Garmin nuvi 2250LT Manuel d'instructions
nüvi
®
2200 series
quick start manual
for use with these nüvi models:
2200, 2240, 2250
2 nüvi2200SeriesQuickStartManual
Getting Started
WARNING
See the Important Safety and Product
Information guide in the product
box for product warnings and other
important information.
When using your device for the rst
time, complete the following tasks.
1. Mount the device (page 2).
2. Connect the device to vehicle
power (page 3).
3. Register the device (page 5).
4. Check for updates.
• Software updates (page 5).
• Free map update (page 5).
5. Download the full owner’s manual
(page 5).
Mounting Your Device
Notice
Before mounting the device, see
the Important Safety and Product
Information guide for information
about laws pertaining to windshield
mounting.
1. Remove the clear plastic from the
suction cup.
2. Clean and dry your windshield
and the suction cup with a lint-free
cloth.
3. Press the suction cup to the
windshield.
4. While pressing, ip the lever back
toward the windshield.
nüvi2200SeriesQuickStartManual 3
5. Snap the mount
➊
onto the
suction cup arm
➋
.
➊
➋
6. Fit the bottom of your device into
the mount.
7. Tilt your device back until it
snaps into place.
Connecting the Device
to Vehicle Power
WARNING
This product contains a lithium-ion
battery. To prevent the possibility of
personal injury or product damage
caused by battery exposure to
extreme heat, remove the device from
the vehicle when exiting or store it
out of direct sunlight.
Charge your device before using it on
battery power.
1. Plug the vehicle power cable into
the mini-USB connector
➊
on the
back of the device.
➊
4 nüvi2200SeriesQuickStartManual
2. Plug the other end of the vehicle
power cable into a power outlet in
your vehicle.
3. If you are using a trafc receiver
in Europe, connect the external
antenna to the trafc receiver and
secure it to the windshield using
the suction cups.
After the device has been connected
to vehicle power, the following
should occur.
• The device turns on.
• The device acquires satellite
signals. When at least one of the
bars is green, your device has
acquired satellite signals.
NOTE: The device may need a
clear view of the sky to acquire
satellite signals.
• The device charges as you drive.
in the status bar indicates the
status of the internal battery.
About myDashboard
You can use myDashboard to register
your device, check for software and
map updates, access manuals, contact
product support, and more.
For more information, go to www
.garmin.com/dashboard.
Setting Up myDashboard
1. Connect the USB cable to the
USB connector on the device.
2. Connect the USB cable to the
USB port on your computer.
3. Double-click to open the
myDashboard Web page.
NOTE: If does not open, or
you are using Windows 7 or a
Mac® computer, go to www
.garmin.com/agent.
4. Follow the on-screen instructions.
nüvi2200SeriesQuickStartManual 5
Registering the Device
1. From myDashboard, click
Register Now.
2. Follow on-screen instructions.
3. Keep the original sales receipt, or
a photocopy, in a safe place.
Updating the Software
1. Open myDashboard (page 4).
2. Register the device (page 5).
3. Under Software Updates, click
Update Now.
4. Follow the on-screen instructions.
nüMaps Guarantee™
Your device is eligible for one
free map update within 60 days of
acquiring satellites while driving with
your nüvi. You are not eligible for
the free map update if you register
by phone or wait longer than 60
days after the rst time you acquire
satellites while driving with your
nüvi. For more information, go to
www.garmin.com/numaps.
Updating Maps
1. Open myDashboard (page 4).
2. Register the device (page 5).
3. Under Map Updates, click Update
Now.
4. Follow the on-screen instructions.
Downloading the Owner’s
Manual
The owner’s manual for your device
is available on the Garmin Web site.
1. Open myDashboard (page 4).
2. Register the device (page 5).
3. Click Manuals.
A list of the product manuals in
several languages appears.
4. Click Download next to the
manual for your device.
5. Click to save the le to your
computer.
6 nüvi2200SeriesQuickStartManual
Device Overview
➊
➋
➊
Power key
➋
microSD™ card slot
Using the Power Key
Press and quickly release the
Power key to view additional
options.
• Touch and drag the scroll bar
to adjust screen brightness.
• Touch Power Off to turn off
your device.
• Press and hold the Power key
to reset the device.
