GBC RLS32 Manuel utilisateur

RLM11

RLSM9

RLS32

RLX20

Mercury Large Ofﬁce Series

Instruction Manual

Speciﬁcations

RLM11

11 sheets

(11 sheets 207V~50Hz)

Continuous operation

230V / 50Hz

5.0A

RLS32

32 sheets

(28 sht 207V~50Hz)

Continuous operation

230V / 50Hz

8.0A

Models

Sheet Capacity

Duty Cycle

Volts / Hz

Amperage

Models

Sheet Capacity

Duty Cycle

Volts / Hz

Amperage

RLSM9

9 sheets

(9 sheets 207V~50Hz)

Continuous operation

230V / 50Hz

5.0A

RLX20

20 sheets

(20 sheets 207V~50Hz)

Continuous operation

230V / 50Hz

7.0A

IMPORTANT: ONLY INSERT ONE CD OR ONE CREDIT CARD AT A TIME.

QuickStart Guide

Illuminated Panel

Models: RLS32, RLX20 Models: RLM11, RLSM9

1 2 3 4

jad

Safety First

Shredders are safe to use as long as you take a few safety

precautions.

tEnsure the machine is plugged into an easily accessible

power outlet, and ensure the cable is not likely to trip up a

passer by.

t

invalidate the warranty. Please return to supplier.

tUnplug your shredder before moving it or when it is not in

use for an extended period of time.

tDo not operate with a damaged power supply cord or plug,

after it malfunctions, or after it has been damaged in any

manner.

tDo not overload electrical outlets beyond capacity as this can

tThe socket-outlet should be installed near the equipment and

shall be easily accessible.

t

the appropriate electrical supply.

tDo not use near water.

tDo not use aerosol dusters or cleaners.

tDo not spray anything into the shredder.

Although this shredder has been designed to be child safe, it is

not advised to operate the machine near children and pets.

We only recommend the use of Rexel branded

shredder lubricant to maintain optimum

performance and safety. GBC accepts no liability

for product performance or safety if anything

other than Rexel branded shredder lubricant is

used (Order Code 1760049).

WARNING: Do not use ﬂammable oil.

Only Rexel oil 1760049 is recommended.

Introduction

Thank you for choosing this shredder from GBC . We are sure it will serve you well, but please take a little time to study these

instructions to ensure you get the best out of your machine.

a Indicator Panel

b Door for Bin

c Wheels

d On/Off Button

e Reverse Button

f Auto Button

g Forward Button

h CD Slot

i Anti-jam Indicator

j Oil Reservoir Cap

1 Oiling in Operation

2 Oil Level

3 Door Open

4 Bin Full

Lights and Icons Explained

Decal Panel

1 2 3 4

Anti-Jam Indicator Auto Bin Full Door Open Oil Level Oiling/Auto

Colour of LED Red Green Blue Red Red Red Green

Power On/Off Switch

Auto Mode light light

Forward Mode light light

Reverse Mode light light

Mercury Anti-Jam Technology light light

Bin Full light light light

Door/Bin Open light light light

Self Cleaning of Cutters light light

Sleep Mode

Auto Oiling in Operation light light

Oil Level Indicator light light

Door Open Safety Function

If the door is opened during shredding as a safety precaution

the shredder will instantly stop, and the door open symbol on

simply press the auto button again (f).

Mercury Anti-Jam Technology

Mercury Shredders will only shred stacks of paper that are

within the shredders sheet capacity. For example, a shredder

with a capacity of 22 sheets will not allow the shredding of

more sheets than this.

Sensors in the paper feed area measure the thickness of

paper about to be shredded. The ability to shred or not is

communicated through red and green lighting. Green means

that the stack of paper is within the shredders sheet capacity

and OK to shred. Red means that you have too much paper,

remove some sheets in order to shred.

Given that you are unable to shred more sheets of paper

than the shredder is capable of shredding, paper jams are

prevented.

This prevents time wasted through reversing paper and

unblocking jams not to mention the mess it can create.

Rare Occasions of Jamming

In the unlikely event of the shredder jamming, use the reverse

function to unblock the shredder.

