GE Appliances

Specification Created 2/00

JBP35WBWW—GE Spectra™30" Free-Standing QuickClean™Electric Range

Dimensions (in inches)

30

25

2-1/2

7-1/2

29-7/8

25-3/8*

47-5/8

44-7/16

2-1/2

Acceptable electrical

outlet area

Preferred electrical

outlet area

Roughed-in dimensions

*Dimension from wall to front of closed door handle is 27-3/4”.

R

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

For answers to your Monogram,

®

GE Profile Performance Series,™

GE Profile™or GE appliance questions, call

GE Answer Center®service, 800.626.2000.

A properly grounded branch circuit with a 3 prong grounding type receptacle is required for

GE ranges.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because terminals are not

accessible after range installation. See shaded area in drawing for location of electrical outlet box.

Recommended outlet locations allow range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent walls below

countertops. To reduce possibility of scorching of walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat, no-load heating element operation.

Installation Information: Before installing, consult installation instructions packed with product

for current dimensional data.

KW Rating

240V 11.7

208V 8.8

GE Appliances

Specification Created 2/00

JBP35WBWW—GE Spectra™30" Free-Standing QuickClean™Electric Range

OVEN

LIGHTSURFACE

UNITS

FRONTREARREARFRONT

OFFOFFOFFOFF

OVENCLEANING–

MOVEDOORLATCHTORIGHT. TURNOVENKNOBTO"CLEAN."

PREHEATED

OVENON

AUTOMATICOVEN

HOUR MIN

CLOCK

COOK

TIME

ON/OFF

START

TIME

ON/OFF

TIMER

ON/OFF

TEMPRECALL

Features and Benefits

• Super Large 5.0 Cu. Ft. Oven Capacity

• Self-Cleaning Oven

• Clean-Well™ Cooktop System

• Lift-Up Upswept Porcelain-Enameled Cooktop with Dual Support Rods

• Two 6" and Two 8" Deluxe Plug-in Calrod™ Heating Elements

• TrueTemp™ System with QuickSet III Oven Controls

• SmartLogic™ Oven Controls

• Removable One-Piece Drip Bowls

• Electonic Clock and Minute Timer

• Digital Temperature Display

• Six-Pass Power Bake Element

• 2 Oven Shelves

• Infinite Heat Controls

• Auto Oven Shut-Off with Override

• Audible Preheat Signal with Light

• Heating Element "On" Indicator Light

• Dual Bake Element

• Self-Clean Cool-Down Time Display

• Delay Clean Option

• Interior Oven Light

• Porcelain-Enameled Broiler Pan with Chrome-Plated Grid

• Frameless Glass Oven Door with Big View Window

• Color-Matched Removable Full-Width Storage Drawer

• Designer-Style Handle

• Model JBP35WBWW - White on white

• Model JBP35BBWH - White

• Model JBP35BBAD - Almond
