Gefen EXT-WHD-1080P-LR-TX Manuel utilisateur

EXT-WHD-1080P-LR-TX

EXT-WHD-1080P-LR-RX

User Manual

Wireless for HDMI 5 GHz

w/ Dual Inputs and Local Output

Release A2

*Preferred

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

Important Safety Instructions

iii

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and if

not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and Receiver unit

• Connect the equipment into an outlet on a circuit different from that to which the

Receiver unit is connected

• Consult the dealer or an experienced radio/TV technician for assistance.

In order to maintain compliance with FCC regulations, shielded cables must be used with

this equipment. Operation with non-approved equipment or this equipment. Operation with

non-approved equipment or unshielded cables is likely result in interference to radio and

TV reception. The user is cautioned that changes and modications made to the equipment

without the approval of the manufacturer could void the user’s authority to operate this

equipment.

FCC Statement

Technical Support

(818) 772-9100 (800) 545-6900

8:00 AM to 5:00 PM Monday - Friday, Pacic Time

Fax

(818) 772-9120

[email protected]

Web

http://www.gefen.com

Mailing Address

Gefen, LLC

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

Product Registration

Contacting Gefen Technical Support

• The Gefen Syner-G Software Suite is a free downloadable application from Gefen

that provides rmware upgrades for this product. Always make sure that the Wireless

for HDMI 5 GHz w/ Dual Inputs and Local Output is running the latest rmware.

• Obstructions such as walls and furniture and RF interference could reduce reception

distance.

• This product operates in the 5 GHz RF region, and features a specic number of

channels. Other 5 GHz transmitters, including WiFi routers, may be occupying the

same channels and may cause reception issues.

• Due to different transmission power levels, using this product with the Wireless for

HDMI 5 GHz (Gefen part no. EXT-WHD-1080P-SR) is not recommended.

• Using multiple Sender and Receiver units:

► US Models: Up to 8 Sender units can be registered per Receiver unit. Up

to 4 Sender/Receiver systems can be operated in the same environment,

simultaneously.

► EU Models: Up to 8 Sender units can be registered per Receiver unit. Up

to 2 Sender/Receiver systems can be operated in the same environment,

simultaneously.

► Each Sender and Receiver unit must placed at least 1 meter apart for optimum

performance. If additional Sender / Receiver pairs are to be used, each set of

units must be placed beyond the reception range (100 feet / 30 meters) of the

other Sender / Receiver pairs in order to prevent interference.

• This product is not compatible with the Wireless for HDMI Extender LR (Gefen part

no. GTV-WHD-1080P-LR) or the Wireless for HDMI Extender SR (Gefen part no.

GTV-WHD-1080P-SR).

Wireless for HDMI 5 GHz w/ Dual Inputs and Local Output is a trademark of Gefen, LLC.

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation

without prior written notice.

Operating Notes

This product uses UL listed power supplies.

Features and Packing List

Features

• Wireless extension of HDMI up to 100 feet (30 meters)

• Supports resolutions up to 1080p Full HD, up to 7.1 channels of LPCM digital audio,

and up to 5.1 channels of Dolby® and DTS® formats

• Transmits through obstacles - does not require line-of-sight

• Long Range performance makes it ideal for multi-room use

• IR Back Channel for source control with carrier frequency selector

• HDMI Features Supported

►CEC

►12-bit Deep Color

►3DTV pass-through

►HDCP pass-through

► Lip Sync

• Uncompressed High Denition A/V from source to display

• Less than 1 frame latency

• AES 128 Encryption

• Compatible with legacy DVI displays

• Sender Unit

►2 HDMI Inputs

►Local HDMI “Mirrored” Output

►IR Output port and included Emitter Array for source control

► Ideal for use with 2 sources in a xed home theater type installation

►Flexible mounting options: ¼-20 thread, wall mounting, shelf placement

• Receiver Unit

►IR Extender module included for hidden installations

► Small and compact form factor - can be installed behind the TV

►Flexible mounting options: ¼”-20 thread, wall mounting, shelf placement

• Handheld IR remote for easy setup and operation

• Firmware update via Mini-USB port using Gefen Syner-G™ software

• WHDI 1.0, FCC Part 15, IC, and ETSI-compliant

• Additional Sender units (Gefen part no. EXT-WHD-1080P-LR-TX) available separately

vii

Packing List

The Wireless for HDMI 5 GHz w/ Dual Inputs and Local Output ships with the items listed

below. The packing contents for each product are listed below. If any of these items are

not present in the box when you rst open it, immediately contact your dealer or Gefen.

EXT-WHD-1080P-LR

• 1 x Wireless for HDMI 5 GHz LR Sender Unit

• 1 x Wireless for HDMI 5 GHz LR Receiver Unit

• 2 x 5 ft. HDMI Cables (M-M)

• 1 x 5 ft. USB to Mini USB Cable

• 1 x 3 ft. USB to DC plug Cable

• 2 x 5V DC Power Supplies with changeable AC plugs

• 1 x IR Remote Control

• 1 x IR Emitter Array Cable

• 1 x IR Extender Module

• 4 x Screws and Wall Anchors - for wall-mounting the Sender and Receiver

• 1 x Quick-Start Guide

EXT-WHD-1080P-LR-TX

• 1 x Wireless for HDMI 5 GHz LR Sender Unit

• 1 x 5 ft. HDMI Cable (M-M)

• 1 x 3 ft. USB to DC plug Cable

• 1 x 5V DC Power Supply with changeable AC plugs

• 1 x IR Emitter Array Cable

• 2 x Screws and Wall Anchors - for wall-mounting the Sender

• 1 x Quick-Start Guide

Features and Packing List

1080P

HDCP

Deep Color Support

Up to 8

Senders

viii

Table of Contents

1 Getting Started

Introduction............................................................................................................ 2

Sender Unit ................................................................................................... 2

Receiver Unit................................................................................................. 5

IR Remote Control ........................................................................................ 7

Installing the Batteries................................................................................... 8

Installation ............................................................................................................. 9

Connection Instructions................................................................................. 9

Sample Wiring Diagram .............................................................................. 10

2 Basic Operation

The Linking Process............................................................................................ 14

Switching Sources............................................................................................... 16

Getting Source Information ................................................................................. 18

Setting the IR Frequency..................................................................................... 20

Using Multiple Sender Units................................................................................ 21

Registering Sender Units ............................................................................ 21

Selecting a Sender Unit .............................................................................. 26

Changing the Name of a Sender Unit ......................................................... 28

Removing Sender Units .............................................................................. 31

3 Appendix

Surface-mounting Instructions............................................................................. 36

LED Indicator Messages ..................................................................................... 37

Icon Messages .................................................................................................... 39

Supported Resolutions........................................................................................ 40

Specications ...................................................................................................... 41

Index.................................................................................................................... 43
