Fujitsu PRIMERGY TX150 S6 Manuel utilisateur

PRIMERGY TX150 S6 Server

Operating Manual

Edition February 2008

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability. The right to technical modification is reserved.

All hardware and software names used are trade names and/or trademarks of their respective

manufacturers.

TX150 S6 Operating Manual

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Concept and target groups for this manual . . . . . . . . . . 7

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 8

1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 18

1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 19

2 Installation steps, overview . . . . . . . . . . . . . . . . . . 21

3 Important information . . . . . . . . . . . . . . . . . . . . . 23

3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 23

3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 30

3.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 31

3.5 Notes on installing in the rack . . . . . . . . . . . . . . . . . 32

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 33

4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 35

4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 36

4.2 Setting up the floorstand model . . . . . . . . . . . . . . . . 37

4.2.1 Mounting the anti-tilt bracket . . . . . . . . . . . . . . . . . . . 38

4.3 Mounting the rack model . . . . . . . . . . . . . . . . . . . 40

4.3.1 Installation in PRIMECENTER/DataCenter Rack . . . . . . . . 45

4.3.2 Installation in Classic Rack . . . . . . . . . . . . . . . . . . . 48

4.3.3 Installation in 3rd party racks . . . . . . . . . . . . . . . . . . 56

4.3.4 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 57

Operating Manual TX150 S6

Contents

4.4 Connecting devices to the server . . . . . . . . . . . . . . . 60

4.5 Connecting the server to the mains . . . . . . . . . . . . . . 61

4.6 Notes on connecting/disconnecting cables . . . . . . . . . . 63

5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 65

5.1 Access to drives (floorstand model) . . . . . . . . . . . . . . 65

5.2 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 67

5.2.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 67

5.2.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

5.3 Switching the server on and off . . . . . . . . . . . . . . . . 76

5.4 Configuring the server . . . . . . . . . . . . . . . . . . . . . 78

5.4.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 78

5.4.2 Configuring the PCI SAS controller with "Integrated Mirroring

Enhanced" . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

5.4.3 Configuring the PCI SAS controller with RAID functionality . . . 79

5.4.4 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 79

5.4.5 Configuration without ServerStart . . . . . . . . . . . . . . . . 80

5.5 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 81

6 Property and data protection . . . . . . . . . . . . . . . . . . 83

6.1 Mechanical access protection . . . . . . . . . . . . . . . . . 83

6.2 BIOS Setup security functions . . . . . . . . . . . . . . . . . 83

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 85

7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 85

7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 86

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 86

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 87

7.5 No screen display or display drifts . . . . . . . . . . . . . . . 87

7.6 No mouse pointer displayed on screen . . . . . . . . . . . . 88

7.7 Unable to read from / write to floppy disk . . . . . . . . . . . 88

TX150 S6 Operating Manual

Contents

7.8 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 88

7.9 Drives reported as “dead” when starting system . . . . . . 89

7.10 Added drive reported as defective . . . . . . . . . . . . . . 89

7.11 Error message on screen . . . . . . . . . . . . . . . . . . . 89

8 CSS components . . . . . . . . . . . . . . . . . . . . . . . . 91

8.1 Hot-plug components . . . . . . . . . . . . . . . . . . . . . 92

8.1.1 Hot-plug power supply units . . . . . . . . . . . . . . . . . . . 92

8.1.1.1 Replacing the hot-plug power supply unit . . . . . . . . . . 92

8.1.1.2 Adding a hot-plug power supply unit . . . . . . . . . . . . . 93

8.1.2 Hot-plug hard disk drives . . . . . . . . . . . . . . . . . . . . 94

8.1.2.1 HDD module and dummy module . . . . . . . . . . . . . . 95

8.1.2.2 Handling hard disk drives and HDD modules . . . . . . . . 97

8.1.2.3 Removing/installing the dummy module . . . . . . . . . . . 98

8.1.2.4 Unlocking the HDD module . . . . . . . . . . . . . . . . . 100

8.1.2.5 Installing the HDD module . . . . . . . . . . . . . . . . . . 102

8.1.2.6 Removing the HDD module . . . . . . . . . . . . . . . . . 104

8.2 Non-hot-plug components . . . . . . . . . . . . . . . . . . . 105

8.2.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 105

8.2.1.1 Opening the server - floorstand model . . . . . . . . . . . . 105

8.2.1.2 Opening the server - rack model . . . . . . . . . . . . . . . 106

8.2.2 Identifying a defective CSS component . . . . . . . . . . . . . 108

8.2.3 Replacing a memory module . . . . . . . . . . . . . . . . . . 109

8.2.4 Replacing the system fan . . . . . . . . . . . . . . . . . . . . 110

8.2.5 Replacing an expansion card . . . . . . . . . . . . . . . . . . 111

8.2.6 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 113

8.2.6.1 Closing the server - floorstand model . . . . . . . . . . . . 113

8.2.6.2 Closing the server - rack model . . . . . . . . . . . . . . . 114

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

TX150 S6 Operating Manual 7

1 Preface

The PRIMERGY TX150 S6 server is an Intel-based server for small and

medium-sized networks and can be used as a floorstand or rack model. The

floorstand model can be converted to a rack model using an optional conversion

kit.

