†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Created 4/07 322032

KW Rating

240V 11.7

208V 8.8

Breaker Size

40 Amps†

30

25

29-7/8

46-7/8

2-1/2

7-1/2

25-3/8

47-5/8

2-1/2

Acceptable electrical

outlet area

30_install_fse_ge.eps

Dimension from wall to front of

closed oven door handle is 27-3/4.

Dimension from wall to front of closed door handle is 27-3/4".

JBP24DM

GE®30" Free-Standing QuickClean™Electric Range

Specification Created 4/07 322032

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing

• Super-Large Oven Capacity - Provides an impressively large oven interior for cooking

more dishes and large meals at once

• QuickSet III Oven Controls - Feature an easy to use design that lets you set precise

cooking temperatures

• Coil Heating Elements - Provides consistent and even heat on the cooktop with a

plug-in element that is removable for easy cleaning

• Dual Element Bake - Alternates the upper broiling element and the lower baking

element for even heating and optimal baking results

• Big Hearth Window - Features an enhanced shape to add an elegant appearance

and make viewing trouble-free

• Chrome Drip Bowls - Contain minor spills and are removable for easy cleaning

• CleanWell™Cooktop System - Ensures spills are properly contained, while providing

convenient cleaning access

• Six Rack Positions - Provides flexibility and allows consumers to make the most of

available oven capacity

• Porcelain Upswept Cooktop - Features raised edges to help contain spills and make

clean-up easy

• Model JBP24DMWW – White on white (white door and white cooktop)

• Model JBP24DMBB – Black on black (black door and black cooktop)

JBP24DM

BROIL SELF

CLEAN

OVEN

LIGHT

CLOCK

TIME CONTROLS

OVEN CONTROLS

ONOFF

KITCHEN

LIGHT

ONOFF

BAKESTART

ON

CLEAR

OFF

JBP24DM

GE®30" Free-Standing QuickClean™Electric Range
