Generac Power Systems GenTran 6295 Feuille d'instructions

Installation Guidelines

For

Manual Transfer Switches

6295-6296 / 6378-6380

This manual should remain with the unit.

This manual must be used in conjunction

with the appropriate owner’s manual.

*NOT INTENDED FOR USE IN CRITICAL

LIFE SUPPORT APPLICATIONS.

*ONLY QUALIFIED ELECTRICIANS OR

CONTRACTORS SHOULD ATTEMPT

INSTALLATION!

ii Transfer Switch Installation Guidelines

Forward

Thank you for purchasing a Generac Manual Transfer Switch to safely connect a portable generator to your home or busi-

ness (single phase). Use where the main electrical panel is located indoors. This product is suitable for service entrance

equipment.

READ THIS MANUAL THOROUGHLY. This manual has been prepared to familiarize personnel involved with the

installation of transfer switches with the manufacturer’s installation requirements. Information and instructions con-

tained herein are not intended to replace or supersede, local, state, or national safety, electrical, and building codes

pertaining to such installations. Applicable laws, codes, and standards must always take precedence over the recom-

mendations contained herein. Always check with the local Authority Having Jurisdiction (AHJ) for the codes or stan-

dards that apply.

Only authorized dealers or qualified, competent installation contractors or electricians thoroughly familiar with applica-

ble codes, standards, and regulations should install this transfer switch. The installation must be in strict compliance

with all codes, standards, and regulations.

It is not intended that this manual be used by any unqualified person for the purpose of installing a transfer switch.

Installation, inspection, and testing of the system must be attempted only by competent, qualified electricians or instal-

lation contractors who are familiar with the equipment and with all installation codes and requirements.

It would be impossible to provide details for every installation configuration. For this reason, much of the information in

this manual is general in nature. Illustrations of typical installations are not intended to serve as specific installation

plans, but may be used in the planning and design process when considering the selection and purchase of a genera-

tor set for standby power applications. Always have the unit specific drawings and manuals on hand before beginning

any installation.

If a portable generator is used to power electrical load circuits normally powered by a utility

power source, it is required by code to install a transfer switch. The transfer switch must

effectively isolate the electrical system from the utility distribution system when the generator

is operating. Failure to isolate an electrical system by such means may result in damage to the

generator and may also result in injury or even death to utility power workers due to backfeed

of electrical energy.

After the transfer switch has been installed, do nothing that might render the installation in non-

compliance with codes, standards, and regulations. Every effort was made to ensure that the

information in this manual was both accurate and complete at the time it was released. However,

the manufacturer reserves the right to change, alter, or otherwise improve this product at any

time without notice.



WARNING!

California Proposition 65

Engine exhaust and some of its constituents are known to the state of California to cause cancer,

birth defects, and other reproductive harm.

WARNING!

California Proposition 65

This product contains or emits chemicals known to the state of California to cause cancer,

birth defects, and other reproductive harm.

Table of Contents

Transfer Switch Installation Guidelines iii

Section 1 Safety

1.1 Introduction .......................................................................................................................... 1

1.2 Safety Rules .......................................................................................................................... 1

1.3 General Hazards ................................................................................................................... 2

1.4 Electrical Hazards ................................................................................................................ 2

1.5 Fire Hazards .......................................................................................................................... 3

1.6 Explosion Hazards ............................................................................................................... 3

1.7 Standards Index ................................................................................................................... 3

Section 2 Installation

2.1 What is Included in this Carton: ......................................................................................... 4

2.2 Tools and Items Needed for Installation: ........................................................................... 4

2.3 Optional Items for Installation: ...........................................................................................4

2.4 Specifications ....................................................................................................................... 5

2.5 Planning Your Installation ................................................................................................... 5

2.6 Installation Procedure ......................................................................................................... 6

Section 3 Operation

3.1 Using Your Transfer Switch ................................................................................................ 9

Table of Contents

Forward ....................................................................................................................ii

Table of Contents

iv Transfer Switch Installation Guidelines

This page intentionally left blank.

