Gembird SKY01UA Manuel utilisateur

USB Skypeadapter

SKY01UAUSBSkypeadapter

USB Skypeadapter

Disclaimer

•We sparednoeffortsto make sure thatthe informationinthismanualiscorrectand

complete.Howevernoliabilityisaccepted foranyerrorsoromissions.Gembird

Electronicsreservestherighttochange thespecificationsofthehardware and

software described inthismanualwithoutpriornotice.

•No partofthismanualmaybereproduced,transmittedortranslatedinanylanguage

inanyform,byanymeans,withoutthepriorwrittenpermissionofGembird

ElectronicsLtd.

•GembirdElectronicsmakesnowarrantiesfordamagesresultingfromcorruptedorlost

data due toamistakenoperationormalfunctionofthe product,thesoftware,

personalcomputersorperipheraldevices.

Gembird®isa registeredtrademarkofGembirdEurope.

Othernamesorproductsnot mentionedabovemayberegisteredtrademarksor

trademarksoftheirrespectiveowners.

USB Skypeadapter

Introduction

ThankyouforbuyingourUSBSkypeadapterforthePSTN

telephone! Thismanualwill help youinstall it properly.

Features

•SupportsSKYPEVoice-over-IP software:

§Free callstoanySKYPEuseranywhereintheworld

§SupportsSKYPEspeed dial

§SupportsSkypeOut and SkypeInservices

•SupportsPSTNtelephonecalling and answering

•Yourtelephonewillbeabletobeusedwithanyvoice

software:MSN Messenger,YahooMessenger,ICQ etc

•CompatiblewithPSTNsystemtones

•Supports"Busy"tonedetection:autodisconnectionafter

remotetalkerhang-up

SKY01UAUsermanual

USB Skypeadapter

•Canbeused forthevoice menu(computersecretary)

•Advancedsignalprocessingforhigh-qualityvoice and

echo-cancellation

•Singlekey'*'toswitchbetweenSKYPEand PSTNcalls

•Incoming call detectionand auto-switching

•Supportsthree-wayconversationbetweenyouandremote

SKYPEand PSTNtalkers

•Call forwardingbetweenSKYPEandPSTNcanbedone

automaticallyormanually

•Alerttoneforanincomingcallduringon-going

conversation

Note1: Three-waycall meansaconcurrentconversation

betweenUSB-UATAuser,andSKYPEandPSTNuseronthe

otherend.

Note2: RedLEDindicatesSKYPEconnectionstatus.Green

LEDindicatesPSTNconnectionstatus.WhenredorgreenLED

is flashing,itindicatesthatSKYPEorPSTNlineis connecting,

USB Skypeadapter

respectively.WhenbothLED'sareon,itindicatesthata

three-waycallis inprogress.

Specifications

•Compliant withUSB1.1and 2.0specification

•CompliantwithUSBAudioDevice ClassSpecification

Version1.0

•Compliant withUSBHID Version1.1

•PSTNvoltage:24~60VDC

•LEDstatusindicators

•SupportsordinaryPSTNtelephonefunctionswithoutUSB

connection

•SupportsnormalSKYPEfunctionswithoutPSTNline

connection

•Noexternalpowersupplyrequired

•Intendedforindoorusage(operatingtemperature:0~55

C,humidity:10~90%)

USB Skypeadapter

Systemrequirements

•PSTNregularorDECTtelephone

•Computerwith

•400 MHz CPUorbetter

•USBport

•128MBofRAM

•15MBofhard diskspace

•Operating system:Windows2000/XP/2003

•"USB-ATA" softwareinstalled

•SKYPEsoftware:version2.0orabove

•Network:LAN,ADSL,ISDN,56Kmodemorbetter

USB Skypeadapter

Installation

InstallingSKYPE

SKY01UAisbasedonSkypeplatform.Beforeusing

SKY01UA,usermustinstallSKYPEsoftware.Fordownloading

SKYPEandmoredetails,visitSKYPE'sofficialwebsiteat

http://www.skype.com.

InstallingSKY01UASoftware

DonotconnectSKY01UAboardtoUSBportduringinstallation!

Hereis theinstallationprocedure:

•Runsetup.exe.Whenthewindowappears,press "NEXT"

button

USB Skypeadapter

•Select theinstallationpathtobeinstalled

•Select theStart Menu folder

•Start installation

•Once installationiscomplete,press"Finish" button

USB Skypeadapter

ConnectingSKY01UA

WhenSKY01UAisconnectedtoPC,PCwill beabletodetect a

new device and install required drivers automatically

UsingSKYPE

•WithSKYPEonlineand running,double-clickonSKY01UA

USB Connector

Phone Jack B

Phone Jack A

USB Skypeadapter

shortcutondesktop.Select"Allowthisprogramtouse

Skype",and thenclickon"OK" button.

•Ifthesystemtrayatthebottomrightcornershowsthe

icon ,it meansthatSKY01UAisoperational.Iftheicon

appears,itmeansthatSKY01UAisnotconnectedtoPC

properly.IfSKYPEsoftwareis notrunningproperly,the

systemtraywillshowtheicon .Usershould checkand
