INSTALLATION INSTRUCTIONS

Product

Revision

Form #

CF20 Docking Station

7160-0802

CF20 Cradle

7160-080

Rev.

INST

712

Printing Spec: PS-004

This instruction sheet is for the CF20 docking station and Cradle only. For instructions on

features, set-up and operation of the CF20 computer, please refer to the manual provided

by Panasonic with the computer.

This docking station is designed to be used with a variety of Gamber-Johnson

mounting systems. Installation instructions for other Gamber-Johnson products are

provided with each individual product.

This instruction sheet is for the following products:

7160-0802-00, (-P) & (-E) Docking Station – No RF, Keyed Alike

7160-0802-02, (-P) & (-E) Docking Station – Dual RF, Keyed Alike

7160-0802-04, (-P) & (-E) Docking Station – No RF, Keyed Different

7160-0802-06, (-P) & (-E) Docking Station – Dual RF, Keyed Different

7160-080 -00, (-P) & (-E) Cradle – No RF, Keyed Alike

7160-080 -01, (-P) & (-E) Cradle – No RF, Keyed Different

Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or

other damage Of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicles or any other application. In order to safely

install and use Gamber-Johnson products full consideration of vehicle occupants vehicle systems (i.e., the location of fuel lines, brake lines, electrical, drive train or other

systems), air-bags, and other safety equipment is required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not

consistent with the original vehicle manufactures specifications and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed

through the Gamber-Johnson Certified Installer Program.

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

Page 2 of 12

Information on Disposal for Users of Waste Electrical & Electronic Equipment

(private

households)

This symbol on the products and/or accompanying documents means that used

electrical and electronic products should not be mixed with general household

waste.

Please dispose of this item only in designated national waste electronic collection

schemes, and not in the ordinary dust bin.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for

further information.

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for the

correct method of disposal.

6-E-1

Information on Disposal for Users of Waste Electrical & Electronic Equipment

(private

households)

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer

and ask for the correct method of disposal.

6-M-1

Warning

This is a class A product. In a domestic environment this product may cause radio interference

in which case the user may be required to take adequate measures.

Page 3 of 12

No user serviceable parts.

Refer to qualified repair center personal for assistance.

Interface Cable

Use of an interface cable longer than 10ft ( m) is not recommended.

Installation by qualified personnel required.

Safety of product may be compromised if incorrectly installed.

complies with

U 60950-1

Page 4 of 12

For

Europe

Declaration of Conformity (DoC)

"Hereby, Gamber-Johnson LLC declares that this Docking Station

is in compliance with the essential requirements and other

relevant provisions of EU Council Directives."

DoC available from Gamber-

Johnson LLC

Manufacturer:

Gamber-Johnson LLC

001 Borham Ave

Stevens Point WI 54481 USA

For

Canada

Canadian ICES-00

CAN ICES- (A)/NMB- (A)

7-M-2

External Antenna

This device has been designed to operate with an external WWAN antenna having a maximum gain

of 4 dBi for the cellular band, dBi for the PCS band, dBi for LTE Band 4, 9 dBi for LTE Band 17

and 10 dBi for LTE Band 1 . WWAN Antenna having a higher gain is strictly prohibited per

regulations of Industry Canada. The required antenna impedance is 50ohms.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen

that the equivalent isotropically radiated power (EIRP) is not more than that required for successful

communication.

Antenne Externe

Cet appareil est conçu pour opérer avec une antenne WWAN (réseau étendu sans fil) dont le gain

maximum est fixé à 4 dBi pour la bande cellulaire, dBi pour la bande de service de

communications personnelles (PCS), dBi pour la bande LTE 4, 9 dBi pour la bande LTE 17 et 10

dBi pour la bande LTE 1 . Les règlements d'Industrie Canada interdisent l'utilisation d'une antenne

WWAN dont le gain serait supérieur à cette limite. L'antenne doit avoir une impédance de 50 ohms.

Afin de réduire le risque d'interférence radioélectrique aux autres utilisateurs des bandes de

fréquences, le type d'antenne et son gain doivent être tels que la puissance isotrope rayonnée

équivalente (PIRE) n'est pas plus élevée que le niveau requis pour assurer la communication.

2-Ca-1-1

For U.S.A.

