱狀態：

 電磁爐通電後，將鍋具放置在微晶玻璃板加

 熱區域中央，按“＋”或“－”鍵，電磁爐

 開始加熱，此時預設火力檔位為第3檔，如

 不放鍋或鍋具不合適，火力指示燈會繼續閃

 爍，電磁爐蜂鳴器有“嗶嗶”響聲，兩分鐘

 後自動關機。

定時/取消狀態：

 電磁爐加熱運行時，按“定時/取消”鍵，電子

 顯示管顯示“30”並閃爍。按“＋”或“－”鍵

 調節定時時間，電子顯示管顯示所設定的時間

 並閃爍，當設定操作完畢20秒後電子顯示管由

 閃爍轉為常亮，此時操作確定。再次按“定

 時/取消”鍵，定時取消，電子顯示管將不顯示

 任何內容。定時範圍為1－99(分鐘)，調整單

 位為1分鐘。

鎖定狀態：

 按“鎖定”鍵，界面控制被鎖定，此時其他操

 作無效。再次按“鎖定”鍵約3秒，界面控制

 被打開，操作如常。

Put the power plug into the socket. Switch on the “Main

On/Off switch”, then press the “Power On/Off switch”.

The induction cooker enters standby mode. The fan will

operate for 3 seconds and then stop. The LED on the

“Power On/Off” switch will ash.

Heat-Up Mode:

After connecting the induction cooker to power

supply, put the cooking pot onto the centre part of

the cook-top. Press “+” or “-“ key. The induction

cooker will start heating up. The cooker is preset at

power level 3. If the pot is not appropriate, the power

indicator will continue to ash and a “beep” sound

will be heard. The cooker will be switched off

automatically after 2 minutes.

Timer Mode:

When the induction cooker is heating up, press

“Timer” key, the digital display will show 30

and ash. Press ”+” or “-“ key to adjust the time. The

digital timer display will show the time set and ash.

20 seconds after time-setting, the digital display will

change from ashing to lighting up. The operation is

conrmed. Press “Timer/Cancellation” key again and

the time set will be cancelled. The digital display

will have no display. The time setting range is 1-99

(minutes). The unit of adjustment is 1 minute.

Key Lock Mode:

Press the “Lock” key. All controls will be locked.

Press “Lock” for 3 seconds. All keys will be

re-activated.

P.6

Sharing Mode:

When two hobs are used simultaneously, the

induction cooker will be in sharing mode. Priority

will be given to hob started rst. The total combined

rating for 2 hobs is limited at 2800 W.

Turbo Heating (For left hob only):

When the cooker is in general heating mode, press

“Turbo” key to switch to turbo heating. The “FF”

signal will appear on the digital display. Cooking hob

will be automatically switched to power level 5 after

5 minutes. When two hobs are operated

simultaneously, press “Turbo” to set the left hob at

Turbo mode while shutting off the right hob. Press

any key (including buttons for the right hob) during

turbo heating will cancel the turbo function.

分享加熱功能：

 當兩個爐頭同時使用時，電磁爐處於功率分享狀

 態。當對電磁爐進行火力調節時，會以當前操作

 爐頭優先分配。兩爐頭總功率上限為2800W。

 快速加熱(此功能僅限左爐頭使用)：

 電磁爐處於一般加熱狀態時，按“快速加

 熱”鍵，爐頭由一般加熱轉為快速加熱，該鍵

 右方顯示“FF”。快速加熱狀態持續5分鐘後自

 動轉為第5段火力。在兩爐同時使用時，左爐

 開啟快速加熱，右爐即自動停止工作。在快速

 加熱狀態下按其他功能鍵(包括右爐按鍵)，快

 速加熱狀態即被取消。

操作說明 OPERATING INSTRUCTIONS

P.7

鍋具 COOKWARE

請使用德國寶電磁爐專用或認可之鍋具，盡量不

要選用其他代替品，以免性能受影響。

適用的各類鍋具

﹣材質:

