USER MANUAL

Triple IR Flame Detector

Information

F-Guard-IR3-HDTriple IR HDFlame Detector User Guide

The owner or authorized user of a valid copy of this manual may reproduce this publication to learn to

use the specified equipment. No part of this publication may be reproduced or transmitted for

commercial purposes, such as selling copies of this publication or for providing paid-for support services.

The Gastech logo isa trademark of GASTECH AUSTRALIA PTY LTD,registered inthe U.S. and other

countries.

Every effort has been made toensure that the information in this manual is accurate. However,

GASTECH AUSTRALIA PTY LTD is not responsible for any inaccuracy or omission in this document. The

information inthis document issubject tochange without notice.

Legal Notice

Hardware, software or documentation is forbidden to be reproduced, transmitted, transcribed, stored in

a retrieval system or translated into any language or computer language, in any form or by any means.

While great efforts have been made toassure the accuracy andclarity of this document, GASTECH

AUSTRALIA PTY LTD assumes noliability resulting fromanyomissions in this document, or misuse of

the information obtained herein. The information inthis document has been carefully checked andis

believed tobe entirely reliable with all of the necessary information included.

GASTECH AUSTRALIA PTY LTD reserves the right to make changes to any products described herein to

improve reliability, function, or design, andreserves the right torevise this document and make

changes from time to time in content hereof with noobligation tonotify any persons of revisions or

changes. GASTECH AUSTRALIA PTY LTD does not assume any liability arising out of the application or

any use of any product orcircuit described herein; neither does itconvey a license under its patent

rights orthe rights ofothers.

For more information & technical support: info@gastech.com· support@fg-detection.com iii

76-M-6010-02-02

F-Guard IR3 HD User Manual

Table of Contents

1Introduction.................................................................................................................... 1

Key Features........................................................................................................................1

Model Number Description ..................................................................................................2

Internal tests .......................................................................................................................2

Product Overview ................................................................................................................3

Accessories..........................................................................................................................4

Installation ..................................................................................................................... 7

General Considerations........................................................................................................7

Preparations for Installation...............................................................................................10

Required Tools...................................................................................................................10

Certification Instructions....................................................................................................10

Mounting the Tilt Mount....................................................................................................11

Mounting the detector.......................................................................................................12

Electrical Wiring.................................................................................................................13

Current Output (0-20mA) Wiring ........................................................................................16

4 Wire Relay Connection ....................................................................................................17

RS-485 Communication Network........................................................................................18

Cabling Recommendations.................................................................................................18

Earth/Ground Regime ........................................................................................................18

3Configuration options ................................................................................................... 20

Sensitivity..........................................................................................................................21

Ultra-Fast Detection...........................................................................................................21

Alarm Delay.......................................................................................................................21

Alarm Latch .......................................................................................................................21

Enable Pre-Alarm 0-20mA ..................................................................................................21

Enable dirty window warning 0-20mA ................................................................................21

Auxiliary Relay...................................................................................................................22

Window Heater .................................................................................................................22

For more information & technical support: [email protected] iv

F101V0020.06

F-Guard IR3 HD User Manual

Video Settings....................................................................................................................22

Modbus Address ................................................................................................................22

Manual BIT – Alarm Output Test (Full loop test)..................................................................22

4Operation ..................................................................................................................... 23

Output Signals ...................................................................................................................23

Testing...............................................................................................................................24

Flame Simulator.................................................................................................................24

5Maintenance ................................................................................................................ 25

Cleaning Procedure............................................................................................................25

6Troubleshooting............................................................................................................ 26

7Servicing ....................................................................................................................... 27

8Communicator Software ............................................................................................... 27

9Specifications................................................................................................................ 28

Fire Detection ....................................................................................................................28

Video Functionality ............................................................................................................28

Electrical Specifications ......................................................................................................28

Outputs .............................................................................................................................29

Mechanical Specifications ..................................................................................................29

Environmental Specifications .............................................................................................29