Transfer Switch Installation Guidelines 1

Section 1 Safety

1.1 — Introduction

Thank you for purchasing a Generac Manual Transfer Switch to safely connect a portable generator to your home or busi-

ness (single phase only). Use where the main electrical panel is located indoors. This product is suitable for service entrance

equipment.

Read this manual thoroughly.If any portion is not understood, contact the nearest Authorized Generac Service

Dealer for clarification. Only authorized dealers or qualified, competent installation contractors or electricians thor-

oughly familiar with applicable codes, standards, and regulations should install this transfer switch.These individuals

are trained/qualified service technicians familiar with the control systems and available options, and also have full

access to drawings, publications, and other information required for a successful installation.The installation must be in

strict compliance with all codes, standards, and regulations.

1.2 — Safety Rules

Throughout this publication, DANGER, WARNING, CAUTION, and NOTE boxes are used to alert personnel to special

instructions about a particular operation that may be hazardous if performed incorrectly or carelessly. Observe them

carefully. They indicate:

Indicates a hazardous situation or action that, if not avoided, will result in death or serious

injury.

Indicates a hazardous situation or action that, if not avoided, could result in death or seri-

ous injury.

Indicates a hazardous situation or action that, if not avoided, could result in minor or mod-

erate injury.

NOTE: Notes provide additional information important to a procedure or component.

These safety warnings cannot eliminate the hazards they indicate. Observing safety precautions and strict compliance

with the special instructions while performing the action or service are essential to preventing accidents.

Four commonly used safety symbols accompany DANGER, WARNING, and CAUTION boxes and the type of informa-

tion each indicates:

Safety

2Transfer Switch Installation Guidelines

This symbol points out important safety information that, if not followed, could

endanger personnel and/or property.

This symbol represents the potential for an Explosion Hazard.

This symbol represents the potential for a Fire Hazard.

This symbol represents the potential for an Electrical Shock Hazard.

SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be

followed during installation of the transfer switch. The manufacturer suggests that these

safety rules be copied and posted in potential hazard areas. Safety should be stressed

to all installers, operators, potential operators, and service and repair technicians for

this equipment.

The manufacturer cannot anticipate every possible circumstance that might involve a hazard. The warnings in

this manual, and on tags and decals affixed to the unit, are not all-inclusive. If using a procedure, work method, or oper-

ating technique the manufacturer does not specifically recommend, ensure that it is safe for others. Also make sure the

procedure, work method, or operating technique used does not result in unsafe conditions.

1.3 — General Hazards

•For safety reasons, the manufacturer recommends that this equipment be installed, serviced, and repaired by an

Authorized Service Dealer or other competent, qualified electrician or installation technician who is familiar with

all applicable codes, standards, and regulations.

•Ensure that the transfer switch is installed, operated, and serviced in accordance with the manufacturer’s instruc-

tions and recommendations. Following installation, do nothing that might render the unit unsafe or in noncompli-

ance.

•Keep the area around the transfer switch clean and uncluttered. Remove any materials that could become haz-

ardous.

•When working on this equipment, remain alert at all times. Never work on the equipment when physically or men-

tally fatigued.

•Inspect the portable generator regularly, and promptly repair or replace any worn or damaged components using

only factory approved parts and procedures.

1.4 — Electrical Hazards

•All generators produce dangerous electrical voltages and can cause fatal electrical shock. Utility power delivers

extremely high and dangerous voltages to the transfer switch as well as the generator when it is in operation.

Avoid contact with bare wires, terminals and other connections. Ensure all covers, guards, and barriers are in

place, and that they are properly secured and/or locked before operation. If work must be done around an oper-

ating unit, stand on an insulated, dry surface to reduce potential shock hazard.

•Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet.

DANGEROUS ELECTRICAL SHOCK MAY RESULT.

•If it is necessary to stand on metal or concrete while installing, operating, servicing, or repairing this equipment,

lay down a dry wooden platform and cover with insulated mats before beginning.

•Verify that the portable generator is properly grounded.

•Wire gauge sizes of electrical wiring, cables, and cord sets must be adequate to handle the maximum electrical

current (ampacity) to which it will be subjected.

