INSTALLATION MANUAL

GPS NAVIGATOR

GP-80

1. EQUIPMENT LIST ............................................................................................1

2. DISPLAY UNIT..................................................................................................2

3. ANTENNA UNIT................................................................................................3

4. WIRING .............................................................................................................5

5. INITIAL SETTINGS...........................................................................................7

6. OPTIONAL DGPS...........................................................................................21

PACKING LISTS AND INSTALLATION MATERIALS

OUTLINE DRAWINGS

INTERCONNECTION DIAGRAM

Back

Your Local Agent/DealerYour Local Agent/Dealer

9-52 Ashihara-cho,9-52 Ashihara-cho,

Nishinomi

a, Ja

anNishinomi

a, Ja

Tele

hone :Tele

hone : 0798-65-21110798-65-2111

0798-65-42000798-65-4200

IRST EDITION :

IRST EDITION : SEP.SEP. 19951995

Printed in JapanPrinted in Japan

ll ri

hts reserved.

ll ri

hts reserved.

Q1Q1 :: OCT.OCT. 06,200306,2003

PUB.No.PUB.No. IME-43740-Q1IME-43740-Q1

*00080734101**00080734101*

(( TENITENI )) GP-80GP-80

* 0 0 0 8 0 7 3 4 1 0 1 ** 0 0 0 8 0 7 3 4 1 0 1 *

*IME43740Q10**IME43740Q10*

* I M E 4 3 7 4 0 Q 1 0 ** I M E 4 3 7 4 0 Q 1 0 *

SAFETY INSTRUCTIONS

WARNING

Do not work inside the

equipment unless totally

familiar with electrical

circuits.

Hazardous voltage which can

cause electrical shock, burn

or serious injury exists inside

the equipment.

Turn off the power at the

mains switchboard before

beginning the installation.

Post a sign near the switch

to indicate it should not be

turned on while the equip-

ment is being installed.

Fire, electrical shock or

serious injury can result if the

power is left on or is applied

while the equipment is being

installed.

Ground the equipment to

prevent electrical shock

and mutual interference.

Confirm that the power supply voltage

is compatible with the voltage rating

of the equipment.

Connection to the wrong power supply

can cause fire or equipment damage. The

voltage rating appears on the label at the

rear of the display unit.

Use the correct fuse.

Use of a wrong fuse can cause fire or

equipment damage.

Keep the following compass safe

distances:

Standard Steering

Display unit 0.6 m 0.5 m

CAUTION

1. EQUIPMENT LIST

Standards

Name

Type

Q'ty

Mass

(kg)

Remarks

GPA-017S

GPA-018S

Antenna Unit

GPA-019S 1

for DGPS

GPR-020

Without Beacon RX

Display Unit

GPR-020

1 2.2

With Beacon RX

CP20-01900

Installation

Materials

CP20-01920

1 set

See lists at end of

manual.

Spare Parts

SP20-00500

1 set

Options

Name

Type

Code No.

Remarks

Flush Mount Kit S

OP20-24

004-393-000

Flush Mount Kit F OP20-25 004-393-280 For display unit.

CP20-01700 004-372-110

Antenna Cable Set

CP20-01710 004-372-120

See page 3.

Right Angle Antenna Base No.13-QA330 000-803-239

L-Type Antenna Base No.13-QA310 000-803-240

Handrail Antenna Base No.13-RC5160 000-806-114

Mast Mount Kit CP20-01111 004-365-780

For antenna unit.

Cable Assy MJ-A6SPF0011-050

(03S9202) 000-132-244 5m, 6p-4p

MJ-A6SPF0011-100

(03S9226) 000-132-336 10m, 6p-4p

MJ-A7SPF0003-050

(20S0241) 000-136-730 5m, For DATA4

20S0093 000-117-603 5m, MJ type 6P

MJ-A6SPF0012-050

(64S4073) 000-134-424 Cross cable 5m

MJ-A6SPF0012-100

(64S4071) 000-133-817 Cross cable 10m

Beacon Receiver Set GR-800 –

Rectifier PR-62 000-013-485 For 100VAC mains

000-013-486

For 220VAC mains

2. DISPLAY UNIT

The display unit can be installed with either of four methods as shown below. Refer to the

outline drawing page D-2, D-3, and D-4.

