Genaray OLED-55 Manuel utilisateur

OctaLux LED - USER MANUAL 1

USER MANUAL

OLED-55

OCTALUX LED

OctaLux LED - USER MANUAL

Thank you for choosing Genaray.

The OctaLux LED Light Softbox produces bright, soft, and

consistent light that’s designed for use in the studio or on

location when shooting portraits, beauty/fashion, tabletop

products, and interviews. 240 individual LEDs generate a

5500 K daylight-balanced light that creates warmth and

glow on your subject. This continuous light emits very

little heat, so it can be used for extended periods without

overheating, and it allows you to get up close for intimate

shots. A dimmer control affords the ability to change the

light output from 10% to 100%.This is a great feature when

environment conditions alter the amount of light needed

for proper exposure.

OctaLux LED

INTRODUCTION

OctaLux LED - USER MANUAL

The housing is sturdy, and the LEDs are not prone to

breakage like ﬂuorescent ﬁxtures, making the Genaray

OLED-55 ideal for everyday usage. The OctaLux LED Light

Softbox is 31.5˝ (80 cm) in diameter, and it attaches with

tension rods to the integrated speed ring, making setup a

snap. Additionally, you have the option of three diffusion

attachments. The diffusers help soften the light output,

which is more ﬂattering and minimizes harsh shadows.

Introduction ................................2-3

Precautions ................................4-5

Overview ......................................6-9

Assembling the Softbox ........10-11

Attaching the Diffusers .........12-13

Mounting the OctaLux .................14

Powering the OctaLux .................15

Disassembling the Softbox ...........16

Speciﬁcations ...............................17

Warranty .......................................19

TABLE OF

CONTENTS

OctaLux LED - USER MANUAL

PRECAUTIONS

· Please read and follow these

instructions, and keep this

manual in a safe place.

· Keep this product away from water

and any ﬂammable gases or liquids.

· Do not leave the device in a

closed vehicle under the sun

or in other areas subject to

very high temperatures.

· Make sure this product is powered off

when plugging it into a power source.

· Always remove the power cord by

holding the plug; do not pull the cord.

· Disconnect the power cord from

the power supply when not in use.

· Use only the correct,

recommended voltage.

· Do not attempt to disassemble

or repair this product. There are

components inside that can produce

a hazardous electric shock.

PRECAUTIONS

OctaLux LED - USER MANUAL 5

PRECAUTIONS

· Do not stare at the light

when it is powered on.

· Do not point directly towards the

naked eye (especially those of

infants and small children)—it

may lead to visual impairment.

· Avoid any unnecessary impact to the

unit, as this can damage the LEDs.

· Handle this product with care.

· Do not touch the LEDs or

expose them to moisture.

· If necessary, clean the LEDs

with only a lint-free, cotton

cloth. Do not smudge.

· Keep this product away from children.

· Make sure that this product is intact

and that there are no missing parts.

· All images are for illustrative

purposes only.

OctaLux LED - USER MANUAL

PRODUCT

OVERVIEW

OctaLux light head

LEDs

Reﬂector dish

Locking knob

Tilt-adjustment knob

120 V AC/DC

power adapter

AC power

cable

Diffuser cap

OctaLux LED - USER MANUAL 7

PRODUCT OVERVIEW

Mounting socket

Integrated

speed ring

DC power input

socket

Handle socket

On/off

dimmer knob Front

diffuser

OctaLux LED - USER MANUAL

PRODUCT

OVERVIEW

Inner diffuser

8 × tension rods

Internal diffuser ringlets

Softbox

tension-rod

pockets

Side B

Side A

OctaLux LED - USER MANUAL 9

PRODUCT OVERVIEW

Touch-fastener strips

Access ﬂaps

31.5˝ (80 cm)

OctaLux softbox

OctaLux light-head handle

Spacer

OctaLux LED - USER MANUAL

ASSEMBLING

THE SOFTBOX

1. Place the OctaLux light head

faceup on a ﬂat surface

2. Open the access ﬂaps on the back

of the OctaLux softbox, place the

softbox around the light head. It will

take shape with the following steps.

3. Insert the ﬁrst tension rod (side B)

in any of the eight pockets at the

outer edge of the OctaLux softbox.

4. Insert the other end of the tension rod

(side A) into the speed-ring socket

on the side of the light head.

5. Insert the next rod at the opposite side

(180°) of the ﬁrst rod. Insert one end

into the correct pocket on the softbox,

and then insert the other end into the

corresponding speed-ring socket.

INSTRUCTIONS
