Gardena 1490 Manuel utilisateur

GARDENA

DBetriebsanleitung

Bohrmaschinenpumpe

GB Operating Instructions

Drill Pump

FMode d’emploi

Mini-pompe

NL Instructies voor gebruik

Voorzetpomp

SBruksanvisning

Borrmaskinpump

IIstruzioni per l’uso

Pompa da trapano

EManual de instrucciones

Minibomba

PInstruções de utilização

Mini Bomba

Art. 1490

GARDENA Drill Pump

1. Applications and Media to be Pumped

The GARDENA Drill Pump is designed for private

use in the house and garden. This includes draining

of small containers, such as aquariums, paddling

pools, defective washing machines, as well as

pumping fuel oil, and temporary aeration of small

garden pools.

AAcids, easy combustible or explosive

substances like petrol, kerosene, nitro,

or food must not be pumped. The temperature

of the liquid must not exceed 40 °C.

In case of doubt, please contact your GARDENA

GARDENA Service Department.

2. Use of Operating Instructions

Translation of the original instructions from German.

Read the operating instructions carefully.

AFor safety reasons, people who are not

familiar with the operating instructions

must not operate the pump. Children under

16 years must not operate the pump and have

to be kept away from plugged-in unit. Persons

with reduced physical or mental abilities may

use the product only if they are supervised or

instructed by a responsible person.

3. Operation and Maintenance

For intermittent or short time use a drill rated

450 Watt minimum is required. For runs of 30 minu-

tes or more a rating of 600 Watt is needed.

Fit the drive shaft (8 mm ∅) to the drill chuck.

AMake sure that the pump cannot twist,

wobble or tilt.

Connect suction and pressure hoses (using

GARDENA hose fittings). The direction of flow

is shown by the white arrows on the pump top.

Connect suction and pressure hoses (using

GARDENA hose fittings). The direction of flow

is shown by the white arrows on the pump top.

Check that the drill rotates clockwise, correspond-

ing with the direction shown by the arrows on the

pump side.

The suction hose should not be more than 3 m

(9 ft.) long. Please make certain that it is leak proof

when connected. The hose should be of non-

collapsing type (hose with woven reinforcement,

e.g. GARDENA Flex Hose or Cord Hose).

Place the suction hose inlet into fluid to be pumped.

Prime pump at max. drill speed. The outlet side

should be open during priming. Pump output can

be regulated by drill speed.

The pump is self-priming. If it does not start

pumping within 12 seconds, switch off at once

and locate the cause (probably a leaking, blocked or

collapsed inlet hose). The pump should not operate

against a closed outlet side for too long a period.

When liquid no longer flows switch off the

electric drill immediately.

After use, or after pumping of fuel oil, clean the

pump out thoroughly with clean water.

4. Technical data

Max. performance

with 13 mm (½”) hose 1.7 m3/h

(6.24g.p.m.)

with 19 mm (¾”) hose 2.4 m3/h

(8.81g.p.m.)

Max. pressure approx. 3 bar

(42 p.s.i.)

Max. pumping height approx. 30 m

(98.43 ft.)

Max.suction height approx. 3 m (9ft.)

Max. permissible r.p.m. 3,400 r.p.m.

Max. permissible temperature

of the liquid to be pumped 40 °C

Drive shaft ∅8 mm

Max. dry running time 12 seconds

We expressly point out that, in accordance with

the product liability law, we are not liable for any

damage caused by our units if it is due to impro-

per repair or if parts exchanged are not original

GARDENA parts or parts approved by us, and if

the repairs were not carried out by a GARDENA

Service Centre or an authorised electrician. The

same applies to spare parts and accessories.

EU Certificate of Conformity

The undersigned,

GARDENA Manufacturing GmbH

Hans-Lorenser-Str. 40

D-89079 Ulm

hereby certifies that, when leaving our factory, the

unit indicated below is in accordance with the har-

monised EU guidelines, EU standards of safety and

product specific standards.

This certificate becomes void if the unit is modified

without our approval.

Description of the unit: Drill Pump

Art. no.: 1494

EU directives: Machinery Directive

98/37/ EC : 1998

2006/42/EC : 2006

Year of CE marking: 1994

Ulm, 01.12.1998 Thomas Heinl

Technical Dept. Manager

Deutschland / Germany

GARDENA

Manufacturing GmbH

Central Service

Hans-Lorenser-Straße 40

D-89079 Ulm

Produktfragen:

(+49) 731 490-123

Reparaturen:

(+49) 731 490-290

service@gardena.com

Argentina

Husqvarna Argentina S.A.

Vera 745

(C1414AOO) Buenos Aires

Phone: (+54) 11 4858-5000

diego.poggi@ar.husqvarna.com

Australia

Husqvarna Australia Pty. Ltd.