• Locate the unit away from exhaust pipes and vents.

• The mounting location should be well ventilated.

• Mount the unit where shock and vibration are minimal.

• Keep the display unit away electromagnetic field generating equipment such as motor,

generator.

• Allow sufficient maintenance space and a sufficient slack in cables for maintenance and

repair.

• If vibration is a problem, tilt the display unit so it contacts the vibration absorbers attached to

the inside of the hanger (tilted within 5 °).

Table Top and Overhead Mounting

TABLETOP OVERHEAD

Display unit mounting methods

Flush mounting type F

An optional flush mount kit type F is required. For details, see outline drawing page D-2.

Name Type Code No.

Flush Mount Kit F OP20-25 004-393-280

Flush mounting type S

An optional flush mount kit type S is required. For details, see outline drawing page D-3.

Name Type Code No.

Flush Mount Kit S OP20-24 004-393-000

3. ANTENNA UNIT

Mounting

Install the antenna unit referring to the installation diagram on page D-4. When selecting a

mounting location for the antenna unit, keep in mind the following points.

• Select a location out of the radar beam. The radar beam will obstruct or prevent reception

of the GPS satellite signal.

• Be sure the location offers a clean line-of-sight to satellite. Objects within line-of-sight to

a satellite, for example, a mast or funnel, block reception and cause prolonged acquiring time

or interruption of position fix.

• Mount the unit as high as possible. Mounting the antenna as high as possible keeps it free

of water spray, which can intercept reception of GPS satellite signal, if water spray is frozen.

• The antenna unit GPA-018S must be grounded. Connect ground wire of 1.25 sq or larger

(local supply) between unit and a stainless steel screw fastened to the mast.

Extending Antenna Cable Length

The standard cable is 15m long. 30m and 50m long extension cable sets are optionally

available. See page 4.

!Extension cable line-up

Fabricate the end of antenna cable and attach the coaxial connector. Details are shown

on next page.

1 m Antenna Cable

30 m or 50 m 1 m

Fabricate locally. (See the next page.)

To display unit

: Connector

Conversion

Cable Assy.

Antenna Unit

GPA-018S GPA-017S

20cm

GPA-019S

Extension Cable Line-up

!Waterproofing the connector

Wrap connector with vulcanizing tape and then vinyl tape. Bind the tape end with

cable-tie.

How to waterproof the antenna

3. ANTENNA UNIT

How to attach the N-P-8DFB connector

Outer SheathArmor Inner Sheath Shield Remove outer sheath and armor by the dimensions

shown left.

Expose inner sheath and shield by the dimensions

shown left.

Cut off insulator and core by 10mm.

Twist shield end.

Clip on clamp nut, gasket and clamp as shown left.

Fold back shield over clamp and trim.

Cut aluminum foil at four places, 90°from one

another.

Fold back aluminum foil onto shield and trim.

Expose the insulator by 1mm.

Expose the core by 5mm.

Slip the pin onto the conductor. Solder them together

through the hole on the pin.

Insert the pin into the shell. Screw the clamp nut into

the shell.

(Tighten by turning the clamp nut. Do not tighten by

turning the shell.)

Cover with heat-shrink tubing and heat.

30 10

Clamp

Nut Gasket

(reddish

brown)

Clamp

Aluminum Foil

Trim shield here.

Trim aluminum

tape foil here.

Insulator

Clamp Nut Pin

Shell

Solder through

the hole.

50 30

4. WIRING

The figure below shows the connection of cables on rear of display unit.

Ground the receiver to

prevent loss of sensitivity

and mutual interference.

CAUTION

Rear of Display Unit

Ground

External Equipment

FUSE 2A

Black Red

DATA1

DATA3DATA4

DATA2

INPUT

10.2~31.2VDC

Antenna Unit

GPA-018S GPA-017S

20cm

GPA-019S

ANT

–

Connection of cables on display unit

4. WIRING

Grounding

The display unit contains several CPUs. While they are operating, they radiate noise, which

can interfere with other radio equipment. Ground the unit as follows to prevent it.