Page 5 of 12

Federal Communications Commission Radio Frequency Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult an experienced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded interface cables when connecting to a computer or

peripheral. Also, any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Responsible Party:

Gamber-Johnson LLC

001 Borham Ave

Stevens Point WI 54481 USA

Tel: 1-800-456-6868

Support Contact: www.gamberjohnson.com

External Antenna

FCC RF Exposure Warning:

This equipment is provided with external antenna connector(s) for connection to optional Docking Station

or Port Replicator for mobile external mounted antenna(s). External antenna(s) must be professionally

installed and cannot exceed recommended maximum antenna gain as described in individual provided

supplement instructions for wireless transmitters.

The maximum allowable antenna gain for the external WWAN base whip antenna for the cellular band is 4

dBi, PCS band is dBi, LTE Band 4 is dBi, LTE Band 17 is 9 dBi and 10 dBi for LTE Band 1 . Also, user

must maintain minimum 20 cm spacing between external antenna(s) and all person's body (excluding

extremities of hands, wrist and feet) during wireless modes of operation.

2-M-1-1

Page 6 of 12

PRE-INSTALLATION RECOMMENDATIONS

Conduct a “Bench Test”

Gamber-Johnson strongly advises a “bench test” be conducted to verify all electronic and software issues are

resolved prior to installation:

1. Make sure the computer is operational by itself.

2. Insert computer into the docking station and verify that the computer is operating in the dock.

. Interconnect entire assembly and verify start-up of all components, including other equipment (printers,

modems, scanners, etc.)

Gamber-Johnson recommends positioning of all mounts and equipment in the vehicle prior to the actual install to

verify that mounting locations are safe and practical.

IMPORTANT SAFETY INFORMATION FOR INSTALLERS

Safety is dependent on the proper installation and servicing of this docking station. It is important to read and follow

all instructions before installing this product.

To properly install a Gamber-Johnson docking station you must have a good understanding of automotive electrical

procedures and systems, along with proficiency in the installation and service of aftermarket vehicle equipment.

There are no adjustments required at any time of the electrical components within the docking station. Opening the

docking station will void the product warranty.

During Installation:

DO NOT connect this docking station to the vehicle battery until:

1. All other electrical connections are made

2. Mounting of all components is complete

. Verification that no shorts exist in the entire system

DO NOT install equipment or route wiring or cords in the deployment path of any air bag.

When drilling into the vehicle, DO make sure that both sides of the surface are clear of anything that could be

damaged.

Caution: If wiring is shorted to the frame, high current conductors can cause hazardous sparks resulting in electrical

fires or flying molten metal.

After installation:

Test the docking station to ensure that it is working properly.

File these instructions in a safe place and refer to them when performing maintenance or reinstalling.

WARNING: Failure to follow all safety precautions and instructions may result in property damage, serious injury, or

death.

Page 7 of 12

Precautions for Operating the Docking Station

•

If a Malfunction or Trouble Occurs,

Immediately Stop Use

If a Malfunction Occurs, Immediately

Unplug the Car Plug and Remove

the Computer from this product

•This product is damaged

•The connector pins are bent

•A foreign object is inside this product

•Smoke is emitted

•An unusual smell is emitted

•Unusually hot

Continuing to use this product while any of the

above conditions are present may result in fire

or electric shock.

•If a malfunction or trouble occurs,

immediately unplug the car plug and remove

the unit from this product. Then, contact your

technical support office for repair.

•Do Not Touch This Product or Cable When It

Starts Thundering

Electric shock may result.

•Do Not Place Containers of Liquid or Metal

Objects on Top of This Product If water or

other liquid spills, or if paper

clips, coins, or foreign matter get inside this

product, fire or electric shock may result.

•If foreign matter has found its way inside,

immediately unplug the car plug and remove

the unit from this product. Then contact your

technical support office.

•

Avoid a Lot of Water, Moisture, Steam,

Dust, Oily Vapors, etc.

Otherwise, possibly resulting in fire or

electric shock.

•

Use Only the Specified Docking Station

with This Product

Using a Docking Station other than the one

supplied (supplied with the unit or one sold

separately as an accessory) may result in a

fire.

•Do Not Connect a Telephone Line, or a

Network Cable Other Than the one

Specified, Into the LAN Port.

If the LAN port is connected to a network

such as the ones listed below, a fire or

electric shock may result.

•Networks other than 1000BASE-T,

100BASE-TX or 10BASE-T

•Phone lines (IP phone (Internet

Protocol Telephone), Telephone

lines, internal phone lines (on premise

switches), digital public phones, etc.)

•

Using this product continuously in a

hot environment will shorten

the product life. Avoid use in these

types of environments.

