USER MANUAL
Genmitsu Z4 Portable High-Speed
Galvo Laser Engraver & Cutter
Contents
Welcome
Safety Guideline
Product Details and Accessories
Product Structure Accessories
Product Parameters
Function Introduction
Electric Stand Introduction
Reminder about the Vent
Resources Download and Software Setup
APP Download & Introduction
Resources Download and Software Setup
Custom PC Engraving Software Introduction
FAQ
01
02
04
05
06
07
08
09
09
10
16
20
25
Welcome
Thank you for purchasing the Z4 Portable High-Speed Galvo Laser Engraver & Cutter from SainSmart.
Included in your package will be a USB Drive, that contains:
● User Manuals
● Windows USB Driver
● Sample Engraving Files
Help, support and ideas can be found on our Facebook Group. (SainSmart Genmitsu CNC Users Group,
https://www.facebook.com/groups/SainSmart.GenmitsuCNC)
You can visit our resource center at https://docs.sainsmart.com/ to learn more about CNC & Laser Engraving.
01
Safety Guideline
Laser processing is risky and users should carefully consider whether the object is suitable for laser processing.
You must be at least 13 years old to operate the laser engraver.
Direct exposure to the laser beam can cause severe bums and eye damage. Ensure that you are weaning
proper laser safety goggles when working in the vicinity of the laser equipment .
Processing objects and emissions shall comply with local laws and regulations.
It is strictly forbidden to place any irrelevant total or diffuse reflecting objects in the equipment.
The equipment should be kept away from electrical equipment that is sensitive to electromagnetic interference,
otherwise it will cause interference.
When you focus the laser do so only on the lowest power setting.
Keep a fire extinguisher nearby since use of the laser may lead to an unexpected fire.
Never leave an operating laser unattended.
Fumes and smoke generated during the engraving / cutting process must be extracted from the room as some
can be poisonous : make sure there is a ventilated system to the outdoors.
Make sure the cutting area under the laser is metal or non-flammable.
Ensure that the room or area you are operating the laser in is sufficiently labeled to prevent someone from
unknowingly walking into an active work area .
Always exercise safety and caution when working with laser marking systems. Consider the listed
recommendations to minimize risk:
02
Safety Guideline
SainSmart does not accept any responsibility or liability for any use or misuse of the Laser.
1. Beware of the laser
After the laser is turned on, it is forbidden to aim at people, animals and flammable materials to avoid
skin burns and fire.
3. No entry
Keep your hands away from the machine when the machine is working to avoid injury.
2. Do not look directly at the light
The brightness of the laser is harmful to the eyes, please try not to look directly at the laser.
4. Turn off machine when not in use
Turn off the machine switch when the machine is not in use to avoid third-party operations.
Be sure to disconnect the power when cleaning, maintaining or servicing the laser equipment.
DO NOT stare at the bright and intense light appearing during the engraving process. Doing so can cause
serious eye damage.
Never use the laser except for the purpose intended.
Pay attention to
03
Product Details and Accessories
1. Front View 2. Rear View
3. Top View 4. Bottom View
Handle
Handle
Quick Action Button Type-C Port
DC Input
USB Port (for
Rotation Module)
Laser Unit Indicator
Laser Protective Shild
04
Product Structure Accessories
Power Supply (Rated for 12V 5A): Do not use any other Power Supply
Unit, this may damage your machine.
USB Drive: Contains drivers, engraving software for PC, user manual and video instruction.
USB Cable: Connect the computer and the machine.
Marker: Paint the engraving surface with marker or paints before engraving, and clean it when the job’s done.
Kraft Paper: Sample materials to test your laser engraver.
Magnet Protective UV Shield (optional):
Easy to remove and clean. The UV Magnet Shield attaches to your Laser Engraver when used in “Portable” Mode
without the stand. It is set to match the perfect focusing height. Simply place the machine on the surface of the
object you want to engrave.
Stand (optional): Set Laser Focal height with the adjustable stand making it easier to engraver objects of various
sizes.
Portable Charger (optional): Portability.
Rotary Attachment (optional): Add-ons to engrave cylindrical objects, additional USB cable is required.
Power Supply
Magnet Protective
UV Shield (optional)
Stand
(optional)
Portable Charger
(optional)
Rotary Attachment
(optional)
USB Drive USB Cable Marker Brush Kraft Paper
153mm
114mm
76mm
05
Product Parameters
Z4
High Strength Anodized Aluminum
Automatic Focusing
450nm Blue Laser
5W
Bluetooth 5.0 Dual Mode Adapter, Type-C Port for PC
Mobile: Android & iOS. Desktop: Windows & Mac OS
JPEG/BMP/GIF/PNG/JPG/XJ/PLT/DXF/HPGL
12V/5A, Portable Charger
0.89A(Standby) 2.2A(Engraving)
Forced Air Cooling
>10000H
5cm×5cm (1.97"×1.97")
0.05mm
600mm/s (1417"/min)
Paper, Wood, Bamboo, Cloth, Acrylic, Plastic, Leather, Bread, Fruit, Glass, Ceramic
Paper, Wood, Bamboo, Leather
Windows/IOS/MAC/Android
11.4×7.6×15.3cm (4.49"×2.99"×6.02")
37.5×22×16.5cm (14.76"×8.66"×6.5")
0.68KG
Model
Material
Laser Focus
Laser Head
Laser Power
Connecting Interfaces
Operating Systems
File Formats
Power Supply
Power Consumption
Cooling
Laser Service Time
Engraving Area
Engraving Accuracy
Engraving Speed
Engravable Materials
Cuttable Materials
Support OS
Laser Unit Size
Package Size
Machine Weight
06
Function Introduction
Quick Action Button Instructions:
Short press once to preview the Laser path. Press again to stop.
Long press once to engrave, long press again to cancel engraving.
During engraving, short press to stop engraving, short press again to continue.
07
Electric Stand Introduction
1. Place the laser unit onto the Laser Stand. To adjust the height of the stand to calibrate laser focus, follow the
instructions below.
2. Place the engraved object on the pad, then pull down the focusing rod, rotate the Knurled Screw, and adjust
the height of the stand. Let the focusing rod touch the surface of the object, tighten the Knurled Screw, and retract
the rod after the ranging is completed.
Mainframe
Lifting Frame
Fixed Focus Lever
Engraving Object
08
Knurled
Screw
