Geemarc CL1100 Manuel utilisateur

Telephone

AMPLIFIED DESK TELEPHONE

WITH VOLUME AND TONE CONTROL

TELEPHONE MULTIFONCTIONS AVEC REGLAGE DU

VOLUME ET DE LA TONALITE

CL1100

User guide / Notice d’utilisation

CAUTION:THIS TELEPHONE PRODUCT IS SPECIFI-

CALLY DESIGNED FOR PEOPLE WITH HEARING DIFFI-

CULTIES AND IS PROVIDED WITH A HANDSET EAR-

PIECE VOLUME CONTROL FOR INDIVIDUAL REQUIRE-

MENTS. DUE CARE MUST BE TAKEN BY ALL USERS

THAT THE HANDSET EARPIECE VOLUME CONTROL IS

SET TO THE LOWEST LEVEL ACCEPTABLE BY EACH

RESPECTIVE USER. CARE SHOULD THEREFORE BE

EXERCISED TO ENSURE THAT ANY NAIVE USERS ARE

ARE FAMILIAR WITH THIS REQUIREMENT.

ATTENTION: CE TELEPHONE PEUT ETRE DESTINE

AUX PERSONNESAYANT DES PROBLEMES D’AUDITION.

IL POSSEDE UN ECOUTEUR A VOLUME VARIABLE. A

LA PREMIERE UTILISATION, ASSUREZ VOUS QUE LE

BOUTON DE REGLAGE DU VOLUME SOIT POSITIONNE

SUR LA POSITION VOLUME MINIMUM. LES PERSONNES

MALE NTEND ANTES P OURR O NT PA R L A SU ITE

AUGMENTER LE VOLUME POUR L’ADAPTER A LEUR

AUDITION.

Now available to purchase from www.M2Cshop.com

INDEX

Description 4

Setting up

- Connecting the telephone 6

- Ringer settings 6

- Dialling types and grounding

(UK version) 8

- Time break recall switch 9

Volume and tone adjustment

- Receiving volume and tone 10

- Sending volume level adjustment 11

Using the phone

- Answering incoming call 12

- Making a call 12

- Last number redial 12

- Recall, * & # buttons 13

- Mute button 13

- Storing telephone numbers 13

- Dialling stored number 14

Guarantee 15

E F SOMMAIRE

Description 16

Installation

- Raccordements 18

- Réglage de la sonnerie 19

- Fréquence décimale/vocale

(Interrupteur Terre/Pulse/Tone)

Option pour l’Angleterre 19

- Interrupteur 300ms/100ms 20

Réglage du volume et de la tonalité

- Volume et tonalité de réception 21

- Réglage du volume d’émission 22

Utilisation

- Recevoir un appel 23

- Appeler 23

- Rappel du dernier numéro 23

- Touches R, * & # 24

- Fonction secret 24

- Mémoriser un numéro de téléphone 24

- Appel d’un numéro en mémoire 25

Garantie 26

2 3

Now available to purchase from www.M2Cshop.com

4 5

Tone reception

adjustment

Last number

redial

Memory storing key

Mute button

Flashing incoming ring

indicator

Direct

memory

buttons

Volume recep-

tion adjustment

Handset

cord

socket

Red light for tone

and volume

activation

Time break recall

button

Direct

memory

buttons

TONE/PULSE/

EARTH switch

(UK option)

Sending

level switch

Line cord

socket*

Time break recall

switch

(R=100ms/300ms)

Volume & Tone

adjustment ON/OFF

switch

Ringer level

adjustment switch

ToneVolume

(*) Classified TNV-3 according to EN60950 standard.

DESCRIPTION

Phonebook insert

card

DESCRIPTION DESCRIPTION

Now available to purchase from www.M2Cshop.com

SETTING UP

1 - CONNECTING THE TELEPHONE

1 - Connect the handset cord.

2 - Open the battery compartment by pulling back

the latch.

3 - Insert correctly 4 x AAA 1.5V alkaline batteries

(not supplied) in the battery compartment (*). Bat-

teries are required if you wish to increase the

ringer level up to 10 dB.

