Specification Created 5/07 330517

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

*Dimension from the wall to the front of the closed door

handle is 29". Depth to the front edge of cooktop 25-1/4".

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 15A

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

JGBP89SEM

GE® 30" Free-Standing Self-Clean Gas Range

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

Features and Benefits

• Self-Clean Oven - Conveniently cleans oven cavity without the need for scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop

to accommodate large cookware and deliver ideal results

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval burner,

for cooking multiple foods at once

• PowerBoil™ 16,000 BTU Burner - Delivers 16,000 BTUs of forceful heat

for rapid boiling

• Lower Oven - Offers an additional 1.0 cu. ft. of capacity for convenient baking

from 150 degrees to 450 degrees

• QuickSet V Oven Controls - Feature an easy to use design that allows you

to set precise cooking temperatures

• Precise Simmer Burner - Delivers a low setting of 140 degrees, ideal for delicate

foods and sauces

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement

of pans between burners

• Model JGBP89SEMSS - Stainless steel

JGBP89SEM

PRECISESIMMER HIGH OUTPUT

LITE

CENTER

654

WARM

ZONE

200

250

300350400

450

LOWER OVEN

HEATING

BROIL LOCKED

COOKSTOPTIMER

CLEAN

CLOCK

ART

CLEAN

BAKE

DELA

DOOR

ime

ontrols

ven

ontrols

On/Off

LoMedHi

ET/

SetWarmingZone

Control

Lockout

12345

67 8 90

lear

ooking

ime

elay

tart

ven

ight

elf

lean

lock

itchen

imer

ake

arming

rawer

roil

tart

rueT

emp

Lower Oven

Double Oven

Specification Created 5/07 330517

JGBP89SEM

GE® 30" Free-Standing Self-Clean Gas Range
