CONTENTS 1

INTRODUCTION 2

Unpacking the LH600 3

DESCRIPTION 4

INSTALLATION 7

Setting Up 7

Wall Mounting 8

USING THE LH600 10

Turn the LH600 On/Off 10

Volume Control 10

Tone Control 10

Telephone Use 10

Microphone SENSE Switch 10

Line Input Selector 11

Microphone Input Selector 11

TROUBLESHOOTING 12

SAFETY INFORMATION 13

GUARANTEE 14

RECYCLING DIRECTIVES 16

CONTENTS

Congratulations on purchasing your GeemarcTM LH600. This is a portable

induction loop system that is suitable for the home. It is easy to setup and

use and fits into any home environment with its sleek and inconspicuous

design. The sound quality of the LH600 is unparalleled and will bring great

pleasure during its everyday use.

This induction loop system allows a hearing aid user to listen to the TV, radio,

CD,ipod, telephone or any other audio device directly into the their hearing

aid via the telecoil ‘T’ setting. This means you can listen to one single audio

device with no other background noise interfering. Also, the volume can be

adjusted without affecting anyone else.

The system simply picks up sound from the audio device. This is done via a

microphone or a connection between the audio device and the amplifier.

The sound is fed into the amplifier. The amplifier passes the sound into the

loop cable (setup around the listening area). This loop transmits the sound

to the hearing aid set to the ‘T’ position.

Its is important that you read the instructions below in order to use your

GeemarcTM LH600 to its full potential. Keep this user guide in a safe place

for future reference.

Note: users of digital hearing aids must make sure their aids have

been programmed for use with the ‘T’ setting.

INTRODUCTION

Unpacking the LH600

When unpacking the LH600 you should find the following in the box:

•1 LH600 Amplifier Unit

•1 Power adaptor/charging Unit.

•1 Telephone line cord

•1 Telephone adaptor

•1 External microphone with 3m extension lead and lapel clip

•1 3.5mm stereo jack to RCA convertor

•1 2m audio cable with 3.5mm stereo plug

•1 SCART to RCA jack adaptor

•1 Loop Cable

•100 cable clips for the wall

•1 Wall Mount

•1 User Guide

INTRODUCTION

General Description

Top View

DESCRIPTION

Left View

Right View

DESCRIPTION

Volume

Power LED

Tone

MIC 1

MIC 2

Line 1

Line 2

MIC sense

Mic in

ut 2

Mic in

ut 1

udio in

ut 1

udio in

ut 2

Telephone input 1V DC supply

Connections for cable loop

Wall Mount Hanger

Wall Mount

DESCRIPTION

Setting Up

Connect Amplifier to the Sound Source

Place the amplifier near the sound source and connect the audio leads

between the sound source and the amplifier. This direct connection method

with leads gives the best results.

TV Connection:

For a TV with SCART connector audio output: connect the SCART

adaptor to the TV set; connect the RCA jack on the SCART adaptor using

the RCA convertor cable; connect the 3.5mm stereo cable to the RCA

convertor cable; connect the other end of the 3.5mm stereo cable to the unit

stereo jack of LINE 1 .

For a TV with RCA connector audio output: connect the RCA convertor

cable to the TV set; connect the 3.5mm stereo cable to the RCA convertor

cable; connect the other end of the 3.5mm stereo cable to the unit stereo

jack of LINE 1 .

For a TV with 3.5mm stereo jack audio output: connect the 3.5mm stereo

cable to the TV set; connect the other end of the 3.5mm stereo cable to the

unit stereo jack of LINE1 .

If you have another audio device you wish to connect, use the stereo jack of

LINE2 . You will have to purchase the extra audio leads.

You can test the connection between Line 1 and the loop by pushing the

LINE1 button . The indicator will light red to confirm. The same can

be done to test the connection between Line 2 and the loop. Simply press

the LINE2 button and the LINE 2 LED will light up red to confirm the

connection.

INSTALLATION

Telephone Connection:

Plug the supplied telephone cord into the TEL jack . The other end of

the cord should be connected to a telephone convertor adaptor. Push the

plug of the telephone convertor into the telephone wall socket.

Connect the Loop Wire

The unit comes with a 38 meters loop wire. Place the wire on the floor

following the wall edges so that the wire runs around the whole room,

starting and ending at the amplifier. Either tuck the wire under the carpet or

fix to the skirting board or wall using the clips provided. Place the loop wire

in the nail clip and hammer the nail clip to the wall in order to fix the loop wire

position. Have a space of 20cm between each nail clip. Any excess loop

wire can either be cut or tied up. The minimum length of loop wire is

10meters. Insert the two ends of the wire into speaker clip terminals

of the unit. Ensure that only bare wire and not the plastic insulation is

inserted.

Connect the Power Supply

Connect the plug of the supplied power adaptor into the DC jack . Plug

the other end of AC power adaptor into the mains wall socket.

Wall Mounting

To wall mount the LH600, drill two holes and insert two screws 40mm apart.

Leave about 5 mm of the screw projecting from the wall,. Guide the wall

mounting apertures of the wall mount over the screws and slide the wall

mount downwards.

Clip the LH600 unit onto the wall mount using the wall mount hanger found

on the base of the unit.

Caution: Ensure there are no electrical lines, water pipes etc. in the wall

where the holes are drilled

INSTALLATION

Connect the Microphone

If for some reason a direct connection is not possible a microphone can be

used to pick up the sound source. Or, a microphone can be used

simultaneously with line input to pick up background noise e.g. the doorbell.

A microphone can also be used for someone to speak directly into the loop

system whilst the hearing aid user is listening to a sound source.

Connect the external microphone wire provided into the 2.5mm stereo jack,

marked MIC1 on the unit. Push the button MIC1 to turn on the

microphone, the indicator will light red .

If you want to use a second microphone, use the 2.5mm stereo jack, marked

MIC2 on the unit. Push the button MIC2 to turn on the second

microphone and the indicator will light red .

INSTALLATION