• Press and quickly release the
Power key to exit the menu.
About Points of Interest
The detailed maps loaded in your
device contain points of interest,
such as restaurants, hotels, and auto
services.
Finding a Point of Interest by
Category
1. From the Main menu, touch
Where To? > Points of Interest.
2. Select a category.
3. If necessary, select a subcategory.
4. Select a destination.
5. Touch Go!.
Touch > Save to save the
location to a Favorites folder on
the device. Use Favorites to save
the location of your workplace,
home, and other common
destinations.
nüvi2200SeriesQuickStartManual 7
6. If necessary, select an option.
• Touch Drive to calculate a
route you will navigate by
driving.
• Touch Walk to calculate a
route you will navigate by
walking.
• Touch Public Transit to
calculate a route that combines
public transit and walking.
NOTE: You must have
cityXplorer™ maps loaded to
navigate using public transit.
Go to www.garmin.com to
purchase cityXplorer maps.
Main Menu
➊
➋➌
➍ ➐➎ ➏
• Touch
➊
to select a transportation
mode.
• Touch
➋
to nd a destination.
• Touch
➌
to view the map.
• Touch
➍
to stop a route.
• Touch
➎
to detour a route.
• Touch
➏
to adjust the volume.
• Touch
➐
to open the menu of
tools and settings.
8 nüvi2200SeriesQuickStartManual
Your Route on the Map
Notice
The speed limit icon feature is for
information only and does not replace
the driver’s responsibility to abide
by all posted speed limit signs and to
use safe driving judgment at all times.
Garmin will not be responsible for
any trafc nes or citations that you
may receive for failing to follow all
applicable trafc laws and signs.
➊ ➋
➌
➏
➐
➍ ➎ ➑➒
Your route is marked with a magenta
line on the map. If you depart from
the original route, your device
recalculates the route. A speed limit
icon could appear as you travel on
major roadways.
• Touch
➊
to view the next turn.
• Touch
➋
to view the turn list.
• Touch
➌
to zoom in and out.
• Touch
➍
to return to the Main
menu.
Touch and hold to return to the
Main menu.
• Touch
➎
to change the data eld.
• Touch and drag
➏
to view a
different area of the map.
• Touch
➐
to view the Where Am
I? page.
• Touch
➑
to view the trip
computer.
• Touch
➒
to change the speed limit
if the speed limit icon shown on
the map is incorrect.
nüvi2200SeriesQuickStartManual 9
Using myTrends
As you drive with the device on,
myTrends™ gathers information that
allows the device to predict when
you are traveling to a common
destination, like your workplace or
home. When myTrends is activated,
the destination and estimated time of
travel will appear in the navigation
bar on the map.
myTrends only works for locations
that are saved as Favorites (page 6).
When myTrends information
appears in the navigation bar,
touch the navigation bar to view
route information.
About the Transportation
Modes
Automobile mode
Pedestrian mode
Routes are calculated differently
based on your transportation mode.
For example, in Automobile mode,
estimated time of arrival is calculated
using the speed limit of the roads on
the route. Pedestrian mode calculates
time of arrival based on walking
speed.
Changing Your Transportation
Mode
1. From the Main menu, touch the
transportation mode icon.
2. Select a mode.
3. Touch Save.
10 nüvi2200SeriesQuickStartManual
About Trafc
Notice
Garmin is not responsible for the
accuracy or timeliness of FM Trafc
information.
Some models can receive FM
Trafc Message Channel (TMC)
trafc content. The FM TMC trafc
receiver, which is integrated in the
vehicle power cable, is included in
some packages. The FM TMC trafc
subscription is automatically enabled.
For information about trafc receivers
and coverage areas, go to www
.garmin.com/trafc.
Receiving Trafc
Information
The vehicle power cable and the
device must be in data range of
an FM station transmitting trafc
information.
1. Connect the trafc receiver to an
external power source.
2. Connect the trafc receiver to the
device.
NOTE: Heated (metallized)
windshields could degrade the
performance of the trafc receiver.
Trafc on Your Route
When calculating your route, the
device examines the current trafc
and automatically optimizes the
route for the shortest time. If a severe
trafc delay occurs on your route
while you are navigating, the device
automatically recalculates the route.
You might still be routed through
trafc if no better alternative routes
exist.
