Garmin Nüvi 760 Manuel d'instructions

Starry Liu, 11643, 2010/09/28

Quick Start Manual

nüvi®760

personal travel assistant

Starry Liu, 11643, 2010/09/28

EN-2

E N

What’s in the Box?

nüvi GPS device and vehicle suction cup

mount.

Vehicle power cable to provide external

power.

USB cable to connect the nüvi to your

computer. Your nüvi connects to your

computer as a mass storage device.

Dashboard disk to mount the suction cup

mount on your dashboard.

Ways to Charge Your nüvi

Use the vehicle power cable.•

Use the USB cable.•

Use an optional AC adapter.•

SD card slot

Headphone/audio

out jack

Microphone

Power key:

slide to the left to turn the unit on/off;

slide to the right to lock the screen

SpeakerGPS antenna

Mini-USB connector

Serial number

External antenna connector

Starry Liu, 11643, 2010/09/28

EN-3

E N

Step 1: Mount the nüvi

1. Plug the vehicle power cable into the power

connector on the right side of the cradle.

2. Snap the cradle onto the suction cup arm.

3. Clean and dry your windshield and the

suction cup with a lint-free cloth. Remove

the clear plastic from the suction cup. Place

the suction cup on the windshield.

4. Flip the lever back, toward the windshield.

5. Fit the bottom of your nüvi into the cradle.

6. Tilt the nüvi back until it snaps into place.

7. Plug the other end of the vehicle power

cable into a power outlet in your vehicle.

Your unit should turn on automatically if it is

plugged in and your vehicle is running.

Cradle

Power cable

Suction cup mount

Starry Liu, 11643, 2010/09/28

EN-4

E N

Step 2: Congure the nüvi

To turn on your nüvi, slide the Power key

to the left. Follow the on-screen instructions.

Step 3: Acquire Satellites

Go outdoors to an open area, out of garages,

and away from tall buildings. Stop your

vehicle, and turn on the nüvi. Acquiring

satellite signals may take a few minutes.

The bars indicate GPS satellite

strength. When one bar is green, the nüvi has

acquired satellite signals. Now you can select

a destination and navigate to it.

Step 4: Use the nüvi

BA C D

E F

G H I

AGPS satellite strength.

BBluetooth

technology status.

CBattery status.

DCurrent time; touch to change time settings.

ETouchtondadestination.

FTouch to view the map.

GTouch to make a call when connected to a

compatible mobile phone (nüvi 710, 760,

and 770 only).

HTouch to adjust the volume.

ITouch to use the tools such as media

players, settings, and Help.

Finding Points of Interest

1. Touch Where to > Points of Interest.

2. Select a category and a sub-category.

3. Select a destination, and touch Go.

To enter letters contained in the name, touch

Where to > Points of Interest > Spell Name.

To search for a location in a different area,

touch Where to > Near.

Singapore postal search

Where to> Address > Spell city/postal code

*For singapore region only

Starry Liu, 11643, 2010/09/28

EN-5

E N

Viewing the Main Pages

Touch View Map to open the Map page. The vehicle icon shows your current location.

Touch the map and drag to view different parts of the map. Touch anywhere on the map; an

arrow appears pointing at the object.

After you touch Go, the Map page opens. Your route is marked with a magenta line. As you

travel, your nüvi guides you to your destination with voice prompts, arrows on the map, and

directionsatthetopoftheMappage.Acheckeredagmarksyourdestination.Ifyoudepart

from the original route, your nüvi recalculates the route and provides new directions.

Touch to save your

current location.

Map Page while Navigating a Route

Touch Arrival or Speed to

open the Trip Information.

Touch Turn In to view the

Next Turn.

Touch the text bar to open the Turn List.

Touch to zoom out. Touch to zoom in.

Touch Menu to return to

the Menu page.

Turn List Next TurnTrip Information

Garmin

and nüvi

are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries.

These trademarks may not be used without the express permission of Garmin. Windows

is a registered

trademark of Microsoft Corporation in the United States and/or other countries. Mac

is a registered trademark of

AppleComputer,Inc.TheBluetooth

wordmarkandlogosareownedbytheBluetoothSIG,Inc.andanyuseof

such marks by Garmin is under license.