Alternating between the reverse and continuous forward

functions will help unblock the feed area.

Initial Setup

The shredder is designed to automatically lubricate the cutting

mechanism as required to ensure the product continues to

work to its maximum performance and to extend the product

open the oil reservoir cap on the head of the shredder (j) and

pour in the 60ml bottle of oil provided as standard. This is

to operate continuously for approximately 1 hour shredding

Auto button (f) for 5 seconds to start the pump and prime the

using a bottle of standard Rexel oil (1760049). The automatic

oiling operation lasts approximately 2 seconds and you

will hear the distribution pump during this time. Auto-oiling

operates after 15 minutes of shredding.

Shredder Control Panel

ReverseForwardAuto

Safety First

This means you should be careful because long hair can become

entangled in the cutting head.

This means don’t reach into the feed opening of the cutting head.

This means be careful of ties and other loose clothing which could

become entangled in the cutting head.

This means be careful of loose jewelry which could become

entangeld in the cutting head.

This means keep children away from shredder.

This means do not shred CD’s.

This means oil level.

This means oiling in operation.

This means do not shred credit cards.

Operation

1RLS32 & RLX20 only. After unpacking the product, pull

out the shredder bag frame and remove the CD shard

tray,which sits on top of the bag frame. Store this tray on

the bag frame as shown and use when you shred CD’s or

credit cards to separate waste for recycling. On the RLM11

and RLSM9 high security models, the CD tray can be left

permanently in position in the shredder.

bottle of oil provided*. Close the cap.

3Connect shredder to mains supply.

4Check that the on/off switch at the back of the machine is

swtiched to the ‘ON’ position.

5Press and hold down the Auto button (f) for 5 seconds to

start the pump and prime the system. Only required when

6To commence shredding, press the auto feed button. This

sets the shredder into auto mode.

7Insert paper to be shredded into the feed area. The

shredder will detect the paper and start automatically.

8If the shredder is left in auto mode for more than 2 minutes

without being used, the shredder will automatically turn

back to standby mode in order to save power.

9The shredder will automatically ‘wake up’ from sleep mode

when paper is inserted into the shredder mouth. There is no

need to press the Auto button (f).

* replacement oil bottle No. 1760049

CD and Credit Card Shredding

1A separate CD tray is provided to collect the shredded

CD shards. On the RLS32 and RLX20, ensure that this is

correctly mounted onto the standard shredder bag frame

before shredding CD’s or credit cards. The RLM11 &

RLSM9 models are supplied with a separate CD bin, which

should be disposed of separately to paper.

2Always shred CD’s and credit cards through the safety

guard slot (h). Only shred 1 credit card or 1 CD at a time.

3Empty the CD tray or CD bin after 8 credit cards or CD’s to

avoid waste spilling over into the paper waste bin.

RLS32 & RLX20 only. Remove the CD tray before

recommencing to shred paper and store on the bag frame

as shown.

RLS32 / RLX20 RLM11 / RLSM9

Guarantee

ACCO Brands warrants its products and their parts

against defects in materials and workmanship under normal

use for a period of 24 months from the original date of

purchase.

During this period we will repair or replace a defective product

or part subject to the following warranty conditions:

The warranty applies only to defects in materials and

workmanship under normal use and does not extend to

damage to the product or parts which result from:-

anyone other than an authorised ACCO Brands Europe

service centre.

accident, neglect, abuse or misuse owing to failure to

comply with the normal operating procedures for a product

of this type.

Nothing in this Warranty shall have the effect of excluding

the liability of ACCO Brands in respect of death and

personal injury caused by the negligence of ACCO Brands.

This Warranty is offered (subject to these terms and

conditions) in addition to, and does not affect your statutory

rights.

Additional Guarantee

ACCO Brands guarantees the cutting blades of the

shredder to be free from defects in material and workmanship

for 20 years from the date of purchase by the original

consumer.

* Please note that the cutter blades will be progressively worn

down by shredding fastened sheets (staples and paperclips)

- this is not covered in the warranty. With regards to CD

shredding, GBC large ofﬁce shredders have been designed to

shred up to 500 CDs during the warranty period. Excessive CD

shredding will wear the cutters and is not covered within the

warranty.

