Garmin Nuvi 1690 Manuel d'instructions

nüvi®1690

quick start manual

01102291

2 nüvi 1690 Quick Start Manual

Looking at Your nüvi

See the Important Safety and Product

Information guide in the product box for

product warnings and other important

information.

Mini-USB

connector

Power button:

Press to turn the nüvi on and off.

microSD

™

card slot

Microphone

Using the Main Menu

➊

Touch to nd a destination.

➋

Touch to view the map.

➌

Touch to make a call when

connected to a compatible

mobile phone.

➍

Touch to adjust the volume.

➎

Touch to use tools such as

settings, help, and weather.

➊ ➋

➌ ➍ ➎

➊ ➋

➌ ➍ ➎

nüvi 1690 Quick Start Manual 3

Using the Main Menu

Toolbar

➋ ➌ ➍ ➎➊ ➏ ➐

➊

GPS signal status. Touch

and hold to view satellite

information.

➋

Bluetooth®technology status.

Touch to change Bluetooth

settings.

➌

Usage mode indicator. Touch to

select a usage mode.

➍

Current time. Touch to change

time settings.

➎

Current temperature. Touch

and hold to view weather

information.

➏

nüLink! services signal status.

➐

Battery status.

Setting Up Your nüvi

Before mounting the nüvi, see the Important

Safety and Product Information guide

for information about laws pertaining to

windshield mounting

Mounting your nüvi

1. Remove the clear plastic from the

suction cup. Place the suction

cup on the windshield.

2. Flip the lever back toward the

windshield.

3. Snap the cradle onto the suction

cup arm.

4. Plug the vehicle power cable into

the back of the cradle.

Suction cup arm

Cradle

Vehicle power cable

4 nüvi 1690 Quick Start Manual

5. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

6. Fit the bottom of your nüvi into

the cradle.

7. Tilt your nüvi back until it snaps

into place. Your unit should turn

on automatically if it is plugged in

and the vehicle is running. Follow

the on-screen instructions.

WARNING: This product contains a lithium-

ion battery. To prevent injury, remove the unit

from the vehicle when exiting or store it out of

direct sunlight.

Acquiring Satellites

1. Go outdoors to an open area,

away from tall buildings and trees.

2. Turn on your nüvi.

Acquiring satellite signals can take a

few minutes. The satellite icon

indicates signal status. When at least

one of the lines is green, your nüvi

has acquired satellite signals.

Finding Points of

Interest

1. Touch Where To? > Points of

Interest.

2. Select a category and a

subcategory.

3. Select a destination, and touch

Go!.

4. If necessary, touch Start to

navigate the route.

To enter letters contained in the

name, touch Where To? > Points of

Interest > Spell Name.

nüvi 1690 Quick Start Manual 5

To search for a location in a different

area, touch Where To? > Near.

Following Your Route

Your route is marked with a magenta

line. As you travel, your nüvi guides

you to your destination with voice

prompts, arrows on the map, and

directions at the top of the map. If

you depart from the original route,

your nüvi recalculates the route.

Touch and drag the map to view a

different area of the map. A speed

limit icon could appear as you travel

on major roadways.

➊ ➋

➌

➍➎

➏

➐

➊

Touch to view the Next Turn or

Junction View page.

➋

Touch to view the Turn List.

➌

Touch and to zoom in

and out.

➍

Touch to return to the Main

menu.

➎

Touch to view the Trip

Computer.

➏

Touch to view the Where Am I?

page.

➐

Touch to change the data eld.

Adding a Stop

1. While navigating a route, touch

> Where To?.

2. Search for the extra stop.

3. Touch Go!.

4. Touch Add as Via Point to

add this stop before your nal

destination.

6 nüvi 1690 Quick Start Manual

Taking a Detour

1. While navigating a route, touch .

2. Touch Detour or Recalculate.

Using nüLink! Services

Your nüvi comes with a subscription

to Garmin nüLink! services,

which allow you to receive current

information on weather, fuel prices,

ight times, and more.

For more information on nüLink!

services, touch Tools > Help, or refer

to the nüvi 1690 Owner’s Manual at

www.garmin.com.

NOTE: You may not be able to

receive current data when you are in a

remote location.

Finding a Destination with

Google™Local

NOTE: Not available in all areas.

Local search enables you to search

for the most up-to-date location

information.

In addition to searching by spelling

the name of a location, you can also

search for a specic category of

location, like hair salon or art gallery.

1. Touch Where To? > Google

Local.

2. Select a category.

3. Select a subcategory.

4. Select a destination.

5. Touch Go!.

nüvi 1690 Quick Start Manual 7

Using Trafc

NOTE: Garmin is not responsible

for the accuracy of the trafc

information.

NOTE: Not available in all areas.

Your nüvi can receive trafc

information through your nüLink!

subscription. Your device must

be receiving a signal from

nüLink! services to receive trafc

information.

The trafc icon changes color

to indicate the severity of trafc

conditions on your route or on the

road you are currently traveling. If

a severe trafc delay occurs on your

route while you are navigating, the

nüvi automatically recalculates the

route.

Using Hands-free

Features

To use the hands-free features, you

must pair your phone and your nüvi.

To pair and connect, your phone

and the nüvi must be turned on and

within 33 ft. (10 m) of each other.

Pairing Your Phone

1. Enable the Bluetooth component

on your phone.