Product Labelling ...............................................................................................................30

Approvals ..........................................................................................................................33

Electromagnetic Compatibility ...........................................................................................33

10 Performance.............................................................................................................. 34

F-Guard-IR3-HD-ASX1, F-Guard-IR3-HD-ASX2(Standard model)...........................................34

False Alarm Immunity ........................................................................................................36

11 Ordering Information................................................................................................. 37

12 Warranty................................................................................................................... 38

Appendix A.......................................................................................................................... 39

For more information & technical support: [email protected] v

F101V0020.06

F-Guard IR3 HD User Manual

List of Figures

Figure 1 - Front view of the F-Guard-IR3-HD...............................................................................3

Figure 2 - Rear view ofthe F-Guard-IR3-HD................................................................................3

Figure 3 - Tilt mount.....................................................................................................................4

Figure 4 - Weather Cover.............................................................................................................4

Figure 5 - Pole Mount...................................................................................................................5

Figure 6 - AirShield .....................................................................................................................5

Figure 7 - Flame Simulator Kit......................................................................................................6

Figure 8 - F-Guard-FSIM-IR3 Flame Simulator Front View .............................. ............................6

Figure 9 - Horizontal Field of View ...............................................................................................8

Figure 10 - Vertical Field of View .................................................................................................8

Figure 11: Tilt Mount Base - Plate View .....................................................................................11

Figure 12: Tilt mount base – Side View......................................................................................12

Figure 13 - Detector on Tilt Mount – Side View ..........................................................................13

Figure 14 – Terminal View .........................................................................................................14

Figure 15 – Source 4-Wire Scheme ...........................................................................................16

Figure 16 – Sink 4-Wire Scheme................................................................................................16

Figure 17 – Source 3-Wire Scheme ...........................................................................................17

Figure 18 – Sink 3-Wire Scheme................................................................................................17

Figure 19 - 4Wire Relay Connection .........................................................................................17

Figure 20: RS-485 Networking ...................................................................................................18

List of Tables

Table 1: Terminal connections ..................................................................................................15

Table 2: Detector Configuration Options ...................................................................................20

Table 3: Sensitivity levels..........................................................................................................21

Table 4: Output Signals.............................................................................................................23

For more information & technical support: [email protected] 1

76-M-6010-02-02

F-Guard IR3 HD User Manual

1 Introduction

The F-Guard-IR3-HD (F-Guard-IR3-HD) will detect fires and explosions extremely

quickly allowing preventative action to be initiated rapidly to help minimize the

consequences!

•Detection within 40 milliseconds of fireballs or explosions

•Standard fire is detected within 1.5s from 100 ft. (30m), 4.1s from 230 ft. (70m) and

9.0s from 262 ft. (80m).

The detector provides fast response, high performance and reliable detection of all types of

hydrocarbon fires (visible and non-visible). The detector addresses slow-growing fires as

well as the fast eruption of fire using improved triple IR (IR3) technology. It operates in all

weather and light conditions with the highest immunity to false alarms.

In addition, the detector provides high-definition (HD) video output of the monitored area

with clear imaging of a fire event and personnel at distances up to 100 ft (30m). This allows

the rescue team to be aware of the exact situation before entering the hazardous area. The

detector automatically records a video of a fire event (1-minute pre- and up to 3 minutes

post-alarm initiation). These features, along with the built-in event logger, provide additional

means to study the cause and development of fire events.

As an option, the colour HD camera can be replaced with a near IR camera if the greater

flame definition is needed.

Key Features

•Extreme sensitivity - up to 260ft (80m) for a 1 ft2(0.1m2) N-heptane pan fire.

•1.5 second detection time - for 1 ft2(0.1m2) N-heptane pan fire at up to 100 ft. (30m) distance.

•Ultra-fast detection mode - detection within 40 milliseconds for fireballs or explosions.

•HD video output with Automatic HD video recording of fire events. Data/Event logger: Alarms,

faults and other relevant events are logged to non-volatile memory.