 鐵、鑄鐵或導磁不銹鋼

﹣形狀:

 底部直徑12cm以上之平底鍋。鍋具底部直

 徑不宜超過25cm，鍋具加上食物的重量不

 宜超過6kg

不適用的各類鍋具

-材質:

 非鐵質金屬、陶瓷、玻璃及以鋁、銅為底的

 鍋具

-形狀:

 底部凹凸差距過大的，底部直徑小於8cm

磁性不銹鋼壺鐵製煎鍋磁性不銹鋼鍋鐵製彩色鍋磁性鐵製琺瑯壺鐵板/鑄鍋

鋁製水壺耐熱玻璃鍋陶瓷鍋底部凹凸不平鍋底附腳鍋底直徑過小

Please use only German Pool authorized cookware

or cookware recommended by us. Any unauthorized

cookware may affect induction cooker’s heating capacity

and quality.

Appropriate Cookware

﹣Material:

Metal, ferromagnetic stainless steel or cast iron

﹣Shape:

Flat bottom with a diameter of 12 cm or more.

Cookware bottom diameter should not exceed 25 cm

and must not weight over 6 kg (with food)

Inappropriate Cookware

﹣Material:

Non-metallic, non-ferromagnetic, ceramic, glass,

aluminum or brass

﹣Shape:

Bottom not at or too bumpy, or bottom diameter

smaller than 8 cm

Ferromagnetic

Stainless Steel

Water Pot

Metal Frying Pan Ferromagnetic

Stainless Steel

Cooking Pot

Metal Saucepan Ferromagnetic

Metal Water Pot

Cast Iron Grilling

Pan

Aluminum

Water Pot

Glass Pot Ceramic Pot Pot With Non-Flat/

Curved Bottom

Pot With

Bumpers

Pot Bottom

Too Small

P.8

﹣請單獨使用13A以上的插座，切勿使用萬用插座

 或與其他電器共用插座。

﹣適用於本機的電源線路的截面應不小於2.0mm�。

﹣請勿用水直接沖洗電磁爐，以免破壞電器絕緣性能。

﹣請勿於排氣口及吸氣口插入鐵絲、金屬等物件，以

 免發生觸電危險。

﹣切勿讓鍋具猛烈撞擊玻璃面板。

﹣電磁爐水平放置後，側面及背面距離牆壁必須預

 留最少10cm或以上，切勿堵塞出風口、將爐身

 鑲嵌或密封。

﹣請勿在煤氣爐、煤油爐等熱源附近使用電磁爐。

﹣請勿將鐵片或其他鐵磁性材料直接放在玻璃面板

 上加熱，避免因高溫而產生灼傷危險。

﹣空鍋具請勿加熱過久，以免發生危險，鍋具溫度過

 高時，電磁爐會自動停止加熱。

﹣切勿加熱罐頭等密封的東西，否則會因罐頭內氣

 體受熱膨脹導致爆炸。

﹣不使用電磁爐時，請將電源插頭由插座拔出，或將

 機底電源開關關閉。

— Single 13 A power jack must be used. Do not share

power jack with other appliances.

— The power cable should not be less than 2.0 mm�.

— Do not apply water directly on to induction cooker.

— Do not insert any wire or metal objects through air

inlet or venting outlet of the induction cooker.

— Please avoid collision between cook-top panel

and cookware.

— A distance of at least 10 cm between the wall and

the sides of induction cooker must be reserved for

venting purposes.

— Do not place or use induction cooker near any heat source.

— Do not heat up any metal plate or other magnetic

objects on the cook-top panel.

-— Do not heat empty cookware for an extended time.

Overheating of cookware will cause damages and injuries.

— Do not heat up un-opened cans on the cook-top. It may

cause explosion.

— When induction cooker is not in use, unplug the power cord

or turn off the Main On/Off switch.