These conditions shall in all respects be governed and

construed in accordance with English Law and subject to the

exclusive jurisdiction of the English Courts.

Bin Full

When the bin is full the shredder will not function and the bin

full symbol will illuminate red.

When this happens you must empty the bin.

tOpen the door and slide out the waste sack support frame.

Carefully remove the waste sack from the frame.

Once the waste bag has been disposed of and replaced, close

the door and press the auto button to resume shredding.

Note: RLX20, RLM11, RLSM9 Models - Once the waste bag

has been reinserted and/or cabinet door has been closed, the

shredder will run in reverse for three seconds, stop for two

seconds and then forward for three seconds to clear away

any remaining paper from the cutter mechanism. This ‘self-

cleaning’ mechanism is additional jam prevention technology

from GBC.

Service

We recommend these machines are serviced every 6 -12

months by a GBC service engineer - see the back of this

booklet for the contact details of your local service centre.

Charges for service applies.

ACCO Brands Europe

Oxford House

Aylesbury HP21 8SZ

United Kingdom

www.accoeurope.com

Ref: CBT.6535

Issue: 1 (06/09)

ACCO Service Division

Hereward Rise, Halesowen, West Midlands, B62 8AN

Tel: 0845 658 6600, Fax: 0870 421 5576

www.acco.co.uk/service

ACCO France

Service Aprés-Vente

Tel: 0820 872 356, Fax: 03 80 68 60 49

[email protected]

ACCO Deutschland

Arnoldstrasse 5, 73614 Schorndorf, Germany

Tel: +49 7181/887-420, Fax: +49 7181/887-498

ACCO Iberia SL

Isaac Peral 19, 28820 Coslada (Madrid)

Tel: 91 669 9391, Fax: 91 672 07 11

ACCO Brands Italia Srl

Via Pietro Nenni 13, Settimo Torinese (TO)

Tel: +39 011 896 11 11, Fax: +39 011 896 11 13

[email protected]

ACCO Brands Benelux B.V.

Peppelkade 64, 3992AK Houten, Nederland/Les Pays-Bas

Tel: 0800-73362, Fax: 02-4140784

[email protected], www.accobenelux.be

ACCO Brands Benelux B.V.

Peppelkade 64, 3992AK Houten, Nederland/Les Pays-Bas

Tel: 0800-21132, Fax: 02-4140784

[email protected], www.accobenelux.be

ACCO Brands Benelux B.V.

Peppelkade 64, 3992AK Houten, Nederland/Les Pays-Bas

Tel: 030-6346060, Fax: 030-6346070

[email protected], www.accobenelux.nl

ACCO Brands Nordic AB

Makadamgatan 5, 254 64 Helsingborg, Sweden

Tel: +46 42 38 36 00, Fax: +46 42 38 36 10

[email protected]

XERTEC a.s.

U Továren, 770/1b, 102 00, Praha 10, Ceska Republika

Tel: +420 271 741 800, Fax: +420 271 743 143

www.xertec.cz

SERWIS ACCO

05-300 Mińsk Mazowiecki, Ul. Grobelnego 4, Polska

Tel: +48 25 758 11 90, Fax: +48 25 758 11 90

ACCO Hungária Kft

Budapest, Ócsai út 4., 1239, Hungária

Tel: +36 1 283 1645, Fax: +36 0 283 0928

Представительство компании

«АККО Дойчланд ГМБХ иКО. КГ»

Россия 105005, Москва, Денисовский пер., д.26

Те л : (495) 933-51-63, Факс: (495) 933-51-64

«Полиграфические системы»

ул. Набережно-Корчеватская, 78, г. Киев, 03035, Украина

Те л .: (+38) 044 252-7103, (+38) 044 252-7104

ACCO Österreich

Sallmann Bürotechnik GmbH, Schumacherstr.13, 5020 Salzburg

Tel: 0662 4345 160, Fax: 0662 4345 164

[email protected]