Starry Liu, 11643, 2010/09/28

EN-6

E N

Adding a Via Point

1. With a route active, touch Menu on the

map, and touch Where to.

2. Search for the via point (extra stop).

3. Touch Go.

4. Touch Add as Via Point to add this stop

before your destination.



TIP: To add more than one stop, edit

the current route. Touch Where to >

Routes.

Using Hands-Free Features

Hands-free phone features are available only if

your nüvi and your compatible mobile phone

have Bluetooth wireless technology. Not

all phones support all the hands-free phone

features the nüvi provides. To use the hands-

free features, you must pair your phone and

the nüvi.

Pairing Your Phone

1. Conrmthatyourphoneissupportedby

the nüvi. (See www.garmin.com/bluetooth.)

2. From the Menu page, touch Tools >

Settings > Bluetooth.

3. Touch the Add button.

4. Enable your phone’s Bluetooth component

and enable Find Me/Discoverable/Visible

mode. These settings might be in a

Bluetooth, Connections, or Hands-free

menu.

5. Touch OK on the nüvi.

6. Select your phone, and touch OK.

7. Enter the nüvi’s Bluetooth PIN (1234) in

your phone.

Calling a Number

1. Touch Phone > Dial.

2. Enter the number, and touch Dial.

3. To end the call, touch > End Call.

Receiving a Call

When you receive a call, a message appears on

the nüvi. Touch Answer.

Starry Liu, 11643, 2010/09/28

EN-7

E N

Using Call Waiting

Ifyougetacallwaitingcall,thenüvidisplays

a message. Touch Answer.Therstcallisput

on hold.

1. During the call, touch > Switch To.

2. Touch End Call to hang up; this does not

disconnect the call on hold.

Using the FM Transmitter

Before using the FM transmitter in your area, see

the FM transmitter legal notice in the owner’s

manual.

You can listen to your nüvi audio on your

vehicle’s FM stereo speakers. From the Menu

page, touch Volume > FM Trans >Enable

FM Transmitter.IfyouareusinganFM

trafcreceiver,touchAuto Tune, and tune

your stereo to the same channel.

Loading Files on Your nüvi

Connect the USB cable to the mini-USB

connector on the nüvi and to an available USB

port on your computer. Your nüvi’s internal

memory and SD card appear as removable

drives in My Computer on Windows

computers, and as mounted volumes on Mac

computers.Copyandpastelesfromyour

computer into the nüvi drives/volumes. When

youarenishedtransferringles,clickthe

Eject icon or drag the volume icon to

the Trash. Unplug your nüvi.

Listening to MP3 Files

LoadMP3lestotheinternalmemoryorSD

card.

Touch Tools > Media Player. Touch Source

to open the music player. Touch Browse.

Touch a category. To play the entire category

from the beginning of the list, touch Play All.

Toplayaspecicsong,touchthetitle.

To create, edit, and listen to playlists, touch

Browse > Playlist.

Starry Liu, 11643, 2010/09/28

EN-8

E N

Locking Your nüvi

1. Touch Tools > Settings > Security.

2. Touch the button below Garmin Lock.

3. Enter a 4-digit PIN and drive to a security

location.



NOTE: IfyouforgetyourPINand

your security location, you must

send your nüvi to Garmin to get

it unlocked. You must also send a

valid product registration or proof of

purchase.

Resetting the nüvi

Ifthenüviscreenstopsfunctioning,turnthe

nüvioffandonagain.Ifthisdoesnothelp,

slide the Power key to the left and hold for

8 seconds. Turn the nüvi back on. The nüvi

should operate normally.

More Information

For more information about your nüvi, touch

Tools > Help. You can download the latest

version of the owner’s manual from

www.garmin.com. For information about

accessories, go to http://buy.garmin.com or

contact your Garmin dealer.

Starry Liu, 11643, 2010/09/28

MA-9

M A

Apa dalam Kotak?

Alat GPS nüvi dan pelekap cawan

kenderaan.