安全注意事項 SAFETY CAUTIONS

﹣清潔前必須先拔下電源插頭。

﹣任何污垢必須即時清理。

﹣必須待爐面完全冷卻才進行清潔。

﹣清潔面板時，先以扭乾的濕布擦拭；若仍未能

 除掉污漬，可用中性去污粉或洗潔精擦拭，然

 後再用濕布擦拭即可。



﹣清潔電磁爐機身時，先用柔軟濕布擦拭﹔若有

 油污難以清除時，用中性洗潔精擦拭後再用濕

 布擦拭乾淨。

﹣切勿用水直接沖洗或將機身浸入水中清洗。

﹣切勿使用堅硬之刷子刷洗爐面。

﹣切勿使用有機溶劑或苯等化學藥品擦拭電磁爐。

— Power plug must be disconnected before cleaning.

— Any stain or deposit on the cook-top surface must be

cleaned off immediately before re-using.

— Cleaning must be done when cook-top surface has

completely cooled down.

— If stain is minimal, wipe off with a dry cloth. If stain

remains, clean cook-top with a moist sponge (soaked

with mild soap) and then wipe again with a clean cloth.

— To clean the body of induction cooker, wipe with a

soft clean cloth. If stain remains, clean with a moist

sponge (soaked with mild soap) and then wipe with a

clean cloth.

— Do not immerse induction cooker into water.

— Do not clean cook-top with any rough cloth or abrasive tool.

— Do not use organic solvents or any cleaning products

that contain chemicals such as Benzene.

清潔與保養 CARE & MAINTENANCE

P.9

常見故障及處理 TROUBLESHOOTING

使用中如發現電磁爐操作上有問題，在送回本公司維修前請先依照下表進行檢查﹕

When you run into any problem operating this product, use the table below to troubleshoot the problem.

If the problem persists, contact our Repairs & Customer Service Centre.

故障現象Phenomenon 檢查要點Check-upItems 處理方法Solution

接通電源，按機底電源總開關，

再按“開/關”鍵，電磁爐無反應。

Power is connected and Main On/Off

switch is turned on, but the induction

cooker does not respond when the

On/Off button is pressed.

•是否停電?

•府上的自動開關或

保險絲是否發生短路?

•插頭是否脫落或接觸不良?

•Is there a power

shortage in your area?

•Is there a short circuit in the

power source of your home?

•Is the power plug too loose

or not connected well?

•電源恢復後再使用。

•檢查短路原因，排險後才使用。

•插牢或更換插孔後使用。

•Try again after power supply resumes.

•Find out the cause of short circuit

and eliminate it before switching on

the cooker again.

•Re-connect the plug or replace the

power jack.

蜂鳴器斷續鳴響且鍋具不加熱。

Buzzer beeps continuously and pan is

not heated.

•鍋具不適應?

•鍋具位置不合適?

•Is the pan not suitable for

induction cooking?

•Is the pan positioned properly?

•使用電磁爐適用之鍋具。

•將鍋具放置在電磁爐面板中心。

•Use an appropriate pan.

•Position the pan in the centre of

cook-top.

在正常運作時停止加熱。

Induction cooker stops heating

during normal operations.

•是否空鍋或溫度過高?

•吸氣口或排氣口是否堵塞?

•室溫太高?

•Is the pan empty or cooking

temperature too high?

•Are the air inlet and outlet

being blocked?

•Is the surrounding temperature

too high?

•防止乾燒，降溫後自動繼續。

•待機件冷卻後才使用，並注意

保持內部通風。

•室溫降低後才使用。

•Avoid operating cooker with an

empty pan. Let cooker cool down

before switching it on again.

•Remove obstruction from the vent.

Let induction cooker cool down and

try again.

•Try again after the room cools down.

保溫失控。

Temperature uctuates.

•鍋底是否凹凸不平?

•Is pan bottom not at?

•更換平底鍋具後使用。

•Replace pan with a at-bottomed one.

