Gefen EXT-WRS232 Manuel utilisateur
Release A8
User Manual
EXT-WRS232
Wireless RS232 Extender
Wireless RS232 Extender
Important Safety Instructions
ii
GENERAL SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. To reduce the risk of electric shock and/or damage to this product, never handle or
touch this unit or power cord if your hands are wet or damp. Do not expose this
product to rain or moisture.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Batteries that may be included with this product and/or accessories should never be
exposed to open ame or excessive heat. Always dispose of used batteries
according to the instructions.
Wireless RS232 Extender
Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and
workmanship.
If equipment fails because of such defects and Gefen is notied within two (2) years from
the date of shipment, Gefen will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or other abuse or
modications. Equipment that fails under conditions other than those covered will be
repaired at the current price of parts and labor in effect at the time of repair. Such repairs
are warranted for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or tness for any particular purpose, all of
which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their original
condition.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or
consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the features and specications is subject to change without notice.
For the latest warranty coverage information, refer to the Warranty and Return Policy under
the Support section of the Gefen Web site at www.gefen.com.
PRODUCT REGISTRATION
Please register your product online by visiting the Register Product page under the
Support section of the Gefen Web site.
iii
iv
Wireless RS232 Extender
Gefen, LLC
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
Telephone: (818) 772-9100
(800) 545-6900
Fax: (818) 772-9120
Visit us on the Web: www.gefen.com
Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacic Time
Wireless RS232 Extender is a trademark of Gefen, LLC.
Important Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging, and any
accompanying documentation without prior written notice.
© 2010 Gefen, LLC. All Rights Reserved.
All trademarks are the property of their respective owners.
Contacting Gefen Technical Support
iv
vv
3GSDI Audio Embedder
Operating Notes
Wireless RS232 Extender
FCC Statement
INSTRUCTIONS TO THE USER
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and Receiver unit
• Connect the equipment into an outlet on a circuit different from that to which the
Receiver unit is connected
• Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must be used with
this equipment. Operation with non-approved equipment or unshielded cables is likely to
result in interference to radio and TV reception. The user is cautioned that changes and
modications made to the equipment without the approval of the manufacturer could void
the user’s authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
vi
3GSDI Audio EmbedderWireless RS232 Extender
Industry Canada (IC) Statement
Applicant’s Name: Gefen, LLC
Manufacturer’s Trade Name: Gefen
Model / IC ID Numbers:
EXT-WRS232R (IC:9057A-EXTWRS232R)
EXT-WRS232S (IC:9057A-EXTWRS232S)
The wireless radio of this device complies with IC RSS-210 Industry Canada. Operation is
subject to the following two conditions: (1) this device may not cause interference,and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that
required for successful communication.
This device has been designed to operate with the antennas provided, and having a
maximum gain of 2.5 dBi. Antennas not included with this product or having a gain greater
than 2.5 dBi are strictly prohibited for use with this device. The required antenna impedance
is 50 Ohms.
Operating Notes
vii
3GSDI Audio EmbedderWireless RS232 Extender
Operating Notes
Important Operating Information
• The Wireless RS232 Extender is capable of operating at a baud rate of either 9600
or 19200. See Setting the Baud Rate for details on setting the correct baud rate for
the RS-232 device.
• The metal housing is immune to EMI interference and the external antenna is capable
of extending RS-232 control up to 100 feet (30 meters) through 8 brick walls. Multiple
Sender units can also operate simultaneously, allowing greater exibility in a wireless
RS-232 solution. See the Conguration section ror details on setting up a wireless
RS-232 network.
• Although the Sender unit can be used without external power, the RS-232 protocol
does not outline specic guidelines for sending power to another RS-232 device.
In most cases, only a small amount of power can be extracted (~10mA) from the DTR
(Data Terminal Ready) and RTS (Ready To Send) lines. This is only suitable for lower
power devices (e.g. mouse devices). If there is not enough available power, the LED
stays in the OFF state.
• After changing DIP switch settings on a Sender and/or Receiver, disconnect the
power and RS-232 cables from each unit, then reconnect them. Failure to do so may
prevent the changes from taking effect or may result in erratic behavior.
viii
3GSDI Audio EmbedderWireless RS232 Extender
Features
• Extends any RS-232 compliant device up to 100 feet (30 meters) from a computer or
other RS-232 controller
• Metal enclose immune to EMI interference
• No cables are required for extension
• Secure locking power connector prevents accidental power disruption due to stress on
power connector
• Two selectable baud rates: 9600 or 19200
• Unlimited number of nodes when using multiple Sender units and Receiver units in a
wireless RS-232 network (one-to-many, many-to-one, or many-to-many)
• Perfect for digital signage applications
• Quick and easy setup
Packing List
The Wireless RS232 Extender ships with the items listed below. If any of these items are
not present in your box when you rst open it, immediately contact your dealer or Gefen.
• 1 x Wireless RS232 Extender (Sender unit)
• 1 x Wireless RS232 Extender (Receiver unit)
• 1 x 6 ft. RS-232 cable (M-F)
• 2 x 5V DC power supplies
• 1 x User Manual
Features and Packing List
3GSDI Audio EmbedderWireless RS232 Extender
Table of Contents
x
01 Getting Started
Panel Layout ......................................................................................................... 2
Sender unit.................................................................................................... 2
Receiver unit ................................................................................................. 4
Installation ............................................................................................................. 6
Connecting the Wireless RS232 Extender.................................................... 6
Sample Wiring Diagram ................................................................................ 6
02 Operating the Wireless RS232 Extender
Conguration....................................................................................................... 10
Setting the Baud Rate ................................................................................. 10
Wireless RS-232 Extender Network Congurations ................................... 10
Using Multiple Sender Units........................................................................ 11
Using Multiple Receiver Units ..................................................................... 12
Using Multiple Sender / Receiver Pairs....................................................... 13
Erasing the Electronic Serial Numbers (ESNs)........................................... 14
03 Appendix
Specications ...................................................................................................... 18