•Option: Improved false alarm immunity in high CO2 applications, like aircraft hangars or

helidecks.

•Option: Improved speed of response - (0.5s) for enclosed spare protection, like automotive

applications in compliance with NFPA 33 or printing presses and conveyors.

•Built-in-Test (BIT) - Automatic (and manual) self-test of window cleanliness and the overall

operation of the detector.

•Window heater to avoid condensation and icing.

•Tilt mounting bracket for accurate detector positioning.

For more information & technical support: [email protected] 2

76-M-6010-02-02

F-Guard IR3 HD User Manual

Model Number Description

Model No is defined as follows:

F-Guard-IR3-HD - A SX X

Standard with RGB camera

Like model 1 with Near IR camera

Like model 1, but recommended for Hangar, Helideck,

Petroleum Loading Racks with RGB camera

Like model 3 with Near IR camera

Like model 1 but with a fast response mode that is designed

for, but not limited to, automotive spray paint applications

where compliance with 0.5s response (per NFPA 33) is

needed. With RGB camera

M25

¾” NPT

1.2.1 Enhanced performance options

•Option 3: Increased false alarm immunity in presence of hot CO2. Recommended for

Hangar, Helideck and Petroleum Loading Racks

•Option 5: Design for, but not limited to, automotive spray paint applications where

compliance with 0.5s response (per NFPA 33) is needed

Internal tests

During normal operation, the flame detector performs self-tests of its optics, electronics and

software. These include a periodic BIT (Built-In-Test) in which the sensors and window

cleanliness are tested. Any detected fault is indicated as shown in Table 4 (in section 4.1).

During the “Dirty Window” fault the detection sensitivity is significantly reduced, while “Fault”

refers to critical faults which prevent flame detection.

For more information & technical support: [email protected] 3

76-M-6010-02-02

F-Guard IR3 HD User Manual

Product Overview

FIGURE 1-FRONT VIEW OF THE F-GUARD-IR3-HD

FIGURE 2-REAR VIEW OF THE F-GUARD-IR3-HD

For more information & technical support: [email protected] 4

76-M-6010-02-02

F-Guard IR3 HD User Manual

Accessories

1.5.1 Mounting Bracket

The detector should be mounted using the

stainless-steel tilt mount part number 85-

6000-TMO-HD. This allows the detector to be

securely attached to a wall, pole or other

solid surface using appropriate fixings. See

sections2.5 and 2.6 for further details.

FIGURE 3-TILT MOUNT

1.5.2 Weather Cover

The weather cover P/N 85-6000-WC-SS-

protect the detector from extreme weather

conditions such

as heat, rain and snow

FIGURE 4-WEATHER COVER

For more information & technical support: [email protected] 5

76-M-6010-02-02

F-Guard IR3 HD User Manual

1.5.3 Pole mount

The pole mount enables the detectors tobe

installed with its tilt mount brackets. The pole

mount kit we supply is suitable for 2-inch or 3-

inch poles. Part number F-Guard-PMA-S23.

FIGURE 5-POLE MOUNT

1.5.4 Air shield

The air shield P/N F-Guard-ASD-S02 allows

the installation of flame detectors in harsh

weather conditions where they may be

exposed to dust, sand, and other particulate

matter. The connection point can be mounted

in the 3, 9 or 12 o’clock locations.

•

Air pressure source: Clean, dry, and oil-

free

air

•

Pressure: 2-3 bar /30-45 psi

•

Fitting: 7/16”—20UNF-2A

•

Operation temperature: -55°C to +85°C / -

67°F to +185°F

FIGURE 6-AIR SHIELD

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GasTech Capteur de sécurité

GasTech

GasTech D-GUARD2R Manuel utilisateur

GasTech

GasTech GTF300-AQ Manuel utilisateur

GasTech

GasTech ToxiPro Manuel utilisateur

GasTech

GasTech G-SHIELD-FIRE Manuel utilisateur

GasTech

GasTech Cannonball3 Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