2. On your nüvi, touch Tools >

Settings > Bluetooth.

3. Touch the button below

Bluetooth, and touch Enabled >

OK.

4. Touch Add Device >OK.

5. Select your phone, and touch OK.

6. Enter the Bluetooth PIN (1234)

for your nüvi in your phone.

8 nüvi 1690 Quick Start Manual

Calling a Number

1. Select Phone > Dial.

2. Enter the number, and touch Dial.

3. To end a call, touch > End

Call.

Receiving a Call

When you receive a call, the

Incoming Call window opens.

Touch Answer to answer the call.

Touch Ignore to ignore the call.

Options for Charging

Your nüvi

Connect the vehicle power cable

to the mount while the nüvi is in

the mount.

Connect the USB cable.

Connect an AC adapter (available

on some nüvi models).

•

Using the Power Button

1. Press and quickly release the

Power button to view additional

options:

Touch and to adjust

the screen brightness.

Touch Lock Screen to

prevent accidental screen

touches.

Touch Power Off to turn off

your nüvi. You can also turn

off the nüvi by holding the

Power button for 2 seconds.

2. Press and quickly release the

power button to exit the menu.

•

nüvi 1690 Quick Start Manual 9

Resetting Your nüvi

If your nüvi stops functioning, reset

your nüvi by pressing and holding

the Power button for 10 seconds.

Securing Your nüvi

1. Ensure that you are at your

security location and that your

nüvi is receiving satellite signals.

2. Touch Tools > Settings >

Security.

3. Touch the button below Garmin

Lock.

4. Enter a four-digit PIN.

5. Touch Set.

NOTE: If you forget your PIN and

your security location, you must

send your nüvi to Garmin to get

it unlocked. You must also send a

valid product registration or proof of

purchase.

Registering Your nüvi

Go to http://my.garmin.com to access

the latest services for your Garmin

products. From the myGarmin™Web

site, you can register your Garmin

device, download the latest map

updates, and subscribe to online

services.

1. Go to http://my.garmin.com, and

click Register.

2. Follow the online instructions

to install myGarmin Agent

™

and

10 nüvi 1690 Quick Start Manual

Updating the Software

1. Connect the nüvi to your

computer using the mini-USB

cable. The AutoPlay menu opens.

2. Double-click to open the

myGarmin Agent Web page. If the

AutoPlay menu does not open, or

you are on a Mac

computer, go

to www.garmin.com/agent.

3. Follow the on-screen instructions.

After you have installed myGarmin

Agent, you will be prompted to

open myDashboard each time you

connect your nüvi to your computer.

myDashboard checks for current

software updates and provides

additional information about your

nüvi.

nüMaps Guarantee™

To receive one free map update

(if available), register your nüvi

at http://my.garmin.com within 60

days of acquiring satellites while

driving with your nüvi. You are not

eligible for the free map update if

you register by phone or wait longer

than 60 days after the rst time you

acquire satellites while driving with

your nüvi.

More Information

For more information about your

nüvi, select Tools > Help. Download

the latest version of the owner’s

manual from www.garmin.com.

For information on accessories, go

to http://buy.garmin.com or contact

your Garmin dealer.

Autres manuels pour nuvi 1690

Table des matières

Autres manuels Garmin GPS

Garmin

Garmin GHC 50 Manuel utilisateur

Garmin

Garmin Foretrex 401 - Hiking GPS Receiver Manuel utilisateur

Garmin

Garmin nüvi 2555LMT Manuel utilisateur

Garmin

Garmin Mobile 10 Manuel d'instructions

Garmin

Garmin GPS 120 Manuel utilisateur

Garmin

Garmin GPS 500 Manuel utilisateur

Garmin

Garmin Oregon 200 - Hiking GPS Receiver Guide de référence

Garmin

Garmin nuvi 785 Manuel d'instructions

Garmin

Garmin Trail Guide Manuel utilisateur

Garmin

Garmin GPSMAP 496 Manuel utilisateur

Garmin

Garmin AERA 660 Manuel d'instructions

Garmin

Garmin Street Pilot 2720 Manuel utilisateur

Garmin

Garmin REACTOR 40 MECHANICAL Manuel utilisateur

Garmin

Garmin GPSMAP 700 Series Manuel utilisateur

Garmin

Garmin GPS III Plus Manuel utilisateur

Garmin

Garmin Apollo NMC 2001 Manuel utilisateur

Garmin

Garmin GPSMAP 67i Manuel d'instructions

Garmin

Garmin Drivesmart 55 Manuel utilisateur

Garmin

Garmin approach X40 Manuel utilisateur

Garmin

Garmin Zumo 500 Manuel utilisateur

Garmin

Garmin GPSMAP 536 Manuel utilisateur

Garmin

Garmin nuvi 350 Manuel du propriétaire

Garmin

Garmin GPSMAP 3005C Manuel utilisateur

Garmin

Garmin NUVI 300 SERIES Guide de référence

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur

Kenwood

Kenwood DNN9330BT Manuel utilisateur

Safelet

Safelet Indra Manuel utilisateur

Bushnell

Bushnell 360100 Manuel utilisateur

Geneq

Geneq SXBlue Manuel utilisateur

ORIGO

ORIGO ED308 Manuel utilisateur

Garmin nuvi 1690 Manuel d'instructions

Manuels GPS populaires d'autres marques