•Before installing or servicing equipment, verify that all power voltage supplies are positively turned off at their

sources. Failure to do so can result in hazardous and possibly fatal electrical shock.



Safety

Transfer Switch Installation Guidelines 3

•Connecting a portable generator to an electrical system normally supplied by an electric utility is by means of the

transfer switch so as to isolate the generator’s electric system from the electric utility distribution system when

the portable generator is operating. Failure to isolate the two electric system power sources from each other by

such means will result in damage to the portable generator and may also result in injury or death to utility power

workers due to backfeed of electrical energy.

•In case of accident caused by electric shock, immediately shut down the source of electrical power. If this is not

possible, attempt to free the victim from the live conductor. AVOID DIRECT CONTACT WITH THE VICTIM. Use

a nonconducting implement, such as a dry rope or board, to free the victim from the live conductor. If the victim is

unconscious, apply first aid and get immediate medical help.

•Do not wear jewelry when working on this equipment. Jewelry can conduct electricity resulting in electric shock,

or may get caught in moving parts resulting in injury.

1.5 — Fire Hazards

•Keep a fire extinguisher near the portable generator and transfer switch at all times. Keep the extinguisher prop-

erly charged and be familiar with its use. Direct any questions to the local fire department.

NOTE: DO NOT use any carbon tetra-chloride type fire extinguishers. These fire extinguishers emit toxic fumes

and the liquid can damage wiring insulation.

1.6 — Explosion Hazards

•Do not smoke around the generator. Immediately wipe up any fuel or oil spills. Ensure that no combustible mate-

rials are left in the generator compartment, or on or near the generator, as FIRE or EXPLOSION may result.

Keep the area surrounding the generator clean and free of debris.

•All types of fuels are potentially FLAMMABLE and/or EXPLOSIVE and must be handled with care. Inspect the

fuel system frequently and correct any leaks immediately. Be sure fuel supply lines are properly installed, purged,

and leak tested before placing the generator set into service.

1.7 — Standards Index

Be sure the transfer switch is in strict compliance with all applicable local, state, and federal laws, codes, and regula-

tions pertaining to such installations. Always use the current version or edition of the applicable law, code, and regula-

tion as it applies to the local jurisdiction.

Installation

4Transfer Switch Installation Guidelines

Section 2 Installation

2.1 — What is Included in this Carton:

• Manual Transfer Switch with wire harness, conduit, fittings and wire connectors (10 or 12)

• Wire Harness, pre-assembled

• 30 amp or 50 amp Aluminum Power Inlet Box (Models 6295-6296 only)

• 10 Foot Power Cord (Models 6295-6296 only)

• Flanged Inlet (inside models 6378 and 6380 only)

• Installation Manual and Warranty Registration card

2.2 — Tools and Items Needed for Installation:

• 5/16” nut driver, 2-1/8” hole saw (if flush mounting)

• Screwdrivers, straight blade and Phillips

• Electric drill, drill bits, wallboard saw

• Wire cutter/stripper

• Safety eye goggles

• Anchors and screws to mount transfer switch to wall/wallboard

• New, 2-pole 60 Amp or 100 Amp, 240V circuit breaker to install in main load center – same manufacturer as existing load center

• Insulated building wire (4-wire, also known as 3-wire plus ground) and conduit to connect between power inlet box and transfer switch

Compatible Circuit Breakers:

Siemens/Murray QT, QPH, HQP, QPF (GFCI), QPHF, QFP, QE, QEH, QAF (Arc Fault), QP (Surge Protector)

Cutler-Hammer Series BD, BR, BQ, GFC

Challenger Type A, C, HAGF

Square D Series HOM (Homeline)

GE Series THQL

2.3 — Optional Items for Installation:

• Arc-fault, GFCI or Surge protection circuit breakers. If Arc-fault, GFCI or Surge protection circuit breakers are used as the branch circuit pro-

tector in the main load center, they MUST be used in the manual transfer switch. You may be able to re-use your existing AFCI, GFCI and

Surge protection circuit breakers in the manual transfer switch. See list of compatible breakers.

• Wire, fittings and conduit to connect the Power Inlet Box to the transfer switch.