•

When using in hot or cold

environment, some peripherals may

fail to work properly. Check the

operation environment of the

peripherals.

Page 8 of 12

•

Do Not Install This Product in Unstable

State

If balance of the unit is lost, it may fall over

or drop, resulting in an injury.

•Docks used in the vertical (Tablet) position

must be installed with the lock on TOP.

Installing the dock upside down may result

in damage to the computer.

•Do Not Install This Product Where

There is a Lot of Water, Moisture,

Steam, Dust, Oily Vapors, etc.

Otherwise, a possibility of fire or

electric shock could result.

Dimensional Drawing

Installation fixing 75mm VESA studs are provided in the areas indicated by the arrows in the figure

above.

How to use

Page 9 of 12

DOCKING PROCEDURE

1. Ensure latch is in the "OPEN" Position

2. Extend the CF-20 handle to the "DEPLOYED" position then insert CF-20

3. Push the top of the CF-20 into the dock. The latch will move to the "Docked" position

4. To secure the tablet ensure it is in the closed position with the display latch engaged then

move the lower latch into the locked position

5. Push the CF-20 handle into the "STOWED" position

6. Push the lock to secure the device

UNDOCK Position

DOCK Position

Lower

Latch

Locked

Unlocked

NOTE:

Portions of your Docking Station may differ somewhat from the illustrations in the operating

instructions, but this should present no problems in actual use. Be sure to follow the operating

instructions when using your Docking Station.

NOTES:

Ensure latch is fully in the "Docked" position. It is recommended that the CF-20 is pushed into

the dock with two hands. For CF-20 fitted with Gadget option, it may be necessary to attach the

main unit in the forward direction only. Refer to device manual for further information.

Description

Parts

Page 10 of 12

A.Lever

B. Lock

C. Secondary Latch

D. Antenna Switch

E. DC-IN jack DC IN 16V

F. LAN port

G. USB port

H. HDMI port

HDMI

I. VGA Port

J. Serial port

External wireless LAN/GPS antenna port

EX. ANT 2

. External wireless WAN antenna port EX.

ANT 1

K L D E F G H I J

K & L ports on the following models only:

7160-0802-02, (-P) & (-E)

7160-0802-06, (-P) & (-E)

Bottom Side

Table des matières

Autres manuels Gamber Johnson Station d'accueil

Gamber Johnson

Gamber Johnson GETAC V110 Manuel utilisateur

Gamber Johnson

Gamber Johnson Getac S400 Manuel utilisateur

Gamber Johnson

Gamber Johnson Recon CF31 Military Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0907-02 Manuel utilisateur

Gamber Johnson

Gamber Johnson ZEBRA TC22 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1252 Series Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1082 Series Manuel utilisateur

Gamber Johnson

Gamber Johnson CF19 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0595 Manuel utilisateur

Gamber Johnson

Gamber Johnson CF54 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1084-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1005 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0840-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson Tab Cruzer 7160-0581 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1265-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0883-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0902-00-P Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0486 Manuel utilisateur

Gamber Johnson

Gamber Johnson GETAC S410 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-1253 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0318-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson CF53 Manuel utilisateur

Gamber Johnson

Gamber Johnson 7160-0542-00 Manuel utilisateur

Gamber Johnson

Gamber Johnson TrimLine 7300-0373-00 Manuel utilisateur

Manuels Station d'accueil populaires d'autres marques

Sony

Sony Dream Machine XDR-DS12iP Manuel utilisateur

Acer

Acer USB Type-C Dock II Manuel utilisateur

ATEN

ATEN UC-2000 Manuel utilisateur

Xcellon

Xcellon HDD-202 Manuel utilisateur

Dok

Dok CR09 Manuel utilisateur

Philips

Philips BTM630/12 Manuel utilisateur

IOGear

IOGear Travel Pro GUD3C09 Manuel utilisateur

RKI

RKI SDM-E2 Manuel utilisateur

iHome

iHome iP15 Manuel utilisateur

VITURE ONE

VITURE ONE MOBILE DOCK Manuel utilisateur

Lindy

Lindy 42984 Manuel utilisateur

CipherLab

CipherLab 8001 Manuel utilisateur

Pyle

Pyle PIPDSP2 Manuel utilisateur

Avol

Avol AS2350 Manuel utilisateur

Datalogic

Datalogic JoyaTouch Manuel utilisateur

Philips

Philips DC190/79 Manuel utilisateur

Targus

Targus DOCK315EUZ Manuel utilisateur

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuel utilisateur
