Garmin GPS Kit Manuel utilisateur

owner’s

manual

eTrex

personal navigator

GARMIN International, Inc.

1200 East 151

Street, Olathe, Kansas 66062, U.S.A.

GARMIN (Europe) Ltd.

Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9AQ, U.K.

GARMIN (Asia) Corporation

No. 68, Jangshu 2

Road., Shijr, Taipei County, Taiwan

www.garmin.com

Part Number 190-00205-00 Rev. A

GARMIN International, Inc.

1200 East 151st Street, Olathe, Kansas 66062 U.S.A.

Tel. 913/397.8200

Fax 913/397.8282

GARMIN (Europe) Ltd.

Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9AQ, U.K.

Tel. 44/1794.519944

Fax 44/1794.519222

GARMIN (Asia) Corporation

No. 68, Jangshu 2nd Road., Shijr, Taipei County, Taiwan

Tel. 886/2.2642.8999

Fax 886/2.2642.9099

be reproduced, copied, transmitted, disseminated, downloaded or stored in any

storage medium, for any purpose without prior written consent of GARMIN

Corporation. GARMIN Corporation hereby grants permission to download a single

copy of this manual onto a hard drive or other electronic storage medium to be

viewed for personal use, provided that such electronic or printed copy of this

manual contains the complete text of this copyright notice and provided further that

any unauthorized commercial distribution of this manual is strictly prohibited.

Information in this manual is subject to change without notice. GARMIN

Corporation reserves the right to change or improve its products and to make

changes in the content without obligation to notify any person or organization of

such changes. Visit the GARMIN website for current updates and supplemental

information concerning the use and operation of this and other GARMIN products.

Website address: www.garmin.com

GARMIN is a registered trademark and eTrex is a trademark of GARMIN Corpora-

tion and may not be used without the express permission of GARMIN Corporation.

April 2000 Part Number 190-00205-00 Rev. A Printed in Taiwan

Introduction

On Your Mark...

Let the Fun Begin

fun

(noun):

1. A source of enjoyment, amusement, or

pleasure.

2. Enjoyment; amusement: have fun at the

party.

3. Playful, often noisy, activity.

We don’t know about the noise, but fun and simplicity

is what the eTrex is all about. To get the most out of your

new eTrex, take the time to read through this Owner’s

Manual to understand the operating features of the unit.

This manual has been designed to provide all that you

need to know to operate your eTrex.

eTrex Registration

Help us better support you by completing your

on-line registration today!

Why should you register your eTrex?

• Notification of Product Updates

• Notification of New Products

• Lost or Stolen unit tracking

Connect to our website (www.garmin.com) and look

for the Product Registration link on the home page.

Thanks for choosing the GARMIN eTrex. If you have

any questions or comments regarding the use of the eTrex

you can visit our website or contact our Customer Service

Department M-F, 8:00-5:00 CST (except holidays) at

1-800-800-1020.

If you have previously

registered your GARMIN

product purchase using a

mail-in registration card, we

invite you to reregister using

our NEW on-line system.

Many services provided by

our new product registration

system are now being

automated and reregistering

your purchase ensures you

the best possible support from

GARMIN.

Table of

Contents

Introduction

Introduction ......................................................................... 1-8

Getting Started ................................................................... 9-17

Reference Section .................................................................. 18

Map Page Options ................................................................. 18

Pointer Page Options ............................................................. 19

Menu Page Selections ............................................................ 20

Mark Waypoint Page ............................................................. 21

Review Waypoint Page .......................................................... 22

Nearest Waypoints ................................................................ 23

Routes .............................................................................. 24-26

Track Logs ........................................................................ 27-28

Setup Page ....................................................................... 29-30

Display and Units Pages ........................................................ 31

Map Datums ......................................................................... 32

Units of Measure .............................................................. 33-34

Interface Page ........................................................................ 35

System Page .......................................................................... 36

Demo Mode .......................................................................... 37

Appendix A: Specifications .................................................... 38

Appendix B: What is GPS? .................................................... 39

Appendix C: Reception Tips ............................................. 40-41

Appendix D: Time Offset Chart ............................................. 42

Appendix E: Wiring Diagram ................................................. 43

Appendix F: Troubleshooting ................................................ 44

Appendix G: FAQ’s ........................................................... 45-46

Appendix H: Index ........................................................... 47-49

Warranty ............................................................................... 50

WARNING: If you choose to use the eTrex in a vehicle,

it is the sole responsibility of the owner/operator of the eTrex

to secure the GPS unit so that it will not cause damage or

personal injury in the event of an accident. Do not mount

the eTrex over airbag panels or in a place where the driver

or passengers are likely to have an impact with it in an acci-

dent or collision.