4 - Snap the battery door back in place.

5 - Connect the line cord to the socket (*).

(*) Classified TNV-3 according to EN60950 standard.

2 - RINGER SETTINGS

A switch located on the upper side allows the

ringer to be switched HI,LOW,OFF:

: Off,

: Low,

: Hi

SETTING UP

Your phone comes with the ringer switched to

«High» and the melody set to «6»:

Low Mid High

Melody 1 1 2 3

Melody 2 4 5 6 (by default)

Melody 3 7 8 9

If you don’t like the ringer melody, you can choose

a new one by changing the settings as per

instructions below:

- Lift the handset.

- Press button.

- Press # button.

- Press any of the 1 - 9 dial keys.

The new ringer settings will be activated with the

next incoming call.

Note: The ringer level will be increased up to 10

dB if you insert batteries into the battery

compartment.

Now available to purchase from www.M2Cshop.com

SETTING UP

4 -TIME BREAK RECALL SWITCH (300/100)

Check the Time Break Recall setting of your

CL1400. For the UK the Time Break Recall should

be set to 100 mS. It can be switched to 300 mS for

other locations or PBX’s.

SETTING UP

3 - DIALING TYPES AND GROUNDING

Switch ETR/PR/T is located on the upper side of

english type models. If you wish to connect your

CL1100 to a public UK/French switch-board (PBX),

move switch ETR/PR/T to position 3 (T). This will

ensure optimal compatibility of your phone with

most (99%) PBX.

Positions: 1 2 3

Position 1:

Pulse dialing. The Ris grounded. This option can

be used only within the UK in very special cases.

Position 2:

Pulse dialing. The Ris set according to the

determined adjustment (see «Time Break Recall

Setting for R Function» p.9).

Position 3:

Tone dialing. The Ris set according to the

determined adjustment (see «Time Break Recall

Setting for R Function» p.9).

P T

ETR R

If you are using your CL1100 with a

hearing aid, set your hearing aid to

“T” position.

Now available to purchase from www.M2Cshop.com

Adjust the TONE and VOLUME buttons to fit the

levels to your own hearing requirements.

2 - SENDING VOLUME LEVEL ADJUSTMENT

If your voice is quiet or called parties have difficulty

hearing you, you can increase the sending level

volume with the switch located on the upper side.

You can also decrease the sending volume if

required. Min Normal Maxi

TONE AND VOLUME ADJUSTMENT

TONE

Bass

+10db max

Treble

+10db max

Normal

VOLUME

0dB

+30db max

30dB ON

15dB OFF

15dB

TONE AND VOLUME ADJUSTMENT

1-RECEIVING VOLUME AND TONE

ADJUSTMENT

You can adjust the receiving volume and tone

according to your own hearing requirements.

The button allows extra volume and tone

functions to be activated or deactivated during the

conversation.

Tone and volume adjustment (15dB to 30dB) is

only activated when the switch located at the

upper side of your phone is set to ON. When this

button is set to OFF only the volume can be adjusted

from 0dB to 15dB.

When the function is activated, the red light of extra

receiving and tone function button is lit.

Note: When the tone (treble), earpiece volume and

sending levels are set to the maximum, whistling

may occur. If whistling occurs the sending level

settings should be decreased with the switch .

Now available to purchase from www.M2Cshop.com

USING THE PHONE

4 - RECALL, * & # BUTTONS

These are used with the new services provided on

digital exchanges. For details please contact your

network operator.

5 - MUTE BUTTON

If you wish to speak privately to someone else in

the room without your caller overhearing,press and

hold the button.You will still be able to hear the

callers but they cannot hear you during the mute

operation.To resume normal conversation, release

the button.

6 - STORING TELEPHONE NUMBERS

Your telephone CL1100 can store 12 direct

memories.

To store a number please follow instructions below:

- Lift the handset.

- Press button.

- Press M1, M2, ... M12 to locate the number.

12 13

USING THE PHONE

1 - ANSWERING INCOMING CALLS

- When an incoming call is received the phone will

ring and the incoming call indicator will flash. To

answer the call lift the handset and speak.

