Genie CCTV ZW2812 Manuel utilisateur

USER MANUAL

WDR TRUE DAY&NIGHT CAMERA

ZW2812

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

TXT

About WDR/BLC/3D DNR

Contents

Speciﬁcation

Safety Instruction

General Features

Set Up Menu

Special Menu

Menu Set Up

Exit

How to Install

Trouble Shooting

►Menu Set Up

►Lens Set Up

►Exposure

►White Bal.

►BLC

►SDNR

►Day & Night

►Image Adj.

►Special

►Camera Title

►Sync

►Motion Det.

►Privacy

►DIS

►COMM Adj.

►Language

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

TYT

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

TZT

0.00004Lux

\]W{}GsG

kjGhGpG}G

sOYU_TXYPG

{GkVuGjG

pjyGTGpyGjGmGyG

kG}

pw]]

zwljpmpjh{pvuz

1/3” SONY Vercal Double Density Interline CCD

NTSC=811(H) * 508/(V) / PAL=795(H) * 595(V)

NTSC=768(H) * 494(V) / PAL=752(H) * 582(V)

2:1 Interlace

Internal

Built-in (English, Japanese, Spanish)

52dB (x128)

WDR / BLC / OFF Selectable

560TV Lines

52dB (AGC OFF / Weight ON)

0.001 Lux (Sens-Up x128)→0.00004 Lux F1.2 (Sens-Up x256)

ATW / AWC / Manual / Outdoor / Indoor

AUTO

(NTSC=1/50sec ~ 1/100,000sec / PAL=1/60sec ~ 1/120,000sec) / MANUAL / A.FLK

AUTO (Selectable limit x2 ~ x256) / OFF

HIGH / LOW / OFF Selectable

OFF/ON (1~32 Level Adjustable)

ON/OFF (8 Zone, ALARM Output)

ON/OFF (8 Zone)

ON/OFF

ON/OFF (Level Adjustable)

COLOUR / BLACK & WHITE / AUTO / EXT

ON/OFF

ON (x10) / OFF

256 Point (Even 128 Point, ODD 128 Point)

RS-485 (Pelco-D Protocol) - Opon

DC 12V / AC 24V - Dual Voltage

CDS ON: 350mA

DC Auto Iris Varifocal Lens(2.8mm-12mm)

-20 ~ +50 Deg C. RH 95% Max.

-20 ~ +60 Deg C. RH 95% Max.

88mm(W) * 115mm(H) * 245mm(D)

X]WW

tvkls ~Y_XYG

Wide Dynamic Range

Camera OSD Control

{

Sensor

Total Pixels

Eﬀecve Pixels

Scanning System

Synchronisaon

O.S.D

Dynamic Range

Backlight

Resoluon

S/N (Y signal)

Min. Illuminaon

White Balance

Electronic Shuer Speed

Sens-Up

Gain Control

DNR

Moon Detecon

PRIVACY

MIRROR(H-REV)

FLIP(V-REV)

Freeze

SHARPNESS

D&N Selecon

DIS

Digital Zoom

Blemish Compensaon

Communicaon

Power Supply

Power Consumpon

Lens

Operang Temperature/Humidity

Storage Temperature/Humidity

Dimension

~G

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T[T

Precautions for use

ફPlease read this manual thoroughly before using the camera to become familiar with the correct

operational procedures.

Cautions When Using

ફDo not open the camera body and touch any electrical parts to avoid possible electric shocks.

ફDo not insert objects into the camera body to prevent fire hazards and electric shock.

ફDo not touch the camera with wet hands to avoid electric shock.

ફDo not disconnect the power cord from a power plug when still connected to the outlet.

ફAlways disconnect the power by removing the plug from the power socket.

ફIf the camera emits a burning smell, immediately disconnect it from the power source and report

the problem to your distributor.

Cautions When Install

ફOnly apply power after installation of the product.

ફDo not install the camera in a position facing directly at a strong light source.

ફDo not install or use the camera in areas of high humidity.

ફDo not install near any cooling or heating equipment.

ફDo not install the camera in dusty environments.

ફDo not install the camera in places where the camera is subjected to physical shocks.

ફThis products must be used with a regulated DC 12V or AC 24V adaptor for power.

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T\T

ሲWDR (Wide Dynamic Range)

The Genie INTUS range of camera uses very advanced WDR technology, which gives

clear images even where the scene is strongly backlit. Adjustable sensitivity.

ሲ560TV Lines

The combination of Sony Super HAD CCD image sensor and DNR DSP provides an

excellent resolution of 560 TV Lines.

ሲDay & Night

Depending on luminance levels the camera switches automatically between colour and

monochrome. The camera’s IR Cut-Filter gives perfect colour rendition during the day.

ሲIllumination

SDNR technology has solved the problem of ghosting and now displays clearer, superior

high resolution images even in extremely low light conditions.

ሲDisk Saving Effects

Advanced SDNR technology improves picture quality and saves hard drive space, as

less noise means much smaller ﬁle sizes - much smaller than standard CCTV camera

images.

ሲDNR DSP Chip

The DNR DSP chipset has various powerful functions that give superior high resolution

Day & Night images. It removes the camera noise and Sens-Up provides quality images

at very low luminance levels. The most advanced technology is combined on a single

DSP chipset, resulting in enhanced surveilance images.

