Fujitsu FI 4220C - Document Scanner Manuel

Operator's Guide

fi-4220C Image Scanner

P3PC-E017-01EN

INTRODUCTION

Thank you for buying the fi-4220C Duplex Color Scanner.

The fi-4220C scanner is capable of scanning color images on both

sides, and has the following features.

■

■ ■

■ Easy Scanning and Display

The ADF (Automatic Document Feeder) allows you to scan

A4-size duplex color documents at a high speed of 25 pages

per minute.

■

■ ■

■ Easily Installable

The scanner's small size allows it to be installed almost

anywhere.

About this manual

How This Manual Is Organized

This manual is organized as follows. An index is provided at the

end of this manual.

1 PREPARING THE SCANNER

This chapter describes how to prepare the scanner for

use.

2 INSTALLATION OF A SCANNER

This chapter describes how to install and connect the

scanner, and how to install the scanner application.

3 BASIC SCANNER OPERATIONS

This chapter describes basic scanner operations.

4 SCANNING VARIOUS TYPES OF DOCUMENTS

This chapter describes how to scan various types of

documents.

5 DAILY CARE

This chapter describes how to clean the scanner.

6 REPLACING CONSUMABLES

This chapter describes how to replace scanner

consumables.

7 TROUBLESHOOTING

This chapter describes how to remedy document jams,

other trouble, items to check before contacting the agent

where you bought the scanner, and how to check device

labels.

iii

8 ADF AND PAPER SPECIFICATION

This chapter describes the required document size and

paper quality for ensuring correct operation of the ADF.

9 SCANNER SPECIFICATION

This chapter lists the scanner specifications.

We hope that this manual is useful in taking full advantage of the

fi-4220C Duplex Color Scanner's advantages.

April, 2002

Revisions

FCC declaration

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for

help.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conformme à la norme

NMB-003 du Canada.

WARNING

Changes or modifications not expressly

approved by the party responsible for

compliance could void the user’s authority to

operate the equipment.

NOTICE •The use of a non-shielded interface cable

with the referenced device is prohibited.

The length of the parallel interface cable

must be 3 meters (10 feet) or less. The

length of the serial interface cable must be

15 meters (50 feet) or less.

•The length of the AC cable must be 3

meters (10 feet) or less.

Bescheimigung des Herstellers / Importeurs

Hiermit wird bescheinigt, daß der/dieldas

•fi-4220C in Übereinsstimmung mit den Bestimmungen der

•AmtsblVfg 243/1991 funkentstört ist. Der Deutschen

Bundesport wurde das Inverkehrbringen dieses Gerätes

angezeigt und die Berechtigung zur Überprüfung der Serie auf

Einhaltung der Bestimmungen eingeräumt.

•Maschinenlärminformationsverordnung 3. GS GV,

18.01.1991:Der höchste Schalldruckpegel beträgt 70 dB (A)

order weniger gemäß ISO/7779.

vii

International Energy Star Program

As a participating operator of the International Energy

Star Program, PFU LIMITED. certifies that this product

satisfies the requirements of the International Energy

Star Program.

The International Energy Star Program is an international program

for promoting energy conservation in computers and other office

equipment. The purpose of this program is to promote the

development and propagation of products provided with functions

for efficiently limiting energy consumption. Operators opt to

participate in this program on a voluntary basis. Equipment

covered by this program are computers, displays, printers,

facsimiles, copiers, and other office equipment. The standards for

each of these equipment Energy Star mark ( ) are unified by

each participating country.

Use in High-safety Applications

This product has been designed and manufactured on the

assumption that it will be used in office, personal, domestic, regular

industrial, and general-purpose applications. It has not been

designed and manufactured for use in applications (simply called

"high-safety applications" from here on) that directly involve serious

danger to life and health when an extremely high degree of safety

is required, for example, in the control of nuclear reactions at

nuclear power facilities, automatic flight control of aircraft, air traffic

control, operation control in mass-transport systems, medical

equipment for sustaining life, and missile firing control in weapons

systems, and when provisionally the safety in question is not

ensured. The user should use this product without adopting

measures for ensuring safety in such high-safety applications. FPU

Co., Ltd. assumes no liability whatsoever for damages arising from

use of this product by the user in high-safety applications, and for

any claims or compensation for damages by the user or a third

party.

viii

About the use of mercury

Scanner lamp includes mercury.

Too avoid unexpected injury, read the followings carefully.

Doing following actions may result in serious personal injuries:

•Put the substance in the lamp into mouth as it contains mercury.

•Vaporize, crumb, condense the scanner.

•Aspirate the chemical liquid containd in scanner parts.

Dispose of the scanner should be conducted as required by local

ordinances or regulations.

Illegal Copying

Copying of bank notes, currency, government-issued bonds and

passports, licenses and permits issued by public and private

organizations, official documents, private documents, etc. is illegal

and punishable by law.

drawings, photographs, etc. cannot be reproduced without the

permission of the rightful person except in individual or domestic

applications, or in other similar applications within a limited scope.

Trademarks

Microsoft®, Windows®and Windows NT®are registered

trademarks of Microsoft Corporation of the USA and other

respective countries.

ISIS®is a registered trademark of Pixel Translations, A Division of

Actionpoint Inc.

Adobe and the Adobe logo as well as Acrobat and the Acrobat

Logo are trademarks of Adobe Systems Incorporated.

Other product names referred to in this manual are registered

trademarks or trademarks of respective companies.

How Trademarks Are Indicated In This Manual

References to operating systems (OS) are indicated as follows:

Windows®95: Refers to Microsoft®Windows®98 operating

system.

Windows®98: Refers to Microsoft®Windows®98 operating

system.

Windows®Me: Refers to Refers to Microsoft®Windows®

Millennium Edition operating system.

Windows®2000: Refers to Microsoft®Windows®2000

Professional operating system.

Windows®XP: Refers to Microsoft®Windows®XP Professional

operating system, and Microsoft®Windows®XP

Home Edition operating system

Windows NT®: Refers to Microsoft®Windows NT®operating

system Version4.0.

Where there is no distinction between the different versions of the

above operating system, the general term "Windows®" is used.
