Genie WONVR216P5 Manuel utilisateur
Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference.
16 Channel H.265 Optimised
NVR with 2HDD Bays
WONVR216P5
ii
Intro Section
Please read this instruction carefully before operating the product and keep it for further
reference. All examples and pictures used here are for reference only.
The contents of this manual are subject to change without notice.
This device should be operated only from the type of power source indicated on the
marking label. The voltage of the power must be verified before use.
CAUTION:
• Please check the device and the accessories after getting the device. If there are any
damages, shortages or defects, please contact your dealer immediately.
Contents
iii
1.0 Introduction..........................................................................................................4
1.1 Product Features...........................................................................................4
1.2 Product Dimensions.....................................................................................4
1.3 Specification.................................................................................................5
2.0 HDD Installation...................................................................................................6
3.0 Rear Panel Instruction..........................................................................................7
4.0 Start Up and Shut Down......................................................................................8
5.0 Login ....................................................................................................................9
6.0 Configurations and Connections ........................................................................10
6.1 Network Configuration & Adding IP Camera...............................................10
7.0 UPnP .....................................................................................................................12
8.0 NAT.......................................................................................................................13
9.0 Manual Recording and Playback .........................................................................14
9.1 Manual Recording.........................................................................................14
9.2 Playback.......................................................................................................14
4
The Genie ‘Optimised’ WONVR216P5 network video recorder is a 16 channel PoE NVR with
resolution on every channel of up to 5MP. There are 16 PoE ports available, 2 bays for hard
drives and this versatile NVR fully supports up to 16 channels of simultaneous playback.
1.1 Product Features
• Supports 16 channel 5MP, 4MP, 3MP, 1080p, 960p and 720p IP input
• Adopt standard H.265 and H.264 high profile compression format to get high quality
video at much lower bit rate
• Intuitive and user friendly Graphic User Interface (GUI), Windows style operation by
mouse
• Multi-mode recording: Manual / Timer / Motion / Sensor
• Search : Time slice, time, event (Manual, sensor, motion), Tag search
• Express and flexible backup via USB, network etc.
• Pentaplex : Preview, Record, Playback, Backup and Remote Access
• DHCP, DDNS, PPPoE network protocol and CMS supported
• Remote control via IE or CMS : Preview, playback, backup, PTZ and configuration
• 1080p HD output, true high resolution display
• 16 channel simultaneous playback
• Authorisation management, log view and device status view
• Multi-user online simultaneously
• 16 PoE network ports supported by IPC direct connection to NVR, supports PoE power
supply
• Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
• Support NAT function and QR code scanning by mobile phone and iPad
• Powerful smart phone & iPad surveillance with iOS and Android OS
1.2 Product Dimensions
1.0 Introduction
380mm
268mm
52mm
Quick Start Guide 16 Channel H.265 Optimised NVR with 2HDD Bays
5
1.3 Specification
Model WONVR216P5
System OS Embedded Linux
Video
Network Input 16 CH IPC input
Network Access Format 5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps
Output HDMI x 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA x 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
Compression Standard H.265, H.264
Incoming Bandwidth 112Mbps
Outgoing Bandwidth 112Mbps
Audio
Network Input 16 channel IPC audio input
Two Way Audio RCA x 1
Audio Local Output RCA x 1
Record
Record Stream Dual stream recording
Resolution 5MP / 4MP / 3MP / 1080P / 960P / 720P @ 25 / 30fps
Mode Manual, Timer, Motion, Sensor
Mobile Device OS iOS, Android
Storage HDD SATA x 2, up to 8TB per HDD
Playback
Simultaneous Playback 16 channel max.
Search Time slice / Time / Event / Tag search
Smart Search Highlight colours to display the camera record in a certain period of time, different
colours refer to different record events
Function Play, Pause, FF, FB, Digital zoom, etc
Network
Interface RJ45 10 / 100 / 1000 Mbps x 1
Protocol TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
PoE Port RJ45 × 16
Record
Stream Dual stream recording
Resolution 5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps
Mode Manual, Timer, Motion, Sensor
Alarm
Mode Manual, Sensor, Motion, Exception
Input Support IPC alarm input
Output Support IPC alarm output
Triggering Record, Snap, Preset, E-mail, etc.
Remote
Monitoring
Immix Compatible with Immix via RTSP only (2-way audio not supported)
Sentinel Yes, Firmware 1.1.0 or later
Backup Local Backup USB stick, USB mobile HDD
Network Backup Yes
Port USB USB 2.0 × 2
Remote Controller Optional
Others
Power Supply DC48V
Consumption <15W (Without HDD)
Working Environment Temperature: -10°C – 50°C,
Humidity: 10% – 90%
Dimensions 380 × 268 × 52 mm
6
This series of the product supports 2 SATA hard drives. Please make sure that the device is
powered off before the installation. The pictures of the installation are for reference only.
1. Loosen the screws to open the cover.
2.0 HDD Installation
2. Place the HDD onto the bottom
of the machine.
3. Put the HDDs onto the bottom of the
device.
4. Connect the power and data
cables.
5. Turn over the machine and secure
the HDD with the screws.
6. Install back the cover and secure
it with the screws.
Note: Please check the inside structure of the device and make sure that the cables are
connected well before installing the cover back. Please format the HDD before using.
7
The interfaces of the rear panel are for reference only.
3.0 Rear Panel Instruction
Internet
DC48VUSB
LAN
2
1
4
35
6
7
8
9
10
11
12
13
14
15
16
PoE Ports IN
OUT
AUDIO
AUDIO
VGA
8
Startup
1. Connect the monitor and the power.
2. The device will boot and the power indicator will display blue.
3. A wizard window will pop up.
Shutdown
Click “Start” and then select “Shutdown” icon. This will bring up a shutdown window. The
device will shut down by clicking “OK” button. Then disconnect the power.
4.0 Start Up and Shut Down
9
The default username is admin and the default password is 123456. You must configure the
wizard if you start the NVR for the first time and you may change the password when you
configure the wizard for the first time. You can skip the settings wizard next time.
Click “Start” and select “Login”. This will take you to see a login box. Enter the default
username and password you set. Then you will see the live image.
5.0 Login
10
6.0 Configurations and Connections
6.1 Network Configuration & Adding IP Camera
After you finish adding IP cameras, you can see the live images through the monitor of the
NVR. The following will mainly introduce how to add the IP cameras via LAN/WAN.
LAN
1. Set the network of the NVR. Go to Start → Settings → Network → TCP/IP. Enter IP
address, subnet mask, gateway, etc. If using DHCP, please enable DHCP in both the
NVR and the router.
2. Go to Start → Settings → Network → Port. Enter HTTP port (the default value is 80),
server port (the default port is 6036).
3. The internal ethernet port is the port which connects all the PoE ports with the NVR
system. The PoE ports are available if the internal ethernet port is online. If it is offline,
all the PoE ports will be unavailable. The IP address and subnet mask of the internal
ethernet port can be changed to make the port in the same network segment with the
IP cameras which directly connect to the PoE ports of the NVR.
4. Go to Start → Settings → Camera → Add Camera. The NVR will automatically refresh the
cameras searched. The IPC which supports the Onvif protocol may be added manually.
If the IPC searched is not in the same local network as the NVR, you should select the
device and click to modify the IP address.
