Genius TVGo DVB-D02 Manuel utilisateur
English
Chapter 1: Introduction
1.1 Package Contents
Upon receiving your TVGo DVB-D02, please make sure the following items are included in
the package.
zTVGo DVB-D02
zCD of Installation Software
zQuick Installation Guide
zUSB cable
zAntenna
zPAL to NTSC connector
zRemote control
1.2 System Requirements
zIBM PC or compatible
zIntel Pentium 4 2.0GB MHz / equivalent AMD Athlon ™ CPU or better processor
zOne available USB2.0 port.
zMinimum 256 MB memory of RAM or more
zMinimum 100 MB hard disk space available
z1024x768 graphic card, DirectX R 9.0c or above compatible graphic card or higher
zMicrosoft Windows XP HOME/PRO EDITION /XP 64bit
zCD-ROM drive
zHard Disk: 5400 RPM or above (7200 RPM preferred)
1
English
Chapter 2: Getting Started
2.1 Connect TVGo DVB-D02
To install the TVGo DVB-D02 into your computer, follow the steps below:
1. Connect the TV antenna cable to the
connector.
2. Connect the Device to PC USB Hub.
2.2 Device Driver Installation for Windows XP
1. Once you connect the TV box, just
follow the messages to finish the driver
installation.
2. Found new hardware window will pop
up on Windows XP desktop
automatically.
2
English
3. Click “Next” button to ignore the install
wizard. It will cancel automatically after
installation of a new device.
4. Choose “Install from a list or specific
location (Advanced). Click “Next”
button.
5. Check the “include the location in the
search” and type in “D:\Driver”, D: is
your CD-ROM Drive. Click “Next” to
install the device driver.
3
English
6. Click “Continue Anyway” button and
finish the installation.
7. Click “Finish” button.
4
English
2.3 Install the TVGo DVB-D02 utility software.
1. Click “Setup Utility” to begin the software
installation.
2. Click “Next” button to start the installation
3. Click “Next” button or choose setup folder
for installation.
5
English
4. Then click “Finish” to complete the
installation of TVGo DVB-D02 Box.
5. Click “OK” button to reboot the PC.
6
English
Chapter 3: Launch the Software
3.1 Running the TVGo DVB-D02 for the first time.
Click Start on Windows Taskbar, and then select Programs\TVGo DVB-D02
1. Click Start on Windows Taskbar, and then select Programs\ TVGo DVB-D02
2. Click the AP ” TVGo DVB-D02”
3. Then the scanning device will start.
7
English
For first time operation, you should complete the setting and scanning channel.
1. Although the TV tuner on your TVGo
DVB-DO2 is fixed, you have to set up
the country or region right the first time
you launch TVGo DVB-DO2. Click
“Next” button to continue.
2. Select your signal source, either analog
or digital. (This section shows step by
step to set up analog TV. Go to step 10 if
you select DVB-T as signal source)
3. Click “Next” button.
8
English
4. Select the correct region from the list
and click “Next” button.
5. Select the input signal source and click
“Finish”.
6. Click “OK” button to start channel
searching.
9
English
7. Available channel information will be
shown on the list.
8. Click the “OK” button to finish the auto
searching.
9. Click the “Finish” button.
10
