GEIGER GEIGER-SoftZero-55 Manuel utilisateur

www.geiger.de EN

DE Bedienungsanleitung

Operating Instructions

Manuel d’utilisation

Manual de instrucciones

Istruzioni per l’uso

Tubular motor:

GEIGER-SOLIDline ../55

Motor control:

GEIGER-SoftZero-55 (GU45..E02)

for facade awnings, screens and ZIP screens

2Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000

Index

1. Characteristics of the GEIGER-SoftZero-55 ..................3

2. General information .........................................................4

3. Guarantee ..........................................................................4

4. Safety information ............................................................4

5. Intended use .....................................................................5

6. Installation instructions ...................................................6

7. Setting of the end stops ...................................................7

8. Correction of the end stops .............................................7

9. GEIGER Powertronic ........................................................8

10. Obstacle detection ...........................................................9

11. Technical data .................................................................10

12. Declaration of conformity ..............................................10

13. Information for the specialist electrician .....................11

14. Notes on waste disposal ...............................................11

15. What to do if… ................................................................12

www.geiger.de EN

1. Characteristics of the GEIGER-SoftZero-55

Universal electronic motor for facade awnings

• Facade awnings, screens and ZIP screens can be operated with the

GEIGER SoftZero-55.

Safety

• A safe locking of the facade awning/screen through torque shutoff

Fabric Protection

• GEIGER-Locking power minimisation (automatic function)

• GEIGER-Powertronic (manual function: power level)

...for a nice long lasting fabric.

Hanging Length Adjustment

• Modiﬁcations in fabric lengths are recognised and compensated for.

Obstacle Recognition

• Active obstacle detection when extending the installation

• Protection of the awning system by retracting the equipment

GEIGER-Operating Radius Identiﬁcation

• Modern electronic control identiﬁes the equipment’s torque curve,

and makes available to the motor the exact amount of power needed

during operation, and while closing.

4Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000

2. General information

Dear customer,

By purchasing a GEIGER tubular motor you have decided on a quality product from

GEIGER.

Thank you very much for your decision and the conﬁdence placed in us.

Before you put this drive into operation please observe the following safety

information. It serves for the prevention of danger and for the avoidance of personal

injury and damage to property.

Please retain this information for future reference.

fFor all facade awnings, screens and ZIP screens

fDrives are switchable in parallel

fAutomatic detection of right/left installation

3. Guarantee

In the case of incorrect installation contrary to the operating instructions and/

or constructional modiﬁcation, the legal and contractual guarantee for property

damage and product liability lapses.

4. Safety information

I ATTENTION: Important safety information. For personal safety, it is

important to follow these instructions. The instructions should be

kept.

fThis appliance is not to be used by persons (including children) whose

physical, sensorial or mental capacities are impaired, or who have no

expe rience or know-how, unless they have been supervised or been given

instructions on the use of the appliance by someone who is responsible for

their safety.

fChildren must be supervised to make sure they do not play with the

appliance.

fThe installation is to be checked regularly for defective balance, wear and

damage.

fDamaged connecting leads must be replaced by the GEIGER connecting

lead of the same wire type.

fDuring operation observe the danger zone.

fIf people or objects are in the danger zone, do not use the installation.

fUrgently shut down damaged installations until repair.

fUnconditionally shut down the unit during maintenance and cleaning

operations.

fPinching and shearing sites are to be avoided and to be safeguarded

against.

fWhen operating the manual actuator with the open sun protection system,

exercise caution as it can fall down quickly if springs expand or are broken.

www.geiger.de EN

fDo not operate the device if operations such as, for example, window

cleaning are to be carried out in the vicinity.

fDisconnect the device from the mains power supply if operations such as,

for example, window cleaning are being carried out in the vicinity.

I ATTENTION: Important safety information. Follow all installation

instructions, as incorrect installation can lead to serious injuries.

fConnection must be carried out by a skilled electrician according to the

regulations in force locally.

fThe mains plug of the tubular motor must be accessible after installation.

fOn the installation of the tubular motor without mechanical protection of

the driven parts, the tubular motor must be installed at a height of at least

2.5 m above the ground or of another level which provides access to the

drive.

fBefore the tubular motor is installed, all leads which are not needed are to

be removed and all equipment which is not needed for actuation is to be

put out of operation.

fIf the tubular motor is controlled by a switch or pushbutton, the switch

or pushbutton must be mounted within eyeshot of the tubular motor. The

switch or pushbutton must not be located in the vicinity of moving parts.