ሲAdditional Functions

OSD - On Screen Display menu with Multi-Language support - 8 Countries

Privacy Masking - 8 Zones

Sens-Up - x256 Magniﬁcation

Digital Zoom - x10

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T]T

SET UP MENU DEFAULT SET MENU

ᐭLENS DC / MANUAL 2.8 - 12mm DC Auto IRIS Vari-Focal Lens

ᐮEXPOSURE SHUTTER :-

AGC: LOW

SENS-UP: OFF

SHUTTER

A.FLK

MANUAL(x256-120K)

ESC(BRIGHTNESS: Level Selectable)

AGC: OFF / LOW / HIGH

SENS-UP: OFF / AUTO(2-256 Level Selectable)

RETURN

ᐯWHITE BAL. ATW

INDOOR / OUTDOOR / AWC / ATW

MANUAL (RGAIN : Level Selectable,

BGain : Level Selectable)

ᐰBACKLIGHT OFF

ᐱSDNR ON ON (RANGE: 0 ~ 32 Level Selectable) / OFF

ᐲDAY & NIGHT AUTO

COLOUR / B/W / AUTO / EXTERNAL

DWELLTIME: 5 ~ 60SEC

DURATION TIME: SLOW / FAST

ᐳIMAGE ADJ.

FREEZE: OFF

V-REV: OFF

H-REV: OFF

DZOOM: OFF

SHARPNESS: ON

FREEZE: ON / OFF

V-REV: ON / OFF

H-REV :ON / OFF

DZOOM: ON / OFF(0 ~ 230 Level Selectable)

SHARPNESS: ON / OFF( I ~ 3 I Level Selectable)

RETURN

ᐴSPECIAL Refer to the next page

ࣜᐵ EXIT Save the SETUP Menu and exit

OSD

zo|{{lyGzwllk

~op{lGihs

isj

hnj

kuy

zluzT|w

zwljphs

lp{

lsj

h{~

opno

vmm

sv~

vmm

ሲzl{{punz

zGGGGGGvzkG

sGGGGGGU

OSD Control Board

WDR: LOW / MIDDLE / HIGH (Level 0-100)

BLC: TOP / BOTTOM / LEFT / RIGHT

LEVEL: LOW / MIDDLE / HIGH

HLC: MASK COLOUR (Level 0-220)

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T^T

SET UP MENU DEFAULT SET MENU

ᐭCAMERA TITLE OFF ON / OFF

ᐮSYNC INT INT / ----

ᐯMOTION DET. OFF

SENSITIVITY: AREA I

AREA MODE: OFF

SEL POS: L - TOP

X POS: Level Selectable

Y POS: Level Selectable

FILL ױSET

RETURN

ᐰPRIVACY OFF

AREA SEL: AREA I

AREA MODE: TOP / BOTTOM / LEFT / RIGHT

MASK COLOUR: GREEN / RED / BLUE

BLACK / WHITE / GREY

TRANSP. : Level Selectable

RETURN

ᐱDIS OFF ON / OFF

ᐲCOMM ADJ.

CAM ID: 0

BAUD RATE: 38400

PARITY: 8-N-1

RET PKT: ENABLE

DISP CAM ID: OFF

CAM ID: ID Selectable

BAUD RATE: 2400 / 4800 / 9600 / 19200

/ 38400 / 57600

PARITY: 8-N-1

RET PKT: ENABLE

DISP CAM ID: OFF

ᐳLANGUAGE ENGLISH

ᐴRESET - RETURNS TO FACTORY SETTINGS

ᐵRETURN - RETURNS TO THE SETUP MENU

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T_T

MAIN SETUP

LENS

EXPOSURE

WHITE BAL

BACKLIGHT

SDNR

DAY / NIGHT

IMAGE ADJ

SPECIAL

EXIT

ATW

OFF

AUTO

MAIN SETUP

LENS

EXPOSURE

WHITE BAL

BACKLIGHT

SDNR

DAY / NIGHT

IMAGE ADJ

SPECIAL

EXIT

ATW

OFF

AUTO

Menu items can be selected by using the OSD buttons of the camera.

I. Press the Set Up button.

úThe Set Up menu will be displayed on the monitor.

2. Move and select the required function using the Up and Down button.

úMove the arrow indicator Up or Down to select the desired feature by pressing the Up or

Down button.

WDR DAY & NIGHT COLOUR CAMERA WDR DAY & NIGHT COLOUR CAMERA

T`T

→DC : DC Auto IRIS Lens

This function controls the image brightness.

I. Move the arrow indicator to LENS using the Up and Down buttons on the Set Up menu screen.

2. Select the desired lens type by pressing the Left or Right button.

3. Changing menu settings using the Left or Right button.

ú

Available values or Status are displayed by pressing the Left or Right buttons.

Press the button until desired value / status is displayed.

4. After completing the setting move the arrow indicator to EXIT and press the SET button to EXIT

Move to available submenu by moving arrow to desired feature.

ú

Submenu is not available when this symbol is displayed ” -----”.

NOTE

قጺ

MAIN SETUP

LENS

EXPOSURE

WHITE BAL

BACKLIGHT

SDNR

DAY / NIGHT

IMAGE ADJ

SPECIAL

EXIT

ATW

OFF

AUTO
