Genie GMC3CH Manuel utilisateur

INSTRUCTION

MANUAL

Micro-Cannon Vandal Resistant

Colour Camera

Product Code:- GMC3CH

•To avoid electrical shock, do not open the case of this product.

•Only use a regulated DC 12V Power supply to operate this product.

•Do not overload electrical outlets or extension cords; this can result in fire or

electric shock.

•Keep this product away from strong magnetic fields.

•Do not expose this product in direct sunlight or strong reflected rays.

•Refer servicing to qualified personnel only.

•Do not change or modify this product; the warranty will be void.

•1/3” Sony Super HAD CCD

•540 TVL

•Rugged Steel Construction

•IP66

1. Loosen the two locking screws①, using the supplied hex-head wrench and remove

the mounting base.

2. Attach the mounting base②to a suitable solid surface, such as a wall or ceiling. On

partitioning locate a wall stud or ceiling joist. Secure the mounting base using the

supplied screws③. Fit the camera④to the mounting base ②and fix in to position

using the two locking screws①, secure them with the hex-head wrench.

3. How to set the angle of view:

Loosen the two locking screws①, using the supplied hex-head wrench, and set the

desired camera angle by moving the camera right /left and up/down.

4. Connect the video connector (BNC) of the camera cable to the incoming video

cable. The other end of the video cable should be connected to a DVR or Monitor.

Plug the camera power connector (red DC jack) into the DC12V regulated power

supply. Switch on the power supply and the picture should will now be displayed on

the Monitor.

Precautions

Features

Installation

•DC 12V

If the camera does not function properly, check the following points before contacting

your distributor.

Troubles Remedies

No video Check the adapter and video cable

between the camera and a monitor

The image on the screen is dar

Check the brightness control on the

monitor

The image on the screen is dim Check if the lens is stained. If dirty, clean

it with a soft, clean cloth

The camera is not working properly and

the camera case is hot

Check if you have connected the

correct power adapter

The contrast on the screen is too wea

djust the contrast feature of the

monitor. The camera may be exposed to

strong light source, change the position

The image on the screen flickers

he camera facing

directly into the sun

or fluorescent light? Change the camera

Trouble Shooting

Note:

▪ Only use a regulated DC 12V adapter, such as the Genie PSUISM.

position

Picture rolls and jumps, scrambled


Incorrect

-hold control

setting on the

monitor

Picture smaller than screen Mains

current may be too low

•Image sensor 1/3” Sony Super HAD CCD, 752H x 582V

•Scanning system 2:1 interlace

•Horizontal resolution 540 TV lines

•Shutter speed Auto, Manual (1/50 to 1/100,000 sec)

•Sync. System Internal

•S/N ratio more than 48db (AGC off)

•Minimum illumination 0.1 Lux

•Video output Composite 1.0Vp-p @75 Ω

•AGC Auto

•White balance Auto

•Lens 3.0mm fixed lens

•Current consumption 120mA Max

•Power supply DC 12V

•Operating temperature -20°C to 50°C

•Dimensions 48 (W) x 37 (H) x 48 (D) mm

•Weight 80g

This warranty gives the original purchaser specific legal rights if our products do not

function because of a defect in materials or workmanship. We will repair or replace the

product, free of charge, for 3 years from original date of purchase.

This warranty does not cover defects caused by modification, misuse, deliberate or

accident damage or damage due to acts of god, or nature.

Specifications

Limited 3 Years Warranty

Edition : GN November 2010
