GE JGBP85DEMWW - 30 In. Gas Ran Manuel

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

All GE ranges are equipped

with an Anti-Tip device.

The installation of this

device is an important,

required step in the

installation of the range.

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

*Dimension from the wall to the front of the closed door

handle is 28-1/4". Depth to the front edge of cooktop 25-1/4".

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 9A

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

JGBP85DEM

GE® 30" Free-Standing Self-Clean Gas Range

330593

Specification Revised 10/08

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

46-1/8

26-1/4*

46-3/8

36-1/4±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

*Dimension from wall

to front of closed

door handle is 29".

All 30" GE gas and electric range backguards

are 30-7/8" wide.*

Note: 30" ranges conform to U.L. requirements

for 0" spacing from adjacent walls below

countertops. To reduce possible scorching of

walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended,

high heat, no-load heating element operation.

*Except these models: JGBS07, JGBS04, JGBP90,

all GE Profile free-standing electric and gas

ranges

Fits most countertop backsplash applications.

Consult Use & Care Manual for detailed

installation instructions.

30-7/8"

JGBP85DEM

PRECISESIMMER

POWERBOIL

SETTINGINTENDEDFOR

USEWITHLARGERPOTS

POWER

BOIL

HIGHOUTPUT

BROILLOCKED

COOKSTOPTIMER

CLEAN

CLOCK

ART

CLEAN

BAKE

DELA

DOOR

ime

ontrols

ven

ontrols

On/Off

Lo Med Hi

ET/

SetWarmingZone

Control

Lockout

12345

67 8 90

lear

ooking

ime

elay

tart

ven

ight

elf

lean

lock

itchen

imer

ake

arming

rawer

roil

tart

rueT

emp

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• QuickSet V Oven Controls - Feature an easy to use design that allows you to set

precise cooking temperatures

• PowerBoil™Burner - Delivers 15,000 BTUs of forceful heat for rapid boiling

• Precise Simmer Burner - Offers a low setting of 600 BTUs, ensuring more temperature

control for simmering

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement of pans

between burners

• Dishwasher-Safe Grates - Feature durable construction for worry-free and effortless

cleaning and maintenance

• Warming Drawer - Convenient drawer keeps breads, desserts or just-cooked foods

warm and ready-to-serve

• Sealed Cooktop Burners - Eliminate the space between the burners and the cooktop

to help contain spills and boil over liquids, ensuring easy cleanup

• TrueTemp™System - Delivers even heat distribution and maximum oven control

• Frameless Glass Oven Door - Offers an easy-to-clean and stylish design that blends

seamlessly into existing cabinetry

• Model JGBP85DEMWW – White on white

• Model JGBP85DEMCC – Bisque on bisque

• Model JGBP85DEMBB – Black on black

JGBP85DEM

GE® 30" Free-Standing Self-Clean Gas Range

330593

Specification Revised 10/08
