Geemarc AmpliCL100 Manuel utilisateur

Multifunction telephone

Téléphone multifonctions

Teléfono multifunción

English P2

Français P20

Español P38

!!!User manual to read carefully before

start to use!!!

CAUTION: this telephone is specifically designed for the people

with hearing difficulties and is provided with a handset earpiece

volume control for individual requirements. Due care must be

taken by all users that the handset earpiece volume control is set

to the lowest level acceptable by each respective user. Care

should therefore be exercised to ensure that any naive users are

familiar with this requirement.

When using your telephone equipment, basic safety precautions

should always be followed to reduce the risk of fire, electric shock

and injury to person, including the following.

WARNING: To avoid the possibility of electrical shock, do not use

this product near water (For example, near a bathtub, wash basin,

kitchen sink or laundry tub, in a wet basement or near a swimming

pool);

WARNING: Avoid using the telephone during electrical storms.

There may be a remote risk of electric shock from lightning. If the

electrical storm is present in your immediate area, possibility of

electrical shock exists;

WARNING: Do not use the phone if you suspect a gas leak in the

area. The phone’s electrical contacts could create a spark, which

could ignite any heavy concentration of leaking gas.

English

Description ...................................................................4

Setting up ......................................................................6

1- Connecting the telephone ..........................................6

2- Ringer volume setting ................................................6

3- Tone/Pulse switch ......................................................7

4- Time break recall setting ............................................7

5- Wall mounting ............................................................7

Volume and tone adjustment ......................................9

1- Receiving volume and tone adjustment .....................9

2- Sending volume adjustment .....................................10

Using the phone .........................................................11

1- Answer a call ............................................................11

2- Making a call ............................................................11

3- Last number redial ...................................................11

4- Recall(FLASH), * & # buttons ..................................11

5- Mute button ..............................................................11

6- Storing telephone numbers ......................................12

7- Dialling stored number .............................................13

Safety informations ....................................................14

Regulatory compliance ..............................................15

Guarantee ...................................................................18

Index

1. Line socket.

2. Volume and tone adjustment ON/OFF switch.

3. 3 emergency numbers.(P1, P2, QuikDialCS™)

4. Reception tone adjustment.

5. Clip for wall mounting.

6. Reception volumen adjustment.

7. Handset cord socket.

8. Last number redial.

Description

9. Time break recall.

10. Memory storing.

11. Flashing incoming ring indicator.

12. Mute.

13. Direct memories.

14. Ring volume setting.

15. Sending volume setting.

16. Extra volume and tone adjustment.

17. Red light of tone/volume activation.

18. Handset cord.

19. Battery compartment.

20. Time break recall.

21. Dialling mode Pulse/Tone.

22. Memo card.

23. Holes for wall mounting.

Description

1 – Connecting the telephone

- Connect the handset cord (1).

- Open the battery compartment (2).

- Insert 4 alkaline batteries (type AAA 1.5V, not supplied) in

the comartment (*). Batteries are required if you wish to

increase the ringer level up to 10 dB (2).

- Snap the battery door back in place.

- Connect the line cord plug into the line socket on the rear of

the unit (*) (3).

- Connect the other end of the line cord into the wall PTT

socket (*) (3).

(*) Classified TNV-3 according to EN60950 standard.

2 – Ringer volume setting

A switch located on the right side allows the ringer to be

switched to Hi, Low or Off:

: Off,

: Low,

: Hi.

Note: The ring level will be increased of 10 dB if you insert

batteries.

Setting up

3 – Dialling mode (Tone/Pulse) settings

The Tone/Pulse switch is factory pre-set to Tone position. In

the UK, all telephone exchanges now use Tone (T) dialing. If

your phone does not dial out, it is probably being used from

an older private switch board (PBX). In this case, the

Tone/Pulse switch must be changed to Pulse (P).

4 – Time Break Recall setting (600/100)

Your phone works with a time break recall. It can be switched

to 600ms and 100ms.

5 – Wall mounting

To wall-mount your telephone, turn the “clip” (located in the

base unit, just below the ear piece).

This will ensure that the handset stays firmly in position.

Setting up

- Drill 2 holes in the wall (80mm apart).

- Insert the wall plugs and the screws leaving about 6 mm of

the screws projecting from the wall.

- Slide the telephone downwards to secure.

Setting up

Wall mount template

Screw

1 – Receiving volume and tone adjustment

You can increase the volume and adjust the receiving tone

according to your own hearing requirements.

The button allows extra receiving and tone functions to

be activated or not during the conversation.

When the function is activated, the red light of extra receiving

and tone function located near the button is lit.

Adjust the TONE and VOLUME buttons to fit the levels to

your own hearing requirements.

Volume and tone adjustment

VOLUME

TONE

Normal