• White, green, black and red THHN or MTW wire, 10 AWG, 300V rated (if breaker configuration is modified or expanded.

• Switched Neutral Kit (Model 6297). If your portable generator has the neutral bonded to the frame of the generator AND 240V “full-power”

receptacle is GFCI protected, you will need to install this accessory with your transfer switch to avoid nuisance tripping of the GFCI breaker

on the generator.

NOTE: ON NEUTRAL BONDED GENERATORS: Some portable generators are intended for use on jobsites, and therefore are subject to

OSHA regulations for GFCI protection on all receptacles. These "contractor grade" generators have their neutral wire bonded to the

ground wire to pass OSHA inspection on job sites, and when connected to a transfer switch, this may cause nuisance tripping of the

generator GFCI breaker. If you’re using a neutral bonded generator to power a house or building through a transfer switch, then deter-

mine if the neutral bond wire on the generator can be disabled without voiding the warranty, preferably by a dealer or a qualified elec-

trician. NOTE: After this action, the generator will no longer pass OSHA inspection on job sites. Consult the manufacturer of your

generator to determine if the neutral bond can be removed. If it can be disabled, then no modifications to your transfer switch installa-

tion are needed. If the neutral bond cannot be disabled or voids the generator warranty, you must install a Switched Neutral Kit (SNK)

accessory with your transfer switch.

Installation

Transfer Switch Installation Guidelines 5

NOTE: If Ground Fault Circuit Interrupters (GFCI), Arc Fault Circuit Interrupters (AFCI), or Surge Protector Circuit Breakers were used

as the branch circuit protector in the main load center, they MUST be used in the transfer switch. GFCI and AFCI breakers require an

isolated neutral connected from the load to the GFCI or AFCI. The load neutral needs to be connected with a wire nut to a 3-6 foot piece

of white wire, run through the harness conduit to the transfer switch and connected to the “load neutral” lug or pigtail on the GFCI or

ACFI breaker. Because GFCI and AFCI circuit breakers can take up more than one space, the overall maximum number of circuits may

be reduced from the number shown. Not all brands of GFCI and Arc Fault breakers will fit.

2.5 — Planning Your Installation

1. Determine the appliances, circuits or equipment you want to operate with generator power during a power out-

age, such as:

2. Determine the amps required for each appliance by reading the label on the appliance. IMPORTANT: No appli-

ance should have an amperage rating that exceeds the GEN MAIN breaker rating in the transfer switch (See

Table 1). The total amperage of all circuits can exceed the generator rating, but not all circuits will be able to be

used concurrently.

3. Assign the circuit # in the load center to a circuit (A2, B2, etc.) in the transfer switch matching the size of the cir-

cuit breaker in the load center to the circuit breaker in the transfer switch. Once you’ve determined which cir-

cuits you want to connect and the appropriate amperage, you will be ready to begin installing your transfer

switch.

4. The location of your load center/electrical panel in your home or business will determine where the transfer

switch will be installed. Refer to Figure 1. In addition to the transfer switch, this kit includes a generator cord

and power inlet box. You will use the generator cord to connect your generator to the power inlet box outdoors.

Whether your load center is in a basement, interior room or garage, we recommend installing power inlet box

on the exterior of your house or building to avoid running generator cord through a door or window.

5. Determine where you will install the power inlet box on an exterior wall at least 5 feet from any openings

(doors, windows, vents, etc.). See Figure 1.

2.4 — Specifications

Model 6295 or 6378 6296 or 6380

# Circuits Provided on Transfer Switch 10 12

Maximum # Circuits 16 16

REQUIRED BREAKER FOR MAIN LOAD CENTER

(not included)

60 amp 2-pole 100 amp 2-pole

Utility Main Breaker 60 amp 2-pole 100 amp 2-pole

Generator Main Breaker 30 amp 2-pole 60 amp 2-pole

Breakers Provided with Unit 3 – 15 amp 1-pole

3 – 20 amp 1-pole

1 – 20 amp 2-pole

1 – 30 amp 2-pole

3 – 15 amp 1-pole

3 – 20 amp 1-pole

1 – 20 amp 2-pole

1 – 30 amp 2-pole

1 – 50 amp 2-pole

Maximum Generator Watts 7500 continuous / 9000 surge 12500 continuous / 18000 surge

