Fujitsu SFP MSA Manuel utilisateur
Specifications
SFP
SFP MSA
MSA Transceiver
Transceiver
• SFP MSA compliant
• Compact package: 56.5 x 13.7 x 8.6mm
• SFF-8472 compliant diagnostic monitor integrated
• Optical interface for SDH STM-16/SONET OC-48,
Gigabit Ethernet
• Applicable for DWDM systems (up to 2.7Gbps)
• RoHS compliant
Description
-5 to 85 °C
56.5 x 13.7 x 8.6 mm / 2.22 x 0.54 x 0.34 inchesDimensions (L x W x H)
1.1W (Max)
Single 3.3 V ±5 %
Compliant with Telcordia GR-253 CORE and ITU-T G.957
> 8.2 dB
0.622 to 2.488 Gbps
1600 ps/nm
80 km
-5 to 70 °C
-9 to -29 dBm
-1 to 4 dBm
-7 to 7 nm
1471 to 1611 nm
CWDM
FIM32152Wxx
1.3 W (Max)
2400 ps/nm
-9 to -28 dBm
0 to 4 dBm
120 km
±100 pm
1528 to 1565 nm
0.622 to 2.7 Gbps
DWDM
FIM32160Wxx
Chromatic Dispersion
Power Supply Voltage
Wavelength Accuracy (EOL)
Wavelength
Distance
Data Rate
Power Consumption
Operating Case Temperature
Application
Receiver Sensitivity
Eye Mask for Optical Output
Extinction Ratio
Optical Output Power
Part Number
Specifications are subject to change without prior notice.
Fujitsu Limited
Optical ComponentｓUnit
Sales & Marketing Department
1-1 Kamikodanaka 4-chome, Nakahara-ku, Kawasaki, 211-8588, Japan (Company Mail No. H0913)
Tel: +81-44-754-3086, Fax: +81-44-754-3598
E-mail: [email protected]
http://www.fujitsu.com/global/services/telecom/optcompo January, 2009
