Gefen EXT-DVI-444DL Manuel utilisateur

www.gefen.com

4x4 DVI Dual Link

Matrix

EXT-DVI-444DL

User Manual

ASKING FOR ASSISTANCE

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM (PST) Monday thru Friday PST

Write To:

Gefen, LLC

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen, LLC reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

4x4 DVI DL Matrix is a trademark of Gefen, LLC

All trademarks are the property of their respective owners.

Rev X3

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Panel Layout

5 Panel Descriptions

6 Connecting And Operating The 4x4 DVI DL Matrix

7 Conﬁguring The 4x4 DVI DL Matrix

9 RS-232 Serial Control Interface

10 Rack Mount Installation

11 Speciﬁcations

12 Warranty

Congratulations on your purchase of the 4x4 DVI DL Matrix. Your complete

satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen 4x4 DVI DL Matrix

Easily combine any four cross-platform Dual Link DVI video display outputs and

four Dual Link DVI digital displays without networking. Our 4x4 DVI Dual Link

Matrix provides a simple, reliable and highly effective method of creating multiple

Dual Link DVI display consoles, with each console capable of accessing any one

of the Dual Link DVI video sources at any time by remote control. You also have

the option of setting up the four displays locally or extending them with a Gefen

extender.

How It Works

The 4x4 DVI Dual Link Matrix has four Dual Link DVI inputs and four Dual Link

DVI outputs. You simply connect your four Dual Link DVI video sources to the

Switcher’s inputs, then connect your four Dual Link DVI displays to the Switcher’s

outputs.

INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE 4X4 DVI DL MATRIX

• The 4x4 DVI DL Matrix does not have any scaling functionality. All of the

attached monitors must be able to display the attached sources’ resolution.

For maximum compatibility it is recommended that only one compatible/

common resolution for all displays be used by all sources.

OPERATION NOTES

Features

• Increases your productivity by letting you view any four Dual Link DVI video

sources on any four Dual Link DVI displays

• Maintains highest resolution digital video with no loss of quality

• Discrete IR Remote (included)

• Supports video resolutions up to 3840x2400

• Supports DDWG standards for DVI monitors

• Includes rack ears

Package Includes

(1) 4x4 DVI Dual Link Matrix

(1) RMT-16IR

(1) 5V DC Power Supply

(4) 6 Foot Dual Link DVI cables

(1) Set Of Rack Ears

(1) User’s Manual

FEATURES

Front Panel

Back Panel

PANEL LAYOUT

12345

910111213141516

PANEL DESCRIPTIONS

1 Display 1 Selected Source LED

The array of 4 LED’s correspond to the 4 source inputs on the back panel of the 4x4 DVI DL

Matrix. The currently selected source being displayed on DVI Output 1 will be indicated by an

active LED.

2 Display 2 Selected Source LED

The array of 4 LED’s correspond to the 4 source inputs on the back panel of the 4x4 DVI DL

Matrix. The currently selected source being displayed on DVI Output 2 will be indicated by an

active LED.

3 Display 3 Selected Source LED

The array of 4 LED’s correspond to the 4 source inputs on the back panel of the 4x4 DVI DL

Matrix. The currently selected source being displayed on DVI Output 3 will be indicated by an

active LED.

4 Display 4 Selected Source LED

The array of 4 LED’s correspond to the 4 source inputs on the back panel of the 4x4 DVI DL

Matrix. The currently selected source being displayed on DVI Output 4 will be indicated by an

active LED.

5 IR Receiver

This IR receiver will receive commands from the included RMT-16-IR remote control.

6 IR Extension Port

Connect an optional IR extension (part# EXT-RMT-EXTIR) to this port.

7 Power LED Indicator

This LED will become active once the included 5V DC power adapter is properly connected.

8 RS-232 Serial Control Interface

Use the commands on page 9 to control the 4x4 DVI DL Matrix using the RS-232 interface.

9 DVI Input 1

Connect a DVI DL source to this input.

10 DVI Input 2

Connect a DVI DL source to this input.

11 DVI Input 3

Connect a DVI DL source to this input.

12 DVI Input 4

Connect a DVI DL source to this input.

13 DVI Output 1

Connect a DVI DL display to this port.

14 DVI Output 2

Connect a DVI DL display to this port.

15 DVI Output 3

Connect a DVI DL display to this port.

16 DVI Output 4

Connect a DVI DL display to this port.

17 Locking 5V DC Power Adapter Input

Connect the included 5V DC power adapter to this port.

How to Connect the 4x4 DVI DL Matrix

1. Connect up to 4 DVI DL sources to the 4x4 DVI DL Matrix input ports using

the supplied DVI DL cables.

2. Connect up to 4 displays to the 4x4 DVI DL Matrix output ports using user

supplied DVI DL cables.

3. Connect the supplied 5V DC power supply to the 4x4 DVI DL Matrix.

4. Power on the displays.

5. Power on each source individually ensuring that a display is pointing to it

while the power on procedure completes.

NOTE: It is extremely important to ensure that when each source is being

powered on it has a display pointing to it. Most sources require (a deﬁnite

requirement if computers are being used) a display to be attached to

receive EDID (display information) and to begin operation. If a source

does not have a display that is pointing to it, a video image may fail to be

displayed. It is recommended that each source be powered on and veriﬁed

that it is outputting video before moving on to power the next source.

CONNECTING AND OPERATING THE 4X4 DVI DL MATRIX

Remote Channel 1:

Default

1 2

Remote Channel 2:

1 2

Remote Channel 3:

1 2

Remote Channel 4:

1 2

Remote Channel 1:

Default

1 2

Remote Channel 2:

1 2

Remote Channel 3:

1 2

Remote Channel 4:

1 2

RMT-16-IR REMOTE CONTROL 4x4 DVI DL Matrix

12345678

OFF

The 4x4 DVI DL Matrix has a bank of 8 conﬁguration DIP SWITCHES. These

switches are located underneath the unit. Peeling back the black metallic sticker

on the bottom of the 4x4 DVI DL Matrix will reveal the Dip Switch bank. These

service switches are used for a number of conﬁguration options. By default, all

Dip Switches are in the OFF position. Each setting is outlined below.

Switch 1 IR Remote Channel Conﬁguration

Switch 2 IR Remote Channel Conﬁguration

Switch 3 Automatic Link Selection \ Dual Link Only Mode

Switch 4 Not Used

Switch 5 Pre-Empahsis For Display Output 1

Switch 6 Pre-Empahsis For Display Output 2

Switch 7 Pre-Empahsis For Display Output 3

Switch 8 Pre-Empahsis For Display Output 4

IR REMOTE CHANNEL CONFIGURATION

Dip Switches 1 and 2 relate to the IR remote control channel that is used by the 4x4

DVI DL Matrix and RMT-16-IR remote control. Dip Switch 1 and 2 on the 4x4

DVI DL Matrix must match Dip Switch 1 and 2 on the RMT-16-IR remote control.

Please view the table below to set the channel on 4x4 DVI DL Matrix and IR

remote control. The remote channel for the RMT-16-IR is located underneath it’s

battery cover.

CONFIGURING THE 4X4 DVI DL MATRIX