Maximum Generator Amps 30 Amps 60 amps

Voltage 125/250 Volts 125/250 Volts

NEMA Type Enclosure 1 – Indoor Only 1 – Indoor Only

NEMA Configuration of Male Inlet in Power Inlet Box NEMA L14-30 CS-6365

Phase 11

Minimum Gauge Cord Size 10/4 AWG 6/4 AWG

❑Refrigerator/Freezer ❑Water Heater ❑Security System

❑Furnace Blower (gas/oil only) ❑Garage Door Opener ❑Sump Pump

❑TV / Radio ❑Microwave, Coffee Maker ❑Computer, Fax and Printer, Phone

❑Lighting ❑Well Pump ❑Aquarium

Installation

6Transfer Switch Installation Guidelines

Figure 1: TYPICAL INSTALLATION

2.6 — Installation Procedure

PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING TO UNPACK, ASSEMBLE, INSTALL,

OPERATE OR MAINTAIN THIS EQUIPMENT. HAZARDOUS VOLTAGES ARE PRESENT INSIDE TRANSFER SWITCH

ENCLOSURES THAT CAN CAUSE DEATH OR SEVERE PERSONAL INJURY. FOLLOW PROPER INSTALLATION,

OPERATION AND MAINTENANCE PROCEDURES TO AVOID HAZARDOUS VOLTAGES.

Table 1: CIRCUIT WORKSHEET

Circuit 6295 or 6378 6296 or 6380 Appliance(s) or Circuits

A1 NA 50A

B1 NA 50A

A2 30A 30A

B2 30A 30A

A3 NA 20A

B3 NA 20A

A4 15A 20A

B4 20A 15A

A5 15A 20A

B5 20A 20A

A6 20A 15A

B6 15A 15A

A7 20A NA

B7 20A NA

Autres manuels pour GenTran 6295

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Generac Power Systems Changer

Generac Power Systems

Generac Power Systems RXGW20SHA3 Manuel utilisateur

Generac Power Systems

Generac Power Systems rtsy100a3 Manuel utilisateur

Generac Power Systems

Generac Power Systems ILC Manuel utilisateur

Generac Power Systems

Generac Power Systems RTSW100G3 Manuel utilisateur

Generac Power Systems

Generac Power Systems RTSF100A1 Manuel utilisateur

Generac Power Systems

Generac Power Systems EZ Switch RTS16EZA1 Manuel utilisateur

Generac Power Systems

Generac Power Systems RTSN100J3S Manuel utilisateur

Generac Power Systems

Generac Power Systems 004635-3 Manuel utilisateur

Generac Power Systems

Generac Power Systems RXSW100A3 Manuel utilisateur

Generac Power Systems

Generac Power Systems GenTran 6295 Manuel utilisateur

Generac Power Systems

Generac Power Systems 006852 Manuel utilisateur

Generac Power Systems

Generac Power Systems 4678-1 Manuel utilisateur

Generac Power Systems

Generac Power Systems PWRview RXEMW200A3 Manuel utilisateur

Generac Power Systems

Generac Power Systems TTS Series Manuel utilisateur

Generac Power Systems

Generac Power Systems 004635-3 Manuel utilisateur

Generac Power Systems

Generac Power Systems GenTran 6379 Manuel utilisateur

Generac Power Systems

Generac Power Systems 5464 Manuel utilisateur

Generac Power Systems

Generac Power Systems GenTran 6294 Manuel utilisateur

Generac Power Systems

Generac Power Systems GenTran 6375 Manuel utilisateur

Generac Power Systems

Generac Power Systems Automatic Transfer Switch Manuel utilisateur

Generac Power Systems

Generac Power Systems RTSJ200A3 Manuel utilisateur

Generac Power Systems

Generac Power Systems RXUW200A3 Manuel utilisateur

Generac Power Systems

Generac Power Systems EZ Switch RTS16EZA1 Manuel utilisateur

Generac Power Systems

Generac Power Systems GenTran 6375 Feuille d'instructions

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