Thanks to its highly developed hardware and software components, the

PRIMERGY TX150 S6 server offers a high level of data security and availability.

These include hot-plug hard disk drive modules, optional hot-plug power supply

units, the ServerView server management software, Prefailure Detection and

Analyzing (PDA) and Automatic Server Reconfiguration and Restart (ASR&R).

Security functions in the BIOS-Setup and on the system board protect the data

on the server against manipulation. Additional security is provided by the

lockable drive cover on the floorstand model and the lockable rack door on the

rack model.

The rack model occupies 5 height units in the rack.

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This operating manual is intended for those responsible for installing the

hardware and ensuring that the system runs smoothly. It contains all the infor-

mation you need to put your PRIMERGYTX150 S6 into operation.

To understand the various expansion options, you will need to be familiar with

the fields of hardware and data transmission and you will require a basic

knowledge of the underlying operating system.

8 Operating Manual TX150 S6

Documentation overview Preface

1.2 Documentation overview

More information on your PRIMERGY TX150 S6 can be found in the following

documents:

– “Quick Start Hardware - PRIMERGY TX150 S6” leaflet (only included as a

printed copy)

– “Quick Start Software - Quick Installation Guide” leaflet (only included as a

printed copy)

– “Safety notes and other important information” manual

– “Warranty” manual

– “Customer Self Service (CSS)” manual

– “Ergonomics” manual

– “Returning used devices” manual

– “Helpdesk” leaflet

– Technical manual for the system board D2559

– “PRIMERGY TX150 S6 Server Operating Manual”

– “PRIMERGY TX150 S6 Server Options Guide”

– “BIOS Setup V4.06 / FirstBIOS Desktop Pro V5.0 /TrustedCoreTM V6.0”

manual

– “SAS/SATA Controller MegaRAID 1064 / 1068 / 1078 Installation Guide”

– "LSI SATA Software RAID User’s Guide"

– “LSI Logic MegaRAID SAS Software User’s Guide”

– “LSI Logic MegaRAID SAS Device Driver Installation” manual

– "Integrated RAID for SAS User’s Guide"

– “Embedded SATA Software RAID for ICH7R User’s Guide”

– “ServerView RAID User's Guide”

– “Integrated Mirroring User’s Guide”

TX150 S6 Operating Manual 9

Preface Documentation overview

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD. The ServerBooks DVD is part of the ServerStart Suite supplied with

every server.

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL:

http://manuals.fujitsu-siemens.com. The PRIMERGY server documentation

can be accessed using the Industry standard servers navigation option.

If you need a replacement copy of the ServerBooks DVD, send the

details of your server to the following e-mail address: Reklamat-PC-

[email protected]

Further sources of information:

– Manual for the monitor

– Documentation for boards and drives

– Documentation for your operating system

– Information files on your operating system

10 Operating Manual TX150 S6

Features Preface

1.3 Features

Customer Self Service (CSS)

The Fujitsu Siemens Computers Customer Self Service (CSS) concept enables

you to identify and replace the affected component yourself in the case of

certain error scenarios.

In the CSS concept, you can replace the following components yourself in the

event of an error:

– Hot-plug hard disk drives

– Hot-plug power supply units

– Memory modules

– System fans

– Expansion cards

For information on replacing these components, see chapter “CSS compo-

nents” on page 91.

CSS indicators on the control panel and on the back of the PRIMERGY server

provide you with information if a CSS event arises (for more information on the

behavior of these indicators, see chapter “Important information” on page 23

and the "Customer Self Service (CSS)" manual on the ServerBooks DVD).

You can also fit your server with a ServerView Local Service Panel, which

enables you to identify the type of component affected by the error directly on

the server (for more information, see the "Customer Self Service (CSS)" manual

on the ServerBooks DVD).

In addition, CSS errors are displayed in ServerView S2, the server

management software from Fujitsu Siemens Computers.

In the event of errors, ServerView S2 refers you directly to the affected

component and its order information in the Illustrated Spares catalog of the

server in question.

System board

The features of the system board are described in the technical manual for the

system board D2559 for the hardware and in the “BIOS Setup” for the firmware.

Autres manuels pour PRIMERGY TX150 S6

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu SPARC Enterprise M4000 Manuel de service

Fujitsu

Fujitsu FUTRO S550 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX620 S6 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX600 S4 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel de service

Fujitsu

Fujitsu Primergy ECONEL 100 S2 Guide rapide

Fujitsu

Fujitsu Primergy BX920 S4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX922 S2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX1330 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX300 S5 Manuel utilisateur

Fujitsu

Fujitsu SPARC ENTERPRISE T1000 Manuel technique

Fujitsu

Fujitsu PRIMERGY CX400 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX920 S2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX620 S4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX2520 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX920 S2 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel de service

Fujitsu

Fujitsu SPARC Enterprise M8000 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX600 Manuel utilisateur

Fujitsu

Fujitsu Primergy BX900 S2 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2400E3 Instructions d'utilisation et d'entretien

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX600 S3 Mode d’emploi

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
