GE JP201CBSS Manuel utilisateur
Specification Revised 7/04
321305
JP201CBSS – GE Built-In Electric Cooktop
GE Appliances
Counter Installation (in inches)
Cooktop Dimensions (in inches)
Note:
Built-In Electric Cooktops require 1-1/2" free area
between the bottom of the cooktop and any combustible
material, i.e., shelving. Requires an 18" minimum from
cooktop to adjacent overhead cabinets. Units are furnished
with a 48” flexible armored cable.
Installation Information:
Before installing, consult
installation instructions [Pub. No. 31-0978] packed with
product for current dimensional data.
KW Rating
240V
3.4
208V
2.5
For answers to your Monogram,
®
For answers to your Monogram,
®
For answers to your Monogram,
GE Profi le
™
or
GE
®
appliance questions, visit our website at
GEAppliances.com or call GE Answer Center
®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
2" MIN.
clearance to
side wall
2" MIN.
clearance to
side wall
18" MIN.
to cabinet
2" to
rear wall
13" MAX.
depth
Cooktop
2-1/2"
Required
20-1/8"
16-1/8"
21-1/4" 16-5/8"
3"
Specification Revised 7/04
321305
JP201CBSS – GE Built-In Electric Cooktop
GE Appliances
JP201CB
2-23-00
Features and Benefits
• Compact cooktop – Smaller cooktop is ideal for 21" cooktop installations
• Coil heating elements – Provides consistent and even heat on the cooktop with a plug-in
element that is removable for easy cleaning
• Chrome drip bowls – Contain minor spills and are removable for easy cleaning
• Heating element “On” light – Illuminates when the cooking surface is activated
• Model JP202DWW – White
• Model JP201CBSS – Stainless steel