Kabel kuasa kenderaan untuk membekalkan

kuasa luar.

Kabel USB untuk menyambung nüvi ke

computer anda. Nüvi anda menyambung ke

computer anda sebagai peranti storan massa.

Cakera Papan Pemuka untuk melekapkan

pelekap cawan ke atas papan pemuka anda.

Cara untuk Mengecas nüvi Anda

Guna kabel kuasa kenderaan.•

Guna kabel USB.•

Guna penyesuai AC opsyenal.•

Slot kad SD

Bicu fon kepala/

audio

Mikrofon

Kunci Kuasa:

seret ke kiri untuk menyalakan atau

memadamkan unit;

seret ke kanan untuk mengunci skrin

Pembesar suaraAntena GPS

Penyambung USB-

mini

Nombor siri

Penyambung antena luar

Starry Liu, 11643, 2010/09/28

MA-10

M A

Langkah 1: Lekapkan nüvi

1. Sambungkan kabel kuasa kenderaan

ke penyambung kuasa pada tepi kanan

pemegang.

2. Detapkan pemegang ke atas pelekap

cawan.

3. Bersih dan keringkan cermin depan dan

pelekap cawan anda dengan kain tanpa

lin. Keluarkan plastik cerah dari pelekap

cawan. Letakkan pelekap cawan di atas

cermin depan.

4. Flipkan tuil sehingga ia diterbalikkan ke

arah cermin depan.

5. Pasangkan bawah nüvi anda ke

pemegang.

6. Songsangkan nüvi sehingga ia muat

dengan baik.

7. Sambungkan hujung kabel kuasa

kenderaan satu lagi ke punca kuasa dalam

kenderaan anda. Unit anda harus menyala

secara automatik jika ia disambung ke

punca kuasa dan kenderaan anda sedang

berjalan.

Pemegang

Kabel kuasa

Pelekap cawan

Autres manuels pour nüvi 760

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Garmin GPS

Garmin

Garmin eTrex 30x Manuel d'instructions

Garmin

Garmin inReach Team Tracking Manuel utilisateur

Garmin

Garmin DĒZL OTR810 Manuel utilisateur

Garmin

Garmin Cessna Caravan G1000 Manuel utilisateur

Garmin

Garmin StreetPilot C580 - Automotive GPS Receiver Manuel utilisateur

Garmin

Garmin Gpsmap 430 - marine gps receiver Instructions de montage

Garmin

Garmin Cessna Caravan G1000 Manuel

Garmin

Garmin CamperVan Manuel utilisateur

Garmin

Garmin dezl 760LMT Manuel d'instructions

Garmin

Garmin GPSMAP 620 Manuel utilisateur

Garmin

Garmin Edge 305CAD - Cycle GPS Receiver Guide de référence

Garmin

Garmin DEZL OTR800 Manuel utilisateur

Garmin

Garmin Nuvi 750 - Automotive GPS Receiver Guide de référence

Garmin

Garmin GPSMAP 8X10 Manuel utilisateur

Garmin

Garmin GTN 725 Manuel utilisateur

Garmin

Garmin A4BVGB01 Series Manuel utilisateur

Garmin

Garmin GPSMAP 4000 Series Manuel utilisateur

Garmin

Garmin GPSMAP 76 series Manuel utilisateur

Garmin

Garmin GPSMAP 60CS Manuel utilisateur

Garmin

Garmin nuvi 2515 Manuel d'instructions

Garmin

Garmin GPS 12CX Manuel utilisateur

Garmin

Garmin GPSmap 585 Plus Manuel utilisateur

Garmin

Garmin GIA 63 Manuel utilisateur

Garmin

Garmin Alpha 100 Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur

Kenwood

Kenwood DNN9330BT Manuel utilisateur

Safelet

Safelet Indra Manuel utilisateur

Bushnell

Bushnell 360100 Manuel utilisateur

Geneq

Geneq SXBlue Manuel utilisateur

ORIGO

ORIGO ED308 Manuel utilisateur

Garmin nüvi 760 Manuel d'instructions

Manuels GPS populaires d'autres marques