*以上為常見故障的判斷與檢查，只供用戶作參考之用。

*如遇故障切勿自行修理，避免發生危險及對機件造成損害，請立即找專業技術人員或聯絡本公司作出適當維修。

* Above table enlists the most common problems regarding the operations of the product and their possible causes as well as suggested solutions.

It is strictly for users’ reference only.

* Should there be any product malfunction or breakdown, DO NOT repair it yourself. Contact our Repairs & Customer Service Centre or consult a

licensed technician immediately.

P.10

型號ModelGIC-BS28B(2)

電壓Voltage/頻率Frequency 220 V / 50 Hz

總功率Rated Power 2800 W

左爐最大功率Left Hob Maximum 2600 W

右爐最大功率Right Hob Maximum 1600 W

尺寸 Dimensions (H) 75 (W) 700 (D) 390 mm

淨重Net Weight 6.6 kg

總重量Gross Weight 7.2 kg

產品規格及設計如有變更﹐恕不另行通知。

Specications are subject to change without prior notice.

中英文版本如有出入，一概以中文版為準。

If there is any inconsistency or ambiguity between the English version and the Chinese version,

the Chinese version shall prevail.

技術規格 TECHNICAL SPECIFICATIONS

Table des matières

Autres manuels German pool Cuisinière

German pool

German pool GIC-128DB Manuel utilisateur

German pool

German pool GIC-BD30B Manuel utilisateur

German pool

German pool GIC-BS22BR Manuel utilisateur

German pool

German pool GIC-CS28B-S Manuel utilisateur

German pool

German pool GIC-228DB Manuel utilisateur

German pool

German pool GIC-BS26B Manuel utilisateur

German pool

German pool GIC-KD28T Manuel utilisateur

German pool

German pool DIC-148DB Manuel utilisateur

German pool

German pool GIC-QD70B Manuel utilisateur

German pool

German pool CKY-285 Manuel utilisateur

German pool

German pool GIC-GD28T-S Manuel utilisateur

German pool

German pool GIH-DD28B Manuel utilisateur

German pool

German pool GIC-BS26B Manuel utilisateur

German pool

German pool GIC-HS25T Manuel utilisateur

German pool

German pool GIC-MS28T Manuel utilisateur

German pool

German pool GIC-BD28B Manuel utilisateur

German pool

German pool GIH-PD50B-SC Manuel utilisateur

German pool

German pool GIC-GD28T Manuel utilisateur

German pool

German pool DIH-146DB Manuel utilisateur

German pool

German pool GIC-128DB-SC Manuel utilisateur

German pool

German pool GIC-U19 Manuel utilisateur

German pool

German pool GID-AS28T Manuel utilisateur

German pool

German pool GIC-BS26B-S Manuel utilisateur

German pool

German pool CKY-281 Manuel utilisateur

Manuels Cuisinière populaires d'autres marques

Modena

Modena FC 7645 SGM Manuel du propriétaire

Electrolux

Electrolux Insight EKG6049 Manuel utilisateur

Stanley

Stanley Donard 60 Manuel utilisateur

Bartscher

Bartscher 201TC Manuel utilisateur

Parkinson Cowan

Parkinson Cowan 50 GR/BU Manuel utilisateur

Siemens

Siemens HK9P00020U Manuel utilisateur

Creda

Creda S150E Mode d’emploi

Creda

Creda HB48309 Manuel utilisateur

Bosch

Bosch HCE743220F Manuel utilisateur

Tricity Bendix

Tricity Bendix SE545P Manuel utilisateur

NEFF

NEFF E1461A2/01 Manuel utilisateur

Zanussi

Zanussi ZCM 700 X Manuel utilisateur

Smeg

Smeg SNL61MA9 Manuel utilisateur

RiverGrille

RiverGrille TF2002501-RG Manuel utilisateur

Vollrath

Vollrath 69504F Manuel utilisateur

Tricity Bendix

Tricity Bendix CSIE500 Manuel utilisateur

AEG

AEG Competence 5731 V Manuel utilisateur

Euromaid

Euromaid ES60 Manuel utilisateur
