Fujitsu MAU3147FC Manuel utilisateur

C141-E215-01EN

MAU3147FC

MAU3073FC

MAU3036FC

DISK DRIVES

PRODUCT/MAINTENANCE MANUAL

C141-E215

FOR SAFE OPERATION

Handling of This Manual

This manual contains important information for using this product. Read thoroughly before using the product.

Use this product only after thoroughly reading and understanding especially the section "Important Alert

Items" in this manual. Keep this manual handy, and keep it carefully.

FUJITSU makes every effort to prevent users and bystanders from being injured or from suffering damage to

their property. Use the product according to this manual.

IMPORTANT NOTE TO USERS

READ THE ENTIRE MANUAL CAREFULLY BEFORE USING THIS PRODUCT. INCORRECT

USE OF THE PRODUCT MAY RESULT IN INJURY OR DAMAGE TO USERS, BYSTANDERS OR

PROPERTY.

While FUJITSU has sought to ensure the accuracy of all information in this manual, FUJITSU assumes no

liability to any party for any damage caused by any error or omission contained in this manual, its updates or

supplements, whether such errors or omissions result from negligence, accident, or any other cause. In

addition, FUJITSU assumes no liability with respect to the application or use of any product or system in

accordance with the descriptions or instructions contained herein; including any liability for incidental or

consequential damages arising therefrom.

FUJITSU DISCLAIMS ALL WARRANTIES REGARDING THE INFORMATION CONTAINED

HEREIN, WHETHER EXPRESSED, IMPLIED, OR STATUTORY.

FUJITSU reserves the right to make changes to any products described herein without further notice and

without obligation.

This product is designed and manufactured for use in standard applications such as office work, personal

devices and household appliances. This product is not intended for special uses (atomic controls, aeronautic or

space systems, mass transport vehicle operating controls, medical devices for life support, or weapons firing

controls) where particularly high reliability requirements exist, where the pertinent levels of safety are not

guaranteed, or where a failure or operational error could threaten a life or cause a physical injury (hereafter

referred to as "mission-critical" use). Customers considering the use of these products for mission-critical

applications must have safety-assurance measures in place beforehand. Moreover, they are requested to

consult our sales representative before embarking on such specialized use.

Compliance With Taiwanese Standards on Radio Wave Use (BSMI).

C141-E215

Caution

This computer device shall meet FCC Class A environment. If you use this device at Home environment, it

may affect to the Television set, Radio receiver, and so on.

In this case, you may require to take action to resolve any affection due to this device.

The contents of this manual may be revised without prior notice.

The contents of this manual shall not be disclosed in any way or reproduced in any media without the express

written permission of Fujitsu Limited.

This page is intentionally left blank.

C141-E215

REVISION RECORD

Edition Date published Revised contents

01 November, 2004

Specification No.: C141-E215-**EN

C141-E215

Related Standards

Product specifications and functions described in this manual comply with the following ANSI (*1)

standards.

Document number Title

NCITS TR-19 FIBRE CHANNEL PRIVATE LOOP SCSI DIRECT ATTATH (FC-PLDA)

ANSI X3.230-1994 FIBRE CHANNEL PHYSICAL AND SIGNALING INTERFACE (FC-PH)

ANSI X3.297-1996 FIBRE CHANNEL PHYSICAL AND SIGNALING INTERFACE-2 (FC-PH-2)

ANSI X3.272-199X FIBRE CHANNEL ARBITRATED LOOP (FC-AL)

ANSI X3.269-199X FIBRE CHANNEL PROTOCOL FOR SCSI (SCSI-FCP)

*1 ANSI = American National Standard Institute

In case of conflict between this manual and any referenced document, this manual takes precedence.

C141-E215 i

Preface

This manual describes the MAU3147FC, MAU3073FC, and MAU3036FC 3.5 type fixed

disk drives with an embedded fibre channel controller.

This manual details the specifications and functions of the above disk drive, and gives the

requirements and procedures for installing it into a host computer system.

This manual is written for users who have a basic understanding of fixed disk drives and

their use in computer systems. The MANUAL ORGANIZATION section describes

organization and scope of this manual. The need arises, use the other manuals.

The organization of this manual, related reference manual and conventions for alert

messages follow.

Overview of Manual

This manual consists of the following seven chapters and one appendix:

Chapter 1 General Description

This chapter introduces the disk drives and discusses their standard features, hardware, and

system configuration.

Chapter 2 Specifications

This chapter gives detailed specifications of the disk drives and their installation

environment.

Chapter 3 Data Format

This chapter describes the data structure of the disk, the address method, and what to do

about media defects.

Chapter 4 Installation Requirements

This chapter describes the basic physical and electrical requirements for installing the disk

drives.

Chapter 5 Installation

This chapter explains how to install the disk drives. It includes the notice and procedures

for setting device number and operation modes, mounting the disk drive, and confirming

drive operation.

Chapter 6 Diagnostics and Maintenance

This chapter describes the automatic diagnosis, and maintenance of the disk drive. This

chapter also describes diagnostic methods for operation check and the basics of

troubleshooting the disk drives.

Chapter 7 Error Analysis

This chapter describes in details how collect the information for error analysis and how

analyze collected error information.

Preface

ii C141-E215

APPENDIX A Connector Signal Allocation

The appendix gives supplementary information, including the signal assignments of

interface connectors.

CONVENTIONS USED IN THIS MANUAL

The MAU3147FC, MAU3073FC, and MAU3036FC disk drives are described as "the

intelligent disk drive (IDD)", "the drive" or "the device" in this manual.

Decimal number is represented normally.

Hexadecimal number is represented as X'17B9', 17B9h or 17B9H.

Binary number is represented as "010".

Conventions for Alert Messages

This manual uses the following conventions to show the alert messages. An alert message

consists of an alert signal and alert statements. The alert signal consists of an alert symbol

and a signal word or just a signal word.

The following are the alert signals and their meanings:

This indicates a hazardous situation could result in minor

or moderate personal injury if the user does not perform

the procedure correctly. This alert signal also indicates

that damages to the product or other property, may occur if

the user does not perform the product correctly.

This indicates information that could help the user use the

product more efficiently.

In the text, the alert signal is centered, followed below by the indented message. A wider

line space precedes and follows the alert message to show where the alert message begins

and ends. The following is an example:

(Example)

Damage

Never open the disk enclosure in the field. Opening the disk enclosure

may cause an irreparable fault.

The main alert messages in the text are also listed in the “Important Alert Items.”

Preface

C141-E215 iii

Attention

Please forward any comments you may have regarding this manual.

To make this manual easier for users to understand, opinions from readers are needed.

Please write your opinions or requests on the Comment at the back of this manual and

forward it to the address described in the sheet.

This page is intentionally left blank.