WARNING: If you choose to use the eTrex in a

vehicle, it is the sole responsibility of the operator of the

vehicle to operate the vehicle in a safe manner, maintain

full surveillance of all driving conditions at all times, and

never become distracted by the eTrex to the exclusion of

safe operating practices. It is unsafe to operate the eTrex

while you are driving. Failure by the operator of a vehicle

equipped with an eTrex to pay full attention to operating

the vehicle and road conditions while the vehicle is in

motion could result in an accident or collision with

property damage and personal injury.

CAUTION: IT IS THE USER’S RESPONSIBILITY TO

USE THIS PRODUCT PRUDENTLY. THIS PRODUCT IS

INTENDED TO BE USED ONLY AS A TRAVEL AID

AND MUST NOT BE USED FOR ANY PURPOSE

REQUIRING PRECISE MEASUREMENT OF DIREC-

TION, DISTANCE, LOCATION, OR TOPOGRAPHY.

CAUTION: The Global Positioning System (GPS) is

operated by the government of the United States, which is

solely responsible for its accuracy and maintenance. The

system is subject to changes which could affect the

accuracy and performance of all GPS equipment.

Although the eTrex is a precision electronic NAVigation

AID (NAVAID), any NAVAID can be misused or misinter-

preted and, therefore, become unsafe.

Warnings and

Cautions

Introduction

Remove the batteries from

your eTrex if you don’t

expect to use it for several

months. Be sure to

observe the proper

polarity when inserting

the batteries. Follow the

battery manufacturer’s

instructions on the proper

care and handling of the

batteries.

Introduction

FCC Compliance

Statement

The eTrex complies with Part 15 of the FCC limits for

Class B digital devices. This equipment generates, uses,

and can radiate radio frequency energy and, if not

installed or used in accordance with the instructions may

cause harmful interference to radio communications.

There is no guarantee that interference will not

occur in a particular instance. If this equipment does

cause harmful interference to other equipment, try to

correct the problem by relocating the equipment.

Consult an authorized GARMIN dealer or other

qualified service technician if the problem cannot be

corrected. Operation is subject to the following condi-

tions: (1) This device cannot cause harmful interference,

and (2) this device must accept any interference received,

including interference that may cause undesired

operation.

The eTrex does not contain any user-serviceable

parts. Repairs should be made only by an authorized

GARMIN service center. Unauthorized repairs can void

the warranty.

Introduction

eTrex Features

The eTrex is a six ounce, 12 channel, hand held GPS

receiver. It has a built-in GPS antenna and only five user-

buttons. All buttons are located on either side of the unit,

allowing for simple, one-handed operation that won’t

obstruct your view of the display. It runs for 22 hours on

two AA batteries in battery save mode.

In addition to determining your location, the eTrex

will create, name and save a location (as an electronic

waypoint) in its memory, allowing you to navigate back

to this point any time you want. And once you start

moving, your GPS provides other data, like speed,

direction of movement, time and distance to destination,

and more.

From these basic features, your GARMIN GPS can

provide one more critical benefit; peace of mind, because,

with GPS you’ll know where you are, where you’ve been

and where you’re going. And since you’ll always know the

way back home, you can concentrate on what you set out

to do and enjoy the great outdoors.

Other features include:

Waypoints: 500 with name and graphic symbol.

Tracks: Automatic track log; 10 saved tracks

let you retrace your path in both

directions.

Route: Route lets you navigate up to 50

waypoints in sequence.

Trip Computer: Current speed, average speed,

maximum speed, direction of

movement, bearing, elevation, time

of sunrise/sunset, trip timer and trip

odometer.

NOTE: You should

always be prepared and

capable of navigating

without the eTrex. It is

designed to augment

other forms of basic

navigation, not entirely

replace them.

eTrex Buttons

Introduction

Operating the eTrex is as simple as pressing a button!

The POWER Button:

• Turns the unit on and off

• Turns the display backlight on and off

The PAGE

Button:

• Switches between pages and backs you out

of pages. If you start to do something and

you don’t want to continue, you can stop

by pressing the PAGE Button.

The UP/DOWN Buttons:

• Select options on pages and menus

• Adjust Display Contrast on Satellite Page

• Zoom in and out on Map Page

• Cycle through trip data on Pointer Page

The ENTER Button:

• Confirms data entry or menu selections

PAGE

PWR

ENTER

Owner's

Manual

The eTrex is ergonomically

designed to be held in your

left hand.

