Geist RSMINI-P Manuel utilisateur
GM1093.doc 1 Revision Date: 10/15/2010
Instruction Manual
Environmental Monitoring Unit
RSMINI-P, RSMICRO, RSMINI163
Firmware Version 3
GM1093 2 Revision Date: 10/15/2010
Contents
Specifications....................................................................................................................3
Overview 3
Environmental 3
Electrical 3
Networking 3
Data Formats 3
EMC Verification 4
Installation .......................................................................................................................5
Guidelines 5
Network Overview 6
Default IP Address 6
Initial Setup 6
Web Interface ...................................................................................................................9
Overview 9
Sensors Page 9
Logging Page 11
Display Page 12
Alarms Page 13
Configuration Page 14
Unit Configuration...........................................................................................................19
Network Configuration 19
Time and Date 20
E-Mail 20
SNMP 22
Accounts and Passwords 23
Telnet 23
Camera Configuration 24
Admin Information 24
Alarms.............................................................................................................................25
Alarm Notifications 25
Alarm Types 25
Thresholds 25
Sensors ...........................................................................................................................27
Overview 27
Internal Sensors 27
Temperature Offset 27
I/O Sensors (RSMINI163) 27
Remote Sensors (RSMINI-P and RSMINI163 Only) 29
Data Logging and Display 29
Accessories .....................................................................................................................30
IP-Addressable Network Cameras 30
RSC Integration 30
Alternate Data Formats 30
Technical Support ...........................................................................................................31
Firmware Version 31
Firmware Updates 31
Resetting the Unit 31
Service and Maintenance 31
More Technical Support 31
Table of Figures ..............................................................................................................32
Revision History..............................................................................................................33
GM1093 3 Revision Date: 10/15/2010
Specifications
Overview
The RSMINI-P, RSMICRO, and RSMINI163 Environmental Monitoring Units provide remote
environmental monitoring and alarming capability needed to detect climate conditions in data
centers. The RSMINI-P, RSMICRO, and RSMINI163 Environmental Monitoring Units are
equipped with a built-in web server. Web pages, including graphs, are generated by the unit to
monitor environmental conditions within the cabinet. No software other than a web browser is
required for operation and several data formats are available. The RSMICRO has built-in
sensors to monitor Temperature and Relative Humidity. The RSMINI-P and RSMINI163 have a
built-in temperature sensor. The RSMINI-P has one expansion port for the connection of up to
16 external sensors. The RSMINI163 has 16 expansion ports for the connection of external
sensors and 3 I/O ports for optional remoter sensors. The RSMINI-P, RSMINI163, and the
RSMICRO support the use of network cameras.
Environmental
Temperature
Operating: 10°C (50°F) min 45°C (104°F) max
Storage: -25°C (-13°F) min 65°C (149°F) max
Humidity
Operating: 5% min 95% max (non-condensing)
Storage: 5% min 95% max (non-condensing)
Elevation
Operating: 0 m (0 ft) min 2000 m (6561 ft) max
Storage: 0 m (0 ft) min 15240 m (50000 ft) max
Electrical
6-12 Volts DC, 2 Amps
Power Over Ethernet (POE) Enabled
Networking
Protocols
HTTP, HTTPS (SSL/TLS), SMTP, POP3, ICMP, DHCP, TCP/IP, NTP, Telnet, Syslog
Ethernet Link Speed
10 Mbit; half-duplex
Data Formats
HTML, SNMP, CSV/Plain Text, XML
GM1093 4 Revision Date: 10/15/2010
EMC Verification
This Class A device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
GM1093 5 Revision Date: 10/15/2010
Installation
Guidelines
•If the Environmental Monitoring Unit is installed in a cabinet the ambient temperature of the
rack should be no greater than 45°C.
•Install the Environmental Monitoring Unit such that the amount of airflow required for safe
operation of equipment is not compromised.
•Mount the Environmental Monitoring Unit so that a hazardous condition is not achieved due
to uneven mechanical loading.
GM1093 6 Revision Date: 10/15/2010
Network Overview
This product comes preconfigured with a default IP address set. Simply connect to the
Environmental Monitoring Unit and access the web page with your browser.
Default IP Address
RSMINI-P, RSMICRO, and RSMINI163 units have a default IP address for initial setup and
access to the unit if the assigned address is lost or forgotten. Once an IP address is assigned to
a unit, the default IP address is no longer active. To restore the default IP address, press and
hold for approximately 20 seconds the reset button for approximately 20 seconds. The reset
button is located below the network connector (RSMINI-P and RSMINI163) or on the side of the
unit (RSMICRO). On the RSMINI-P and RSMINI163 the idle and activity lights on the network
connector will both light up when the IP address has been reset.
Note: Pressing the reset button will restore the default IP address and will also clear all
password settings.
The Configuration page allows you to assign the network properties or use DHCP to connect to
your network. Access to the unit requires the IP address to be known, so use of a Static IP or
reserved DHCP is recommended. The default address is shown on the front of the unit:
•IP Address: 192.168.123.123
•Subnet Mask: 255.255.255.0
•Gateway: 192.168.123.1
Initial Setup
Connect the RSMINI-P, RSMICRO, or RSMINI163 unit to your computer using a crossover cable
or hub/switch.
Windows XP
On your computer, go to “Start > Settings > Control Panel > Network and Dial Up
Connections”
Right click on “Local Area Connection” and select “Properties”
Select “Use the following IP address”. Use these settings:
IP Address: 192.168.123.1
Subnet Mask: 255.255.255.0
Gateway: Leave blank
Click “OK” twice.
The unit should now be accessible in a web browser via the unit’s permanent IP address:
http://192.168.123.123/. See Unit Configuration (page 19) for details.
Figure 1: Network settings for initial setup.
MacOS X Leopard
Open System Preferences via the Dock or the Apple menu.
Select “Network” under “Internet & Network.”
Select “Ethernet” from the list on the left side of the window and enter these settings on the
right side of the window:
Configure: Manually
IP Address: 192.168.123.1
Subnet Mask: 255.255.255.0
Router: Leave blank
Hit “Apply” and confirm the changes.
The unit should now be accessible in a web browser via the unit’s permanent IP address:
http://192.168.123.123/. See Unit Configuration (page 19) for details.
GM1093 7 Revision Date: 10/15/2010
Figure 2: MacOS X network settings for initial setup
GM1093 8 Revision Date: 10/15/2010
GM1093 9 Revision Date: 10/15/2010
Web Interface
Overview
The unit is accessible via a standard, unencrypted HTTP connection as well as an encrypted
HTTPS (SSL) connection. The following web pages are available:
Sensors Page
The front page, Sensors, gives both instantaneous and historical views of the unit’s data. Real
time readings are provided for all sensor data next to historical graphs.
Optional cameras may be added and their live snapshots are shown on this page. On RSMINI-P
and RSMINI163 units, plug-and-play sensors appear below the internal sensors when attached.
The menu bar allows access to the rest of the Environmental Monitoring Unit’s functionality.
Figure 3: Sensors Page – Internal Temperature Sensor
Firmware
Version
Alternate
Formats
Real Time
Sensor
Readings
Historical
Sensor Data
GM1093 10 Revision Date: 10/15/2010
Figure 4: Sensors Page – External Sensor Data (RSMINI-P Only)
Real Time Sensor
Readings
Sensor Friendly
Name
Historical
Sensor Data
