Genie CCTV HDB2810IR Manuel utilisateur

Model: HDB2810IR

True Day/Night HD-SDI 2.1MP

Vandal Resistant

INTUS Night Vision Camera

User Guide

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 1 -

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER(OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER(OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER(OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

The lightning flash with an arrowhead symbol, within an equilateral

triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

INFORMATION - This equipment has been tested and found to comply with

limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.

These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

WARNING - Changes or modifications not expressly approved by the

manufacturer could void the user’s authority to operate the equipment.

This installation should be made by a qualified service person and

should conform to all local codes.

CAUTION: To prevent electric shock and risk of fire hazards.

Do NOT use power sources other than those specified.

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 2 -

Contents

Dimensions

Package Contents

Installation

General Features

Safety Instructions

Precautions

Specication

Troubleshooting

Menu Set Up

• OSD Control Keys

• Set Up Menu

• Menu Set Up

• Lens

• Exposure

• Back Light Compensation

• Day & Night

• White Balance

• DNR

• Image

• Motion Detection

• System

• Exit

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 3 -

90.5

302.7

170

100

Camera Dimensions

Package Contents

VIDEO TEST CABLE 1EA

INSTRUCTION MANUAL 1EA

SCREW TS T1, 4X25 4EA

GREEN TERMINAL 2P MAIL 1EA

L-WRENCH 4.0mm 1EA L-WRENCH 0.89mm 1EA

REC BASE ADAPTOR BRACKET 1EA

BOLT M5*15, HEXAGON SOCKET 4E

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 4 -

HEXAGON SOCKET SCREW 5X10, 4EA

TAPPING SCREW 4X25, 4EA

SDI Output Connector

Video Output Connector

Power Input Te rminal : AC24V/DC12V

Camera + Installation

Cable Connection

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 5 -

General Features

DNR (Digital Noise Reduction)

DNR technology utilises both an adaptive 2D filter which reduces noise in the brightness of the image

and an adaptive 3D filter which reduces noise caused by movement. The result is that the HD-SDI

camera supports Motion Adaptive DNR which removes noise and greatly reduces motion blur.

HD (High Definition) Surveillance

HD-SDI cameras provide superb surveillance images compared to a normal VGA camera.

WDR (Wide Dynamic Range)

WDR is a powerful and ultra advanced technology that captures cleaner and superior high resolution

images even where they appear dark due to a strong back light presence.

HLC (High Light Compensation)

High Light Compensation function is especially effective for reading car number plates at night time. Users

can select and define the required observation area for the target object and ignore strong highlight areas.

Illumination

With an incredible minimum illumination of 0.5 Lux, images can be captured even in extremely low light

conditions and signal noise is significantly reduced by the ultra advanced DNR (Digital Noise Reduction)

technology.

Privacy Zone

Privacy Zones can be set to block viewing for specific areas in the picture.

Additional Functions

OSD - On Screen Display menu

rivacy Masking - 32 zones, Sens-Up - x64 times, Digital Zoom - x8

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

DNR

Digital

Reduction

Noise

Illumination

Minimum

High Definition

DSP

3D-DNR

OSD

Privacy Zone

HLC

Wide Dynamic Range

Digital

WDR

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 6 -

Do not install the camera in

extreme temperature conditions.

Do not touch the front lens of the

camera.

Do not install or use the camera in an

environment where the humidity is high.

Do not install or use the camera in an

environment where the humidity is high.

Never keep the camera pointed

directly at strong light.

Do not expose the camera to

radioactivity.

Do not install the camera under

unstable lighting conditions.

Do not drop the camera or subject

it to physical shocks.

Only use the camera under conditions

where temperatures are between

-20°C and +50°C. Be especially careful to

provide ventilation when operating under

high temperatures.

This is one of the most important parts of

the camera. Be careful not to leave

fingerprints on the lens cover.

If exposed to radioactivity the CCD

will fail.

Severe lighting which changes or flickers

can cause the camera to work improperly.

NOTE

* If the camera is exposed to

spotlightorobjectreecting

strong light, smear or blooming

may occur.

* Please check that the power

satisesthenormalspecication

before connecting the camera.

Precautions

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 7 -

Safety Instructions

Precautions for use

Please handle this camera carefully

Thiscamerashouldbeinstalledbyaqualiedpersononly.

There are no user serviceable parts inside.

Do not disassemble this camera other than to make initial adjustments.

Only use a CE approved regulated DC12V, or AC24V power supply.

Useappropriatelowvoltagepowercabletopreventreorelectricalshock.

Please ensure that your installation area can support the weight of the camera.

Do not use strong or abrasive detergents when cleaning the camera.

Do not expose the camera to direct sun.

Do not install the camera in places where humidity is high.

Do not install near cooling or heating devices.

True Day/Night HD-SDI 2.1MP Vandal Resistant INTUS Night Vision Camera

- 8 -

OSD Control Keys

1. Control keys are used to access and operate the OSD menu.