This symbol identifies notes

throughout the manual

which will give you helpful

information.

Introduction

eTrex

Description

DOWN

Button

UP Button

ENTER

Button

External Power

and

Data Connector

(top rear)

Internal

GPS Antenna

LCD Display

(with backlight)

POWER

Button

PAGE

Button

Battery

Compartment

(in rear)

Waterproof Case

Introduction

Accessories

Standard Accessories

Lanyard....................................... Part No. 013-00052-00

Provides convenient method for carrying the eTrex. Attaches to a slot on the

bottom of the unit.

Owner’s Manual .......................... Part No. 190-00205-00

Quick Start Guide ....................... Part No. 190-00205-01

Optional Accessories

Carrying Case ............................. Part No. 010-10266-00

Protects the eTrex when not in use.

Auto Power Adapter .................... Part No. 010-10203-00

Provides eTrex operation from a automobile cigarette lighter.

PC Data Cable ............................. Part No. 010-10206-00

Allows for transfer of data from a PC to an eTrex.

Data Cable .................................. Part No. 010-10205-00

Wiring harness. Connections for data input/output.

Bicycle Mounting Kit ................... Part No. 010-10267-00

Allows the eTrex to be mounted on bicycle handle bars.

PC Cable/Auto Power Adapter .... Part No. 190-10268-00

Allows transfer of waypoints and routes from a PC to the eTrex and

provides unit operation from an automobile cigarette lighter.

MapSource® Map Data CD-ROMs

An excellent tool for creating waypoints and routes on your PC using a

background map and downloading them to your eTrex. See your

GARMIN dealer for MapSource details.

Installing the Batteries

The eTrex operates on 2 AA batteries (not included),

which are installed at the back of the unit. To install the

batteries, remove the battery cover by turning the lock

ring at the back of the unit 1/4 turn counter-clockwise.

Insert the batteries observing proper polarity. Attach the

battery cover by turning the lockring 1/4 turn clockwise.

The 2 AA batteries should last about 22 hours in battery

save mode.

Auto Power Adapter-

Converts 12VDC output

from the lighter to 3VDC

input to the eTrex. Not

interchangeable with

power adapters for

GARMIN VHF 720,

725, and 725e, or GPS

170, 175, 190, and 195.

Lanyard

PC Interface Cable with

Auto Power Adapter

Bicycle Mounting Kit

Table des matières

Autres manuels Garmin GPS

Garmin

Garmin Geko 201 Manuel utilisateur

Garmin

Garmin StreetPilot 2730 Guide de configuration

Garmin

Garmin EDGE 1030 PLUS Manuel utilisateur

Garmin

Garmin APPROACH G80 Manuel utilisateur

Garmin

Garmin GPSMAP 696 Manuel utilisateur

Garmin

Garmin West Marine 276C Plus Manuel utilisateur

Garmin

Garmin nuvi 2405 series Manuel d'instructions

Garmin

Garmin GPSMAP 400 series Manuel utilisateur

Garmin

Garmin nuvi 2455LMT Manuel utilisateur

Garmin

Garmin GPSMAP 7400 Series Manuel utilisateur

Garmin

Garmin Montana 600 Series Manuel utilisateur

Garmin

Garmin quatix Manuel utilisateur

Garmin

Garmin GPSMAP 400 series Manuel utilisateur

Garmin

Garmin GNC 420W Manuel

Garmin

Garmin GPSMAP 76CS Manuel utilisateur

Garmin

Garmin GPSMAP 4000 Series Manuel du propriétaire

Garmin

Garmin LIVE 1695 Manuel d'instructions

Garmin

Garmin GMX 200 Manuel utilisateur

Garmin

Garmin aera 500 Manuel de formation

Garmin

Garmin Etrex Legend - GPS Receiver Instructions de fonctionnement

Garmin

Garmin GPSMAP 700 Series Manuel utilisateur

Garmin

Garmin Nuvi 215 Manuel utilisateur

Garmin

Garmin Foretrex 301 - Hiking GPS Receiver Guide de référence

Garmin

Garmin eTrexLegend TM Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur

Kenwood

Kenwood DNN9330BT Manuel utilisateur

Safelet

Safelet Indra Manuel utilisateur

Bushnell

Bushnell 360100 Manuel utilisateur

Geneq

Geneq SXBlue Manuel utilisateur

ORIGO

ORIGO ED308 Manuel utilisateur