ACCO Schweiz

ABC Bürotechnik AG, Winkelbüel 4, 6043 Adligenswil

Tel: 041 375 6060, Fax: 041 375 6061

[email protected]

ACCO-Rexel Ltd

Clonshaugh Business & Technology Park, Clonshaugh, Dublin 17, Ireland

Tel: 01 816 4300, Fax: 01 816 4302

[email protected], www.accorexel.ie

Rexel Ofﬁce Products (PTY) Ltd

Crusher Road, Crown Ext.3, PO Box 102,

Crown Mines, Johannesburg 2025, South Africa

Tel: +27 (0) 11 837 7723

[email protected]

ACCO Brands Asia Pte Ltd

47 Ayer Rajah Crescent, #05-08/17, Singapore 139947

Tel: +65 6776 0195, Fax: +65 6779 1041

[email protected]

ACCO Brands Japan K.K.

14F Harmony Tower, 1-32-2 Honcho, Nakano-ku, Tokyo 164-8721

Tel: (81)-03-5351-1801, Fax: (81)-03-5351-1831

[email protected], www.accobrands.co.jp

ACCO Australia

Level 2, 8 Lord Street, Botany, NSW 2019

Tel: +61 2 9695 2574, Fax: +61 2 9700 0189

www.acco.com.au

Service

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GBC destructeur de papier

GBC

GBC Alpha Ribbon Manuel utilisateur

GBC

GBC 4500S-2 Manuel utilisateur

GBC

GBC GBC Shredmaster 75X Manuel

GBC

GBC ShredMaster Jam Free Series Manuel utilisateur

GBC

GBC Style Manuel utilisateur

GBC

GBC AutoFeed+ 60X Manuel utilisateur

GBC

GBC Mercury RDS2270 Manuel utilisateur

GBC

GBC MOMENTUM Manuel utilisateur

GBC

GBC ShredMaster 3550X Manuel

GBC

GBC SHREDMASTER 2240S Manuel utilisateur

GBC

GBC Shredmaster 6120S Manuel utilisateur

GBC

GBC Auto+ 100M Manuel utilisateur

GBC

GBC Shredmaster PRO 64C Manuel utilisateur

GBC

GBC GBC Shredmaster 80S Manuel

GBC

GBC CS50-59 Manuel utilisateur

GBC

GBC 750s Manuel utilisateur

GBC

GBC SHREDMASTER SM15-08 Manuel utilisateur

GBC

GBC Shredmaster 6160X Manuel utilisateur

GBC

GBC SHREDMASTER 1236SE Manuel utilisateur

GBC

GBC CX25-36 Manuel utilisateur

GBC

GBC Shredmaster 1130S Manuel utilisateur

GBC

GBC Shredmaster 1236S Manuel utilisateur

GBC

GBC Shredmaster 5570X Manuel

GBC

GBC Shredmaster 31SX Manuel utilisateur

Manuels destructeur de papier populaires d'autres marques

Swingline

Swingline STACK-AND-SHRED200X&200XL 60X Mode d’emploi

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Manuel utilisateur

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Manuel utilisateur

Rexel

Rexel Optimum AutoFeed+ 45X Manuel utilisateur

Martin Yale

Martin Yale 227284S1 Manuel utilisateur

Bonsaii

Bonsaii DocShred C223-A Manuel utilisateur

HSM

HSM Pure 740 max Manuel utilisateur

TRU RED

TRU RED TR-BMC20A Manuel utilisateur

Fellowes

Fellowes 50S Manuel utilisateur

Gude

Gude GH 2600 P Manuel utilisateur

Ativa

Ativa DQ80M Manuel utilisateur

Q-Connect

Q-Connect Q8CC Manuel utilisateur

Fellowes

Fellowes POWERSHRED C-325CI Manuel utilisateur

Olivetti

Olivetti Privacy 5000C Guide de démarrage rapide

UNITED OFFICE

UNITED OFFICE UAV 190 A1 Manuel utilisateur

Dahle

Dahle paperSAFE 22022 Manuel utilisateur

Formax

Formax OnSite FD 87 Manuel utilisateur

GEHA

GEHA Home & Office S7 CD Manuel utilisateur
