Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires that new

construction (not existing) utilize a 4-conductor connection to an electric range.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because terminals

are not accessible after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow range to be installed

directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent

walls below countertops. To reduce possibility of scorching walls, engineering

recommends a minimum of 1-1/2" spacing to allow for possible extended, high-

heat, no-load heating element operation.

Installation Information: Before installing, consult installation instructions

packed with product for current dimensional data.

KW Rating

240V 13.9

208V 10.4

Breaker Size

40 Amps†

PB970DP/TP

GE Profile™ 30" Free-Standing Electric Range

Specification Revised 5/09 221022

7-1/2

29-7/8

25-3/4*

Acceptable electrical

outlet area

Orient the electrical

receptacle so the length

is parallel to the floor.

*Dimension from wall to front of

closed oven door handle is 28-7/8.

fse_dual_cavity_install.eps

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Features and Benefits

• 6.6cu.ft.totalovencapacity-Largecapacityisidealforbigmeals

• Upperoven-Providestheidealspaceforcookingpizzasandsmalleritems

• 12"/9"/6"Tri-RingElement-Providesthreecookingareasinonefortheultimatein

cooking versatility

• 6”/9”PowerBoil™Element - Accomodates various-size pots or pans and 3,000 watts

of power speeds the boiling process

• WarmingZone-Provideslowheatcapabilityforfoods,makingmeal

coordination simple

• HiddenBakeOvenInterior-Concealsthelowerovenbakeelementtoeliminate

hard-to-reach areas that collect food and spills for easy cleaning

• PizzaMode-Providesidealcookingconditionsforpreparingfreshorfrozenpizzasat

the touch of a button

• Slowcookmode-Twoslowcookoptions–beefandpoultry–deliveridealconditions

for specific meals

• Self-CleanOven-Convenientlycleanstheovencavitywithouttheneedforscrubbing

• Self-CleanHeavy-DutyOvenRacks-Doublecoatedporcelain-enameledracksno

longer require hand cleaning

•ModelPB970DPBB–Blackonblack

•ModelPB970TPWW–Truewhite

PB970DP/TP

GE Profile™ 30" Free-Standing Electric Range

Specification Revised 5/09 221022

AKE

ROIL

TART

IZZA

12345

67890

pper

ven

ower

ven

ITCHEN

IMER

OOK

IME

VEN

IGHT

ELAY

TART

ARM

ELF

LEAN

LOCK

LEAR

AKE

ELF

LEAN

ROIL

ROOF

VEN

IGHT

LOW

OOK

LEAR

OOK

IME

ELAY

TART

OWER

VEN

PPER

VEN

ETTINGS

HI HI

EAR

RONT

EAR

RONT

ARMING

ONE

MED

PB970TPWW