•

The grounding wire should be 1.25sq or larger.

•

The grounding wire should be as short as possible.

External Equipment

The DATA1, DATA2, and DATA3 ports are used to connect an external equipment such as

autopilot, remote display, navigation equipment. Refer to the interconnection diagram on

page S-1 for connection of DATA1, DATA2 and DATA 3 port. The DATA4 port is used to

connect NMEA equipment, IBM-PC or DGPS beacon receiver as follows;

Connection of DATA4 port

DATA4

TD-A

TD-B

RD-A

RD-B

S·G

RS-422 level

IBM PC

Beacon Receiver

NMEA equipment

In case of RS-422 Level

DATA4

S·G

In case of RS-232C Level

RS-232C level

IBM PC

Beacon Receiver

NMEA equipment

NOTE: See page 15 for selection of input/output signal.

5. INITIAL SETTINGS

Checking Operation

1. Turn on the GP-80.

2. Confirm that "OK" and "BEACON RCVR INSTALLED" are display on the self-test

display.

Confirm that "BEACON RCVR

INSTALLED" is displayed when

DGPS function is provided.

BEACON RCVR INSTALLED

DATA #3: LOG PULSE OUTPUT

PROGRAM MEMORY =OK

SRAM =OK

=OK

Internal Battery

Self-test display at equipment start up

3. At the GP-80, press [MENU ESC], [8] and [1]. Confirm that "BEACON OK" is displayed.

DGPS Setup

The default setting is "manual".

Automatic DGPS setup

The GR-800 can automatically select optimum reference station by feeding it position data.

If it takes more than 5 minutes to fix DGPS position at the automatic mode, switch to

manual mode. Use at manual mode when a external beacon receiver has no automatic

function of station selection.

1. Press [MENU ESC], [9] and [7] to display the DGPS SETUP menu.

These items appear when

"MAIN" is selected.

DGPS SETUP

Freq. 288.0kHz

ENT: Enter MENU: Escape

Baud Rate 200 bps

DGPS MODE

Ref. Station Auto Man(ID= )___

:Select

On Off

DGPS SETUP menu

2. Press

to select DGPS MODE and press

to select On.

3. Press

to select Ref. Station.

4. Press

to select Auto.

Autres manuels pour GP-80

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Furuno GPS

Furuno

Furuno GP-150-Dual Manuel utilisateur

Furuno

Furuno GP-1610C Manuel utilisateur

Furuno

Furuno GP-1670F Manuel

Furuno

Furuno FEA-2807 Manuel utilisateur

Furuno

Furuno LC-90 Mark-II Manuel utilisateur

Furuno

Furuno GP-1670F Guide de démarrage rapide

Furuno

Furuno GN-86F Manuel utilisateur

Furuno

Furuno GPS Navigator GP-500 MARK-2 Manuel utilisateur

Furuno

Furuno GP-39 Manuel utilisateur

Furuno

Furuno Felcom 82 Manuel

Furuno

Furuno GP-320B Manuel utilisateur

Furuno

Furuno GP-500 Manuel utilisateur

Furuno

Furuno GP-170 Manuel utilisateur

Furuno

Furuno LC-90MK2 Manuel utilisateur

Furuno

Furuno GP-80 Manuel utilisateur

Furuno

Furuno GP-90 Manuel utilisateur

Furuno

Furuno GP-7000 Manuel utilisateur

Furuno

Furuno KW-941 Manuel utilisateur

Furuno

Furuno GP-39 Manuel utilisateur

Furuno

Furuno NAVNET 3D MFD8/12/BB Manuel utilisateur

Furuno

Furuno GP-330B Manuel utilisateur

Furuno

Furuno GP-50 MARK-3 Manuel utilisateur

Furuno

Furuno GP-3500 Manuel utilisateur

Furuno

Furuno GP-330B Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