The height of installa tion must be at least 1.5 m above the ﬂoor.

If the apparatus is equipped without a pin and a socket connector (STAS3K)

in the connecting lead, or other means for disconnecting from the mains

with at least a 3 mm contact opening on each pole, a disconnecting device

of this type must be incorporated into the permanently installed electrical

installation according to the wiring rules.

fPermanently installed control devices must be attached visibly.

fThe correct dimensioning of the drive is to be observed.

5. Intended use

The tubular motors of the model range SOLIDline ../55 with the SoftZero -55

system are designed exclusively for the operation of facade awnings, screens and

ZIP screens.

If the tubular motors are used for other applications and/or modiﬁcations are

performed to the tubular motors, which have not been discussed with GEIGER

Antriebstechnik, then the manufacturer is not liable for personal injury and/or

damage to property and for consequential damage.

6Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000

6. Installation instructions

Before ﬁxing, the strength of the masonry or of the subsurface is to be checked.

I Caution: If the tube is screwed/riveted to the drive, the measure must be

taken from the tube end to the center of the drive and marked on the tube.

When drilling the winding shaft never drill into the

area of the tubular motor!

When inserting into the shaft, the tubular motor

must not be struck and must not be allowed to fall

into the shaft.

Installation into facade awnings and

screens:

Insert motor with a suitable adapter and drive into

the shaft up to the stop of the shaft adapter.

Fix the motor support on the awning. Fix the motor

together with the shaft on the motor support. The

bearer locks into place.

Depending on the selected motor head,

different ﬁxation systems can be used:

– Place the motor with square insert in the star-

shaped bearer and lock with pin

– Place the motor into the existing engine bearer

and lock

– Place the motor in a compatible engine bearer with clip system and lock with

spring or rotating lever

www.geiger.de EN

7. Setting of the end stops

Connect the setting cable to the connecting cable of the GEIGER SoftZero-DG.

When doing so, take care to ensure that the colours of the different leads do tally

with each other. The assignment of the direction keys 1 and 2 to the direction of

rotation is dependent on the installation situation of the motor. Then connect the

setting cable to the 230V mains.

Setting of the lower end position

Press the programming key until the LED blinks 1 x, then release the programming

key. Run the motor with the direction keys to the desired lower end position. Press

the programming key - the LED blinks 2 x.

Setting of the upper end position (Torque shutoff)

Run the motor with the direction keys to the desired upper end position. When

the upper end position is reached, the motor turns off automatically the learning

process. The programming is ﬁnished and the motor returns to normal operation.

I There is no need to ﬁrst delete the end stops (memorised) if you wish to

modify them.

8. Correction of the end stops

If a lengthening/shortening of the hanging has resulted due to e.g. temperature

changes, this will be automatically corrected by closing the awning.

If, due to temperature changes, modiﬁed winding behaviour should arise and the

hangings should run against the stop, an immediate end position correction takes

place.

After the ﬁrst reference run, the motor automatically identiﬁes the torque necessary

to close the awning and closes it with the lowest possible power, so that the fabric

is optimally protected.

Mains:

230

VSetting cable

M56....

Service

terminals

Connecting cable

to limit stop12

Programming

key

LED

Hirschmann coupling

Adaption cable

M56B265

8Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000

9. GEIGER Powertronic

The GEIGER Powertronic enables the user to change the motor’s closing characteris-

tics. The user can raise or reduce the closing power applied through the motor. This

way, he or she inﬂuences the closing characteristics of the casing. A rise in the closing

power causes a tighter closing of the casing with increased stress on the fabric; a

reduction in the closing power causes a looser closing and less strain to the fabric.

Closing power levels: from level 0 to level 7

GEIGER-delivery setting: level 0

I Caution: By manually raising the closing power (e.g. from level 0 to

level 3) the fabric endures more strain.

In which situations is the GEIGER Powertronic applied?

• If the casing does not completely close.

• If the closing operation should be optimised for better fabric protection.

When can the GEIGER Powertronic be applied?

• Anytime; this function can be activated during initial operation, as well as at a

later date.

Which resources are necessary?

