GE JGB295DER Manuel

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

330525

Optional Gas Range Accessory Drip Pans for Sealed and Standard

Burner Models

(Available at additional cost)

To order these accessory drip pans, call toll-free 800-626-2002

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

All 30" GE gas and electric range backguards

are 30-7/8" wide.*

Note: 30" ranges conform to U.L. requirements

for 0" spacing from adjacent walls below

countertops. To reduce possible scorching of

walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended,

high heat, no-load heating element operation.

*Except these models: JGBS07, JGBS04, all GE

Profile free-standing electric and gas ranges

Fits most countertop backsplash applications.

Consult Use & Care Manual for detailed

installation instructions.

30-7/8"

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

46-1/8

26-1/4*

46-3/8

36-1/4±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

*Dimension from wall

to front of closed

door handle is 28-5/8".

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

46-1/8

26-1/4*

46-3/8

36-1/4±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

*Dimension from wall

to front of closed

door handle is 28-5/8".

Specification Revised 8/10

JGB295DER

GE® 30" Free-Standing Gas Convection Range

Features and Benefits

• Self-clean oven–Allows you to spare yourself from the trouble and effort it takes to

scrub the oven interior

• Super-large oven capacity–Remarkably large oven interior is ideal for holidays,

dinner parties and everyday family cooking

• Gas convection oven–Convection heating circulates the air to keep the heat

consistent, enhancing the baking or roasting results

• Heavy-cast, continuous grates–Matte-finish, connected cooktop grates provide a

study, uninterrupted surface that allows pots and pans to move easily

• Deep-recessed cooktop–Cooktop keeps spills, and everything else, contained in one

area that’s easy to wipe clean

• PowerBoil™ 16,000 BTU Burner–Delivers 16,000 BTUs of forceful heat for rapid boiling

• Precise Simmer burner–Allows for low, even heat distribution that is ideal delicate

foods and sauces

• TrueTemp™ oven system–This feature helps ensure the temperature you set is

the temperature you get, with less variance, to give you the baking and broiling

performance you desire

• Sealed cooktop burners–Burners are sealed to the cooktop to keep foods and liquid

contained on the cooktop, making cleaning painless

• QuickSet V Oven Controls–Feature an easy to use design that allows you to set

precise cooking temperature

• Model JGB295DERBB - Black on black

• Model JGB295DERWW - White on white

JGB295DER

Clear

Off

Bake Clock

Bake

Kitchen

Timer

Oven

Light

Self

Clean Cooking

Time

Start

True Temp

Oven Controls Time Controls

Broil

Control

Lockout

Delay

Start

12345

67890

Specification Revised 8/10 330525

JGB295DER

GE® 30" Free-Standing Gas Convection Range
