Quick Start Guide
Quick Start Guide
The Vision of Security
Thank you for purchasing GV-Storage System V2. This guide is designed to assist the new user in
getting immediate results from the GV-Storage System V2.
GV-Storage System V2
© 2015 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the
written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is accurate.
GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no
responsibility for errors or omissions. No liability is assumed for incidental or consequential
damages arising from the use of the information or products contained herein. Features and
specifications are subject to change without notice.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: +886-2-8797-8377
Fax: +886-2-8797-8335
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV series products are
trademarks of GeoVision, Inc. Windows and Windows 7 are registered trademarks of
Microsoft Corporation.
March 2015
i
Contents
Contents .................................................................................................................................................. i
1. Introduction....................................................................................................................................... 1
1.1 Compatible GeoVision Products.............................................................................................. 1
1.2 Packing List ............................................................................................................................. 2
1.3 Before You Begin .................................................................................................................... 3
1.4 Usage Notice........................................................................................................................... 4
1.5 Front View & Rear View ..........................................................................................................7
2. Installation....................................................................................................................................... 10
2.1 Install on a Network............................................................................................................... 10
2.2 Turn on the Power................................................................................................................. 11
2.3 Log in..................................................................................................................................... 12
2.4 Create a RAID Volume.......................................................................................................... 13
2.4.1 Use “Quick Installation” ........................................................................................... 14
2.4.2 Create an independent volume for each host......................................................... 17
2.5 Configure Initiator on the Host............................................................................................... 20
3. Accessing Video Recordings........................................................................................................ 24
4. Tools for GV-Storage System V2 .................................................................................................. 26
1. Introduction
This guide is designed to assist the new user in getting immediate results from the GV-
Storage System V2. For advanced information on how to use the GV-Storage System V2,
please refer to GV-Storage System V2 User’s Manual.
1.1 Compatible GeoVision Products
GV-Storage System V2 can work in conjunction with these GeoVision products to save data:
1
1.2 Packing List
GV-Storage System V2:
•GV-Storage System V2
•HDD Tray x 24
•Power Cord x 2
•RS-232 Cable
(For UPS, phone jack to DB9 male).
•Rail Kit
•Keys, Screws for Drives and Rail Kit (packet)
•Quick Start Guide
•Software Disk
GV-Expansion System:
•GV-Expansion System
•HDD Tray x 24
•Power Cord x 2
•Mini-SAS Cable
•Rail Kit
•Keys, Screws for Drives and Rail Kit (packet)
•Quick Start Guide
•Software Disk
2
1.3 Before You Begin
Before starting, prepare the following items:
•A management computer with a Gigabit Ethernet network interface card (recommended)
on the same network as the GV-Storage System V2.
•Connection cables:
。 GV-Storage System V2: CAT 5e, or CAT 6 (recommended) network cables for one
management port and six iSCSI data ports.
。 GV-Expansion System: SAS cables (supplied)
•Prepare a storage system configuration plan by the network administrator. The plan
should include network information for the management port and six iSCSI data ports. If
using static IP addresses, please prepare a list of the static IP addresses, the subnet
mask, and the default gateway.
•A Gigabit Layer 2 or Layer 3 managed stackable switch.
•CHAP security information, including CHAP username and secret (optional).
3
1.4 Usage Notice
Please pay attention to the following notice when you use the storage system.
•Recommended Hard Drive
For system efficiency, we recommend the following enterprise level hard disk drives. Avoid
using desktop level or green HDD which may affect system efficiency.
•WD RE series
•Seagate Constellation ES.3 series
•HGST Ultrastar series
•Before Powering On and Off
Shut down GV-Storage System V2 first and then GV-Expansion System if they are
connected.
For powering on, be sure to turn on GV-Expansion System first and then GV-Storage System
V2 in case of wrong data detection.
•Default IP Addresses Setting
Port Type Field Default Setting
ID admin
Password 0000
IP 192.168.0.199
Subnet Mask 255.255.252.0
HTTP port 80
Management Port
HTTPS port 443
Port 1 192.168.1.1
Port 2 192.168.2.1
Port 3 192.168.3.1
Port 4 192.168.4.1
Port 5 192.168.5.1
Port 6 192.168.6.1
Subnet Mask 255.255.255.0
iSCSI Port
iSCSI port 3260
•VD (Virtual Disk) Restriction
Don’t assign the same VD to more than one host for recording usage; otherwise you
may suffer data lost or corrupt.
4
•Initiator Node Name Restriction
The Initiator node name only accepts lower-case letters. Use lower-case letters for Host
name in the storage system (select Volume Configuration / Virtual Disks / Options ▼/
Attach LUN / Allowed Hosts). Otherwise you cannot establish the connection between the
storage system and the host.
Î
•Replacing Hard Drives
To prevent the storage system from RAID failure, select Volume Configuration / RAID
Groups / Options ▼/ Deactivate to deactivate the RAID group on the Web UI when
replacing the hard drive. Then re-activate the RAID group after you finish replacing the hard
drive.
5
•Order of Hard Drive Slots
Remember the order of hard drive slots on the storage system. When you see the “Failure”
health status on Web UI (select Volume Configuration / Physical Disks) or the warning
message from Email notification, remove the failed hard drive in the correct slot.
If you remove the hard drive in the wrong slot, you could suffer data loss.
•Maximum Recording Channels
The maximum number of channels supported by GV-Storage System V2 varies with the
resolution, as listed below. It’s highly suggested to keep the total bitrates under 2700 Mbps
for better recording performance.
Video Streaming Complex Scenes Normal Scenes
Resolution Frame rate Bitrate Record
Channels Bitrate Record
Channels
1.3 MP 30 fps 5 Mbps 534 ch 1.73 Mbps 1560 ch
2 MP 30 fps 7 Mbps 385 ch 3.86 Mbps 699 ch
3 MP 20 fps 10.48 Mbps 257 ch 3.38 Mbps 798 ch
4 MP 15 fps 11.65 Mbps 231 ch 8.93 Mbps 302 ch
5 MP 10 fps 16.48 Mbps 163 ch 3.16 Mbps 854 ch
6
1.5 Front View & Rear View
Front View
Figure 2-1
No. Name Description
1 Power Button
and Power LED Blue: Power ON.
Off: Power OFF.
2 Mute Button Press to mute the alarm.
3 IP Reset Button Reset the IP address of the management port to default settings:
192.168.0.199.
4 Status LED: Red: System failure.
Off: System OK.
5 Access LED This indicates host connectivity, not the hard drive activity.
Blink: There is host activity (data I/O or management).
OFF: There is no host activity.
6~9 HDD Groups HDD Groups A, B, C, D
Note: IP Reset button is not available in GV-Expansion System.
7
