TMS200

200A Manual Transfer Switch

200A 250VAC

TTS Series

Switches

TMS200

The Generac TMS200 Manual Transfer Switch

Designed for ease of installation with the flexibility for multiple

application options

Flexibility and control for temporary generators

Integrated camlock functionality for mobile generator sources

Features

Image used for illustration purposes only.

Optional Features

=ExtEndEd Warranty availablE

=tHrEE-PHaSE vOltaGE COnFiGUratiOnS availablE

Generac products are designed to the following

standards:

UL1008,

UL508,

UL50,

CSA C22.2 No. 178

NEC 702

NEMA 250

Codes and Standards

=alUMinUM COnStrUCtiOn

=POWdEr-COatEd Ul tyPE / nEMa 3r EnClOSUrE

=StainlESS StEEl HardWarE

=intEGratEd CaMlOCK “QUiCK COnnECt” CaPability

=Utility POWEr Fail rElay alarM

=SlidEbar-tyPE MECHaniCal intErlOCK

=HinGEd “PadlOCKinG” dOOrS

=FiEld MOdiFiEd dOOr SWinG

=Ul1008 liStEd

Cabinet Specifications

Dimensions 20"W x 10"D x 36"H

Weight 53.8 lbs.

Construction

Single Chamber with Main Door

0.080 14GA Aluminum

UL Type / NEMA 3R Rated

Powder Coat Finish for Corrosion Resistance

UL Listed - Non-Automatic Transfer Switch & Suitable for Service Equipment

Stainless Steel Hardware

3-Point Latching System with Pad-Lockable Handle

Mounting Options Wall

H-frame

Installed Pre-wired alarm terminal strip

Electrical Specifications

Voltage/Phase/Amps

120/240 Single-Phase, 200A

120/208 3-Phase, 200A

120/240 3-Phase, 200A

Breaker Generac 200 amp Utility Breaker

Generac 200 amp Generator Breaker

Fault Current Rating 22k AIC Rated

200A Camlock Generator Connection

Single-Phase: Black L1, Red L2, White-Neutral, Green-Ground

3-Phase: Black L1, Red L2, Blue L3, White-Neutral, Green-Ground

Uses 4 CH E1016 Male Connectors

Mating Connector – CH E1016 Female

Input to Generator 350MCM - #6 AWG

Output to Site 350MCM - #6 AWG

Generator Annunciator Connector Deutsch DTM04-12PA-L012

Alarm Terminal Board

Generator Run Alarm

Generator Fail – Shutdown Alarm

Generator Fail – Non Shutdown Alarm

Low Fuel Alarm

Generator Theft Alarm

AC Utility Fail Alarm

Additional Components

Mounting Bracket Installation Mounting Bracket

Alarm Cable 100' length of multi-conductor cable

Enclosure Gasket Full Exterior x 2"W x 1/2"D Closed Cell Gasket

Shipped loose with switch

2 of 2

Application and Engineering Data

TMS200

Generac Power Systems, Inc. • S45 W29290 HWY. 59, Waukesha, WI 53189 • generac.com

Specification characteristics may change without notice. Dimensions and weights are for preliminary purposes only. Please consult a Generac Power Systems Industrial Dealer for detailed installation drawings.