- On completion of the call, carefully replace the

handset in the cradle to release the line.

2 - MAKING A CALL

- Lift the handset.

- Await the dial tone and dial required number.

- On completion of the call, carefully replace the

handset in the cradle.

3 - LAST NUMBER REDIAL

- Lift the handset.

- Await the dial tone and press button.

- A previously dialled number will be automaticaly

redialled (not in use for memory numbers).

Now available to purchase from www.M2Cshop.com

GUARANTEE

From the moment your Geemarc product is purchased, Geemarc

guarantee it for the period of one year. During this time, all repairs

or replacements (at our option) are free of charge.Should you

experience a problem then contact our helpline or visit our website

at www.geemarc.com.The guarantee does not cover accidents,

negligence or breakages to any parts. The product must not be

tampered with or taken apart by anyone who is not an authorised

Geemarc representative.The Geemarc guarantee in no way limits

your legal rights.

IMPORTANT: YOUR RECEIPT IS PART OF YOUR GUARANTEE

AND MUST BE RETAINED AND PRODUCED IN THE EVENT

OF A WARRANTY CLAIM

Please note: The guarantee applies to the United Kingdom only.

Declaration : Hereby Geemarc Telecom SA declares that this product is in

compliance with the essential requirements and other relevant provisions of

the Radio and Telecommunications Terminal Equipment Directive 1999/5/EEC

and in particular article 3 section 1a, 1b and section 3.

Telephone connection : Voltages present on the telecommunication network

are classified TNV-3 (Telecommunication Network Voltage) according to the

EN60950 standard.

The telephone does not operate if the line current is lower than 18 mA.

For product support and help visit our website

at www.geemarc.com

telephone 01707 384438

or fax 01707 372529

GUARANTEEUSING THE PHONE

- Dial the number.

- Press again Button.

Numbers will be lost after few hours if you

disconnect your phone. Entering a new number in

the same location will automatically erase the

previous number.

7 - DIALING STORED NUMBERS

Pierre 01 64 57 .. ..

- Lift the handset and

await the dial tone

- Press the appropri-

ate location button

M1, M2... M12 and

the number stored in

this location will be di-

aled automatically.

To register your

stored phone num-

bers, use the index

located on the front of

your phone. Use this

table to prepare your

phone book.

Example:

14 15

Now available to purchase from www.M2Cshop.com

Autres manuels pour CL1100

Table des matières

Autres manuels Geemarc Téléphone

Geemarc

Geemarc amplidect 295 photo Manuel utilisateur

Geemarc

Geemarc Clearsound CL600 Manuel utilisateur

Geemarc

Geemarc Dallas 10 Manuel utilisateur

Geemarc

Geemarc Ampli1100 Manuel utilisateur

Geemarc

Geemarc AmpliCL100 Manuel utilisateur

Geemarc

Geemarc Jupiter 3 Manuel utilisateur

Geemarc

Geemarc CL50 Manuel utilisateur

Geemarc

Geemarc BDP400 Manuel utilisateur

Geemarc

Geemarc Ampli555 Manuel utilisateur

Geemarc

Geemarc CL100 Manuel utilisateur

Geemarc

Geemarc CL10+ Manuel utilisateur

Geemarc

Geemarc CL200+ Manuel utilisateur

Geemarc

Geemarc Ampli100VM Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

Geemarc

Geemarc CL1400 Manuel utilisateur

Geemarc

Geemarc AmpliPOWER 40 Manuel utilisateur

Geemarc

Geemarc AMPLIDECT 280 Manuel utilisateur

Geemarc

Geemarc CL210A Manuel utilisateur

Geemarc

Geemarc CL9000 Manuel utilisateur

Geemarc

Geemarc CL595 Manuel utilisateur

Geemarc

Geemarc CL8350 Manuel utilisateur

Geemarc

Geemarc AMPLI600 Manuel utilisateur

Geemarc

Geemarc Ampli455 Manuel utilisateur

Geemarc

Geemarc PhotoTEL Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur

Ericsson

Ericsson Dialog 3213 Manuel utilisateur