Locked Bag 18

Gosford NSW 2250

Phone: (+61) (0) 2 4372 1500

customer.service@

husqvarna.com.au

Austria / Österreich

Husqvarna Austria GmbH

Consumer Products

Industriezeile 36

4010 Linz

Tel.: (+43) 732 77 01 01

consumer.service@husqvarna.at

Belgium

GARDENA Belgium NV/SA

Sterrebeekstraat 163

1930 Zaventem

Phone: (+32) 2 7 20 92 12

Mail: info@gardena.be

Brazil

Palash Comércio e

Importação Ltda.

Rua São João do Araguaia, 338

– Jardim Califórnia –

Barueri – SP - Brasil –

CEP 06409-060

Phone: (+55) 11 4198-9777

eduardo@palash.com.br

Bulgaria

Хускварна България ЕООД

1799 София

Бул. „Андрей Ляпчев” Nº 72

Тел.: (+359) 2 80 99 424

www.husqvarna.bg

Canada / USA

GARDENA Canada Ltd.

100 Summerlea Road

Brampton, Ontario L6T 4X3

Phone: (+1) 905 792 93 30

info@gardenacanada.com

Chile

Antonio Martinic y Cia Ltda.

Cassillas 272,

Centro de Cassillas

Santiago de Chile

Phone: (+56) 2 20 10 708

garfar_cl@yahoo.com

Costa Rica

Compania Exim

Euroiberoamericana S.A.

Los Colegios, Moravia,

200 metros al Sur del Colegio

Saint Francis - San José

Phone: (+506) 297 68 83

exim_euro@racsa.co.cr

Croatia

KLIS d.o.o.

Stanciceva 79

10419 Vukovina

Phone: (+385) 1 622 777 0

gardena@klis-trgovina.hr

Cyprus

FARMOKIPIKI LTD

P.O. Box 7098

74, Digeni Akrita Ave.

1641 Nicosia

Phone: (+357) 22 75 47 62

condam@spidernet.com.cy

Czech Republic

GARDENA spol. s r.o.

Tuшanka 115

627 00 Brno

Phone: (+ 420) 548 217 777

gardena@gardenabrno.cz

Denmark

GARDENA – Husqvarna

Consumer Outdoor Products

Salgsafdelning Danmark

Box 9003, S-200 39 Malmö

info@gardena.dk

Estonia

Husqvarna Eesti OÜ

Consumer Outdoor Products

Kesk tee 10, Aaviku küla

Rae vald, Harju maakond

75305

kontakt.etj@husqvarna.ee

Finland

Oy Husqvarna Ab

Consumer Outdoor Products

Lautatarhankatu 8 B / PL 3

00581 HELSINKI

info@gardena.fi

France

GARDENA France

Immeuble Exposial

11 allée des Pierres Mayettes

ZAC des Barbanniers

B.P. 99

92232 GENNEVILLIERS

cedex

Tél. (+33) 01 40 85 30 40

service.consommateurs@

gardena.fr

Great Britain

Husqvarna UK Ltd

Preston Road

Aycliffe Industrial Park

Newton Aycliffe

County Durham

DL5 6UP

info.gardena@

husqvarna.co.uk

Greece

HUSQVARNA GREECE S.A.

Branch of Koropi

Ifestou 33A

Industrial Area Koropi

194 00 Athens – Greece

V.A.T. EL094094640

Phone: (+30) 210 66 20 225

info@husqvarna-consumer.gr

Hungary

Husqvarna

Magyarország Kft.

Ezred u. 1

1044 Budapest

Phone: (+36) 80 20 40 33

gardena@gardena.hu

Iceland

Ó. Johnson & Kaaber

Tunguhalsi 1

110 Reykjavik

ooj@ojk.is

Ireland

Michael McLoughlin & Sons

Hardware Limited

Long Mile Road

Dublin 12

Italy

GARDENA Italia S.p.A.

Via Donizetti 22

20020 Lainate (Mi)

Phone: (+39) 02.93.94.79.1

info@gardenaitalia.it

Japan

KAKUICHI Co. Ltd.

Sumitomo Realty &

Development Kojimachi

BLDG., 8F

1 Nibanncyo, Chiyoda-ku

Tokyo 102-0084

Phone: (+81) 33 264 4721

m_ishihara@kaku-ichi.co.jp

Latvia

SIA „Husqvarna Latvija”

Consumer Outdoor Products

Bakužu iela 6

Riga, LV-1024

info@husqvarna.lv

Lithuania

UAB Husqvarna Lietuva

Consumer Outdoor Products

Ateities pl. 77C

LT-52104 Kaunas

centras@husqvarna.lt

Luxembourg

Magasins Jules Neuberg

39, rue Jacques Stas

Luxembourg-Gasperich 2549

Case Postale No. 12

Luxembourg 2010

Phone: (+352) 40 14 01

api@neuberg.lu

Netherlands

GARDENA Nederland B.V.

Postbus 50176

1305 AD ALMERE

Phone: (+31) 36 521 00 00

info@gardena.nl

Neth. Antilles

Jonka Enterprises N.V.