• GEIGER setting cable M56K144 (D), M56F150 (CH) or M56F151 (D with service

terminal)

Please note:

• The stop positions are not affected when the GEIGER Powertronic is activated.

• The selected power level is not affected when the end stop positions are changed

• Only activate the GEIGER Powertronic after the stop positions have been

taught-in and a complete reference run has been conducted.

GEIGER Powertronic – changing the power levels

Connect the setting cable to the connecting cable of the motor. When doing so,

take care to ensure that the colours of the different leads do tally with each other.

Then connect the setting cable to the 230V mains.

Activating the GEIGER Powertronic

Press the programming key about 8 seconds until the LED blinks 3 x, then release

the programming key.

Changing the power levels

The motor is delivered with the power level 0. In order to increase the force press

key 2. Press key at least 2 seconds and stop at least 2 seconds. In order to

reduce the force press key 1. In order to store the selected level, press shortly the

programming key – the LED lights up. The adjustment process is ﬁnished.

www.geiger.de EN

10. Obstacle detection

If, after teaching-in, the ﬁrst complete, uninterrupted run from one stop position to

the other is conducted, the necessary torque will be taught-in.

With each successive complete and uninterrupted run from one stop position to

the other, the necessary torque is automatically readjusted. Slow changes to the

equipment through aging, contamination, the cold or heat are accounted for in this

regard. This process takes place for both running directions independently of one

another.

Should UPWARD movement be blocked by an obstruction, the motor turns off and

a short reverse movement occurs.

The direction of movement in which the obstruction was detected is locked.

The device will be unlocked if the motor is run for a short time period in the oppo-

site direction. The obstruction must also be removed before the motor can be rerun

in the direction of the obstruction.

I Because of the motor sensitive obstacle detection, the correct

dimensioning of the torque for the respective installation size is

essential.

In the following table please ﬁnd a selection aid to ﬁnd out the right motor size:

These are estimated values so please check the correct functioning of the

installation.

I When using a wind sensor the correct functioning of the retract

command under wind load should be checked by the manufacturer of

the sun protection before commissioning.

1 2 3 4 5 6 8 10 12 15 20 25 30

0,2 0,5 0,7 1,0 1,2 1,5 2,0 2,5 2,9 3,7 4,9 6,1 7,4

0,3 0,5 0,8 1,1 1,3 1,6 2,2 2,7 3,2 4,0 5,4 6,7 8,1

0,3 0,6 0,9 1,2 1,5 1,8 2,4 2,9 3,5 4,4 5,9 7,4 8,8

0,3 0,6 1,0 1,3 1,6 1,9 2,6 3,2 3,8 4,8 6,4 8,0 9,6

0,3 0,7 1,0 1,4 1,7 2,1 2,7 3,4 4,1 5,2 6,9 8,6 10,3

0,4 0,7 1,1 1,5 1,8 2,2 2,9 3,7 4,4 5,5 7,4 9,2 11,0

0,4 0,8 1,2 1,6 2,0 2,4 3,1 3,9 4,7 5,9 7,8 9,8 11,8

0,4 0,8 1,3 1,7 2,1 2,5 3,3 4,2 5,0 6,3 8,3 10,4 12,5

0,4 0,9 1,3 1,8 2,2 2,6 3,5 4,4 5,3 6,6 8,8 11,0 13,2

0,5 0,9 1,4 1,9 2,3 2,8 3,7 4,7 5,6 7,0 9,3 11,6 14,0

0,5 1,0 1,5 2,0 2,5 2,9 3,9 4,9 5,9 7,4 9,8 12,3 14,7

0,5 1,1 1,6 2,2 2,7 3,2 4,3 5,4 6,5 8,1 10,8 13,5 16,2

Weight of bottom bar [kg]

3 Nm 6 Nm 9 Nm 12 Nm

Winding diameter [mm]

100

110

10 Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000

11. Technical data

Technical data of short motor SOLIDline (GU45..)