Sta. Rosa Weg 196

P.O. Box 8200, Curaçao

Phone: (+599) 9 767 66 55

pgm@jonka.com

New Zealand

Husqvarna New Zealand Ltd.

PO Box 76437

Manukau City 2241

Phone: (+64) 09 9202410

Norway

GARDENA – Husqvarna

Consumer Outdoor Products

Salgskontor Norge

Kleverveien 6

1540 Vestby

info@gardena.no

Poland

Husqvarna Poland Spółka z o.o.

Oddział w Szymanowie

Szymanów 9 d

05-532 Baniocha

Phone: (+ 48) 22 727 56 90

gardena@gardena.pl

Portugal

GARDENA Portugal Lda.

Sintra Business Park

Edifício 1, Fracção 0-G

2710-089 Sintra

Phone: (+351) 21 922 85 30

info@gardena.pt

Romania

MADEX INTERNATIONAL SRL

Soseaua Odaii 117-123,

Sector 1,

Bucureєti, RO 013603

Phone: (+ 40) 21 352 76 03

madex@ines.ro

Russia

ООО ГАРДЕНА РУС

123007, г. Москва

Хорошевское шоссе, д. 32А

Тел.: (+7) 495 380 31 92

info@gardena-rus.ru

Singapore

Ray PRIVATE LIMITED

40 Jalan Pemimpin

#02-08 Tat Ann Building

Singapore 577185

Phone: (+65) 6253 2277

shiying@hyray.com.sg

Slovak Republic

GARDENA spol. s r.o.

Tuшanka 115

627 00 Brno

Phone: (+ 420) 548 217 777

gardena@gardenabrno.cz

Slovenia

GARDENA d.o.o.

Brodiљиe 15

1236 Trzin

Phone: (+386) 1 580 93 32

servis@gardena.si

South Africa

GARDENA

South Africa (Pty.) Ltd.

P.O. Box 11534

Vorna Valley 1686

Phone: (+27) 11 315 02 23

sales@gardena.co.za

Spain

GARDENA IBÉRICA S.L.U.

C/ Basauri, nº 6

La Florida

28023 Madrid

Phone: (+34) 91 708 05 00

atencioncliente@gardena.es

Sweden

GARDENA

Husqvarna Consumer Outdoor

Products

Försäljningskontor Sverige

Box 9003

200 39 Malmö

info@gardena.se

Switzerland / Schweiz

Husqvarna Schweiz AG

Consumer Products

Industriestrasse 10

5506 Mägenwil

Phone: (+41) (0) 848 800 464

info@gardena.ch

Turkey

GARDENA / Dost Diþ Ticaret

Mümessillik A.Þ. Sanayi

Çad. Adil Sokak No.1

Kartal - Ýstanbul

Phone: (+90) 216 38 93 939

info@gardena-dost.com.tr

Ukraine / Україна

ТОВ «ГАРДЕНА УКРАЇНА»

Васильківська, 34, 204-Г

03022, Київ

Тел. (+38) 044 498 39 02

info@gardena.ua

1490-20.960.09 /0309

©GARDENA

Manufacturing GmbH

D-89070 Ulm

http://www.gardena.com

Autres manuels pour 1490

Ce manuel convient aux modèles suivants

Autres manuels Gardena Pompe à eau

Gardena

Gardena FSP 3500 Manuel utilisateur

Gardena

Gardena 4000/1 Manuel utilisateur

Gardena

Gardena 6000/3 S Manuel utilisateur

Gardena

Gardena 5500/5 inox Manuel utilisateur

Gardena

Gardena 3000/4 Manuel utilisateur

Gardena

Gardena 15000 Manuel utilisateur

Gardena

Gardena 9000CLEAR Manuel utilisateur

Gardena

Gardena 4000/5 Manuel utilisateur

Gardena

Gardena 9000CLEAR Manuel utilisateur

Gardena

Gardena 21000 inox Manuel utilisateur

Gardena

Gardena 1265 Manuel utilisateur

Gardena

Gardena 5500/5 inox Manuel utilisateur

Gardena

Gardena 9000 aquasensor Manuel utilisateur

Gardena

Gardena RP 300 Manuel utilisateur

Gardena

Gardena 4000/5 Manuel utilisateur

Gardena

Gardena Comfort 5000/5E LCD Manuel utilisateur

Gardena

Gardena 20000DIRT Manuel utilisateur

Gardena

Gardena FSP 5500 7868 Manuel utilisateur

Gardena

Gardena 1787 Manuel utilisateur

Gardena

Gardena 10000 SL Inox Manuel utilisateur

Gardena

Gardena Submersible Pump6000 S Manuel utilisateur

Gardena

Gardena WP 1800 Manuel utilisateur

Gardena

Gardena 4000/4 Manuel utilisateur

Gardena

Gardena 3000/4 Manuel utilisateur

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