GU4503/55 GU4506/55 GU4509/55 GU4512/55

Voltage 230 V~/50 Hz 230 V~/50 Hz 230 V~/50 Hz 230 V~/50 Hz

Current 0,47 A 0,63 A 0,8 A 1,0 A

Cos Phi (cosj)>0,95 >0,95 >0,95 >0,95

Inrush current

(factor)

x 1,2 x 1,2 x 1,2 x 1,2

Power 105 W 140 W 180 W 220 W

Torque 3 Nm 6 Nm 9 Nm 12 Nm

Speed of rotation 55 1/min 55 1/min 55 1/min 55 1/min

Protection type IP 44 IP 44 IP 44 IP 44

Total length1) 515,5 mm 545,5 mm 565,5 mm 585,5 mm

Operating type S2 4 min S2 5 min S2 4 min S2 4 min

Diameter 45 mm 45 mm 45 mm 45 mm

Weight approx.

1,9 kg

approx.

2,2 kg

approx.

2,4 kg

approx.

2,7 kg

1) SOLIDline-ZN/-KS: +1 mm / SOLIDline-COM/-SIC + 4,5 mm / SOLIDline-SOC: + 4 mm

Subject to technical modifications

12. Declaration of conformity

We herewith explicitly declare that this product complies with the essential require-

ments and relevant directives. It is authorised for use in all EC member states and

in Switzerland without any need of prior registration. The Declaration of Conformity

concerning this product is available on our website:

www.geiger-antriebstechnik.de.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GEIGER Moteur

GEIGER

GEIGER SOLIDline Manuel utilisateur

GEIGER

GEIGER SOLIDline SoftPlus-Qi GU45-E09 Series Manuel utilisateur

GEIGER

GEIGER GEIGER-SOLIDline x/55 Series Manuel utilisateur

GEIGER

GEIGER GJ5606k F03 Manuel utilisateur

GEIGER

GEIGER INline System GSI56 r Series Manuel utilisateur

GEIGER

GEIGER SOLIDline GU45 Series Manuel utilisateur

GEIGER

GEIGER SOLIDline GU4506 Manuel utilisateur

GEIGER

GEIGER SOLIDline-MOR GU4510 Manuel utilisateur

GEIGER

GEIGER GEIGER-SOLIDline Series Manuel utilisateur

GEIGER

GEIGER GEIGER-SOLIDline Series Manuel utilisateur

GEIGER

GEIGER GJ56 E14-1002 Series Manuel utilisateur

GEIGER

GEIGER GJ56 E14-1002 Series Manuel utilisateur

GEIGER

GEIGER SOLIDline GJ56 Series Manuel utilisateur

GEIGER

GEIGER SOLIDline Manuel utilisateur

GEIGER

GEIGER GJ5610v1 Manuel utilisateur

GEIGER

GEIGER SOLIDline GJ56 Series Manuel d'utilisation

GEIGER

GEIGER GB45MR Series Manuel utilisateur

GEIGER

GEIGER GJ56 e Series Manuel utilisateur

GEIGER

GEIGER GEIGER-Solid Line Manuel utilisateur

GEIGER

GEIGER PRO.TECline Spindle GB45 Series Manuel utilisateur

GEIGER

GEIGER GJ5606-DuoDrive Manuel utilisateur

GEIGER

GEIGER GEIGER-MODULARline Manuel utilisateur

GEIGER

GEIGER GEIGER-SOLIDline Manuel utilisateur

GEIGER

GEIGER GJ56E11 Series Manuel utilisateur

Manuels Moteur populaires d'autres marques

Rotax

Rotax 125 senior MAX evo Manuel utilisateur

Kohler

Kohler K361 Manuel utilisateur

MTD

MTD OHV Series Manuel utilisateur

Kohler

Kohler COMMAND CH18-745 Manuel utilisateur

Mercury

Mercury D4.2L D-Tronic Manuel utilisateur

Selve

Selve SE Plus-RC Series Manuel utilisateur

Perkins

Perkins 1206E-E66TA Manuel utilisateur

Skov

Skov DA 174 Manuel

Rossi

Rossi TX11 Series Manuel utilisateur

Siemens

Siemens SIMOTICS T-1FW3 Feuille d'instructions

AL-KO

AL-KO PRO 350 Manuel utilisateur

MTU

MTU 12 V 4000 Lx4 Manuel utilisateur

Nanni

Nanni N3.30 Manuel d'instructions

Nanni

Nanni N5.160 CR2 Manuel utilisateur

KSB

KSB SuPreme Series Instructions d'installation

Hiwin

Hiwin EM1 Series Manuel utilisateur

Rotax

Rotax 912 i series Mode d'emploi

Siemens

Siemens SIMOTICS XP 1MB1 Manuel utilisateur
